Lighting Systems F7000-21

1BHFPG '4FSJFT-JHIU54PMJE8BMM.PVOU

E0808

Features

1. Housing: Single piece of high purity extruded aluminum, a portion from

recycled material.

2. Housing End: Die-cast aluminum, welded in place.

3. End Cap: Die-cast aluminum. Encloses the end of the run.

4. Lamps: F28T5 or F54T5HO as specified. By others. Installed fromthe ceiling

side of the luminaire.

5. Ballast: Electronic. Meets ANSI starting, end-of-life protection and sound

rating specifications. Low THD.

Electrical

Connections: Pre-wired with 18 gauge wires and polarized cannon plug con-

nectors for simultaneous mechanical/electrical connection.

Emergency Battery Pack: 90 minute operation, 700 lumens for 54W and 520

lumens for 28W.

Dimming: Advance Mark X standard (no additional wires required); use compat-

ible dimmer. Dimming ballasts using additional control wires (eg Lutron Hi-Lume

or ECO-10, Osram) can be used; consult factory and use X4 or X5 power feeds

with additional leads, as appropriate. Ballast not to exceed 1.25” (3.18cm) wide by

1.20” (3.05cm) high.

iGEN: F7000 accepts iGEN (DALI) with supplemental 2-wire control technology.

Use with X5 power feed.

Power Tray: Code-gauge, die-formed steel, pre-paint white enamel finish;

secured by quarter-turn fasteners for easy access to wiring. Holds ballasts, sock-

ets, and wiring. Accepts ballasts up to 1.25” (3.18cm) wide by 1.20” (3.05cm) high.

Finish

Powder-coated, baked enamel, white or aluminum, as specified.

Mounting

Each module includes two wall-mounting brackets. Bracket hole pattern accom-

modates junction box (single gang box rotated 90 degrees) or other appropriate

mounting method using customer supplied fasteners.

Labels

UL, cUL and I.B.E.W.

Ordering Instructions

Individual Fixtures:

1. Order one MODULE.

2. Order one END SET.

Continuous Rows:

1. Order the appropriate number of MODULES for the complete run.

2. Order one END SET.

Ordering Information

Complete Ordering Instructions below.

1.63”

(4.14cm)

3.25”

(8.26cm)

4.44” (11.28cm)

FW7

Family Series

Type Lamps Color Wattage Voltage Length

1 1

5= Curved 1= Solid 1= 1 LampAL = Aluminum

WH = White

1= 28W

2= 54W

3= 28W Dimming

4= 28W EM

5= 54W Dimming

6= 54W EM

1= 120v

2= 277v

4= 4’ (121.92cm)

8= 8’ (243.84cm)

Factory installed ballast disconnect allows the ballast to be disconnected fromand

reconnected to incoming power under load without turning the entire circuit off.

Job Information Type:

"JSQPSU3PBE'BMM3JWFS."tt'BY

We reserve the right to change details of design, materials and finish.

XXXMJHIUPMJFSDPN½1IJMJQT(SPVQt

Lighting Systems F7000-21

1BHFPG '4FSJFT-JHIU54PMJE8BMM.PVOU

E0808

CANDLEPOWER

ZONE 0 22 45 67 90

DEG.

CANDELAS

90 00000

95 69 79 93 120 53

105 434 454 461 374 243

115 814 780 673 598 439

125 949 925 875 775 621

135 1113 1094 1037 911 788

145 1218 1191 1119 1022 926

155 1226 1204 1159 1097 1034

165 1206 1195 1175 1141 1108

175 1160 1157 1157 1151 1143

180 1139 1139 1139 1139 1139

Performance

CANDLEPOWER CURVE

1200

900

600

300

100

110

120

130

140

150

160

170

180

REPORT NO.: ITL54694.IES

LAMPS: 1-F54T5

LUMENS: 5000 each

EFFICIENCY: 75.3%

CAT. NO.: F7511WH214

DISTRIBUTION

Zone Lumens % Lamp %Luminaire

0 - 90 0 0.0 0.0

90 - 180 3763 75.0 100.0

0 - 180 3763 75.0 100.0

80% 70% 50%

50 30 10 50 30 10 50 30 10

0 727272 6161 61 424242

1 626057 5351 49 363534

2 545047 4743 40 323028

3 484339 4137 34 282624

4 423732 3632 28 252220

5 373227 3227 24 221917

6 332723 2824 20 201714

7 302420 2521 18 181512

8 272117 2318 15 161311

9 241915 2116 13 14119

10 22 17 13 19 15 12 13 10 8

20% FLOOR CAVITY REFLECTANCE

COEFFICIENTS OF UTILIZATION

% EFFECTIVE CEILING CAVITY REFLECTANCE

WALL REFLECTANCE

ROOM CAVITY RATIO

Mounting Accessories

all Mount End Set

FW7EWH = White

FW7EAL = Aluminum

Fixture Lengths & Mounting Reflected (Plan View)

20'-3" (617.22cm)

16'-3" (495.30cm)

12'-3" (373.38cm)

8'-3" (251.46cm)4'-3" (129.54cm)

2'-8"

(81.28cm)6'-8" (203.20cm)

6'-8" (203.20cm)2'-8"

(81.28cm)

1'-4"

(40.64cm)

6'-8" (203.20cm)1'-4"

(40.64cm)6'-8" (203.20cm)

6'-8" (203.20cm)1'-4"

(40.64cm)6'-8" (203.20cm)2'-8"

(81.28cm)

1'-4"

(40.64cm)

16.00" (40.64cm)

3/4"

(1.91cm)

1-1/2"

(3.81cm)

3/8" (0.95cm)

END OF ROW DETAIL

GAP BETWEEN FIXTURES

JOINING DETAIL

Recommended mounting is a single gang outlet box rotated 90 degrees at the

feed point. Remaining mounting points could be outlet boxes as well, or a couple

of holes per mounting point spaced 3-1/4” (8.26cm) at 1-3/4” (4.45cm) above the

bottomof fixture.
