Lincoln Electric PIPELINER LN-23P Manuel utilisateur

Wire Feed Speed Wire Size Dimensions Net

Product Product Input Range Range H x W x D Weight

Name Number Power Rated Current / Dut C cle ipm (m/min) in. (mm) in. (mm) lbs. (kg)

LN-23P K316L-1 14-50V DC 350A/60% 30-170 .068-5/64 20.5 x 9 x 19 27

(0.76-4.3) (1.7-2.0) (520 x 230 x 480) (12.3)

Innershield (FCAW-S)

Processes

LN-23P Wire Feeder

K316L-1 LN-23P

Order

Advantage Lincoln

• Weighs less than 50 lbs (22 7 kg) including optional

Magnum® Innershield® gun and 14 lb (6 3 kg) coil of

electrode

• Continuous wire feed speed control, voltage control

and analog voltmeter are standard

• Completely enclosed wire reel keeps the wire free of

contaminants

• Equipped with trigger interlock circuit to reduce

operator fatigue

• Gun-mounted two-position switch allows on-the-fly

change to 83% of the preset wire feed speed

• Electrode and control cable quickly connect to power

source

• One or two LN-23P wire feeders can be directly

connected to recommended Lincoln power sources,

but only one can be used at a time

• 3 year warranty on parts and labor

• Manufactured under a quality system certified to

ISO 9001 requirements

SEMIAUTOMATIC WIRE FEEDERS

Description

The LN-23P semiautomatic wire feeder is able to handle the

toughest work sites and is an excellent choice for field erection

and pipe welding applications. It is portable, easy to set-up, and

ideal for reaching difficult locations. The LN-23P utilizes special

lightweight 14 lb. (6.35kg) Innershield (FCAW-S) coils, making it

extremely easy to carry around the job site, and has a built-in

dual wire feed speed switch for out-of-position welding.

CV-300, CV-400, CV-655, DC-400, DC-600, DC-655,

Ranger 250, Ranger 305, Commander 300, Commander 500

The Following Require Wire Feed Module (K632-1):

Pipeliner 200, SA-250, Classic II, Classic 300

The Following Require CV Adapter (K385-1):

SAE-400, SAE-400 Weld ‘N Air

Recommended Power Sources

www.lincolnelectric.com

E8.90 12/02

Technical Specifications

LN-23P Adapter Kit (K350 or K350-1)

Magnum Self-Shielded Gun (K355-10 or K345-10)

Required Options

• 25 ft. (7.6m) Control Cable

• 25 ft. (7.6m) 1/0 Electrode Cable

• 3/32” Drive Rolls and Guide Tubes

Unit Includes

Shown with required option -

Magnum self-shielded gun.

PRODUCT DESCRIPTION ORDER NUMBER QUANTITY PRICE

Custom r Assistanc Policy

Th busin ss of Th Lincoln El ctric Company is manufacturing and s lling high quality w lding quipm nt, consumabl s, and cutting quipm nt. Our chall ng is to m t th n ds of our custom rs and to

xc d th ir xp ctations. On occasion, purchas rs may ask Lincoln El ctric for advic or information about th ir us of our products. W r spond to our custom rs bas d on th b st information in our pos-

s ssion at that tim . Lincoln El ctric is not in a position to warrant or guarant such advic , and assum s no liability, with r sp ct to such information or advic . W xpr ssly disclaim any warranty of any

kind, including any warranty of fitn ss for any custom r’s particular purpos , with r sp ct to such information or advic . As a matt r of practical consid ration, w also cannot assum any r sponsibility for

updating or corr cting any such information or advic onc it has b n giv n, nor do s th provision of information or advic cr at , xpand or alt r any warranty with r sp ct to th sal of our products.

Lincoln El ctric is a r sponsiv manufactur r, but th s l ction and us of sp cific products sold by Lincoln El ctric is sol ly within th control of, and r mains th sol r sponsibility of th custom r. Many

variabl s b yond th control of Lincoln El ctric aff ct th r sults obtain d in applying this typ of fabrication m thods and s rvic r quir m nts.

Subj ct to Chang – This information is accurat to th b st of our knowl dg at th tim of printing. Pl as r f r to www.lincoln l ctric.com for any updat d information.

THE LINCOLN ELECTRIC COMPANY

22801 St. Clair Ave., Cleveland, OH 44117-1199 • 216.481.8100 • www.lincolnelectric.com

LN-23P Wire Feeder Order Form

Required Options

Magnum Self-Shielded

Gun

Rated 350 amps, 60% duty

cycle, 90° nozzle. For .068

through 5/64” (1.7 through

2.0 mm) Innershield wire.

Includes reduced speed

switch. 10 ft. (3.0m).

Order K345-10

Magnum Self-Shielded

Gun

For lighter weight and easier

handling. Rated 250 amps,

60% duty cycle. For .068

through 5/64” (1.7 through

2.0 mm) Innershield wire.

Includes reduced speed

switch. 10 ft. (3.0m).

Order K355-10

LN-23P Adapter Kit

Allows the LN-23P to be con-

nected to the power source,

but only one can be used at

a time. 115 AC input.

Order K350 - for Terminal

Strip connection.

Order K350-1 - for

14 Pin MS-type connection.

Power LN-23P Adapter

Source Kits Required

Pip lin r 200, SA-250, Classic II, Classic 300 K350-1 Adapt r Kit

K632-1 Wir F d Modul

CV-300, CV-400, CV-655, DC-400, DC-600, K350-1 Adapt r Kit

DC-655, Rang r 250, Rang r 305, Command r 300,

Command r 500

SAE-400, SAE-400 W ld ‘N Air K350 Adapt r Kit

K385-1 CV Adapt r

Power Sources and Adapters

LN-23P Wire Feeder K316-L

Required Options

LN-23P Adapter Kit: for Terminal Strip Connection K350

for 14 Pin MS-type Connection K350-1

Magnum Self-Shielded Gun - 350 Amps K345-10

Magnum Self-Shielded Gun - 250 Amps K355-10

Recommended Power Sources

CV-300 See publication E4.20

CV-400 See publication E4.30

CV-655 See publication E4.40

DC-400 See publication E5.20

DC-600 See publication E5.40

DC-655 See publication E5.46

Ranger 250 See publication E6.103

Ranger 305 See publication E6.117/E6.118

Pipeliner 200 with Wire Feed Module See publication E6.131/E6.132

SA-250 with Wire Feed Module See publication E6.160

Classic II with Wire Feed Module See publication E6.140

Classic 300 with Wire Feed Module See publication E6.155/E6.156

Commander 300 See publication E6.205

Commander 500 See publication E6.215

SAE-400 with CV Adapter See publication E6.180

SAE-400 Weld ‘N Air with CV Adapter See publication E6.185

TOTAL:
