Lightolier SL205B Manuel utilisateur

Job Information Type:

Job Name:

Cat. No.:

Notes:

SL205B

Decorative, Spectral, Floating Paper, Optic Forms

Page 1 of 3

Ceiling Cutout: 6 1⁄16" (167mm)

Ordering Guide (2 Part System: Trim and Frame-In-Kit)

Trim Frame-In-Kit Lamp Volt Finish

SL205BT S6132BU 1-26/32W TTT 120/277V Clear acrylic with white lacquer lens

and stainless steel trim ring.

S6132B-347 1-26/32W TTT 347V

*Use 4100K lamp for optimal white lens rendering.

1 ⅛" MAX.

(29mm)

6 ⅞"

(175mm)

7 ⅞"

(200mm)

6 ⅛"

(156mm)

11 ⅛"

(283mm)

13 ⅝"

(346mm)

SL205B

Decorative, Spectral, Floating Paper, Optic Forms

Page 2 of 3

Job Information Type:

1 ⅛" MAX.

(29mm)

6 ⅞"

(175mm)

7 ⅞"

(200mm)

6 ⅛"

(156mm)

11 ⅛"

(283mm)

13 ⅝"

(346mm)

Features

1. Reflector: Specular aluminum, 16 ga. Comfort Clear low

iridescence finish.

2. Lens: 1 ⅛" (29mm) thick clear acrylic finished with a

translucent diffused coating.

3. Trim Ring: 12 ga. aluminum. Stainless steel finish.

4. Socket Cup: Heat dissipating die-cast aluminum. Positive

locking attachment, without tools, to reflector assures proper

optical alignment of lamp.

5. Mounting Frame: Die-cast aluminum suitable for dry

ceilings.

6. Retaining Springs: Rust resistant springs simplify reflector/

housing removal for inspection and maintenance.

7. Mounting Brackets: 16 ga. steel. Use 18" (457mm)

mounting bars (optional) or with standard ¾" (19mm), 1 ½"

(38mm) lathing channels (by others) or ½" (13mm) tubing (by

others). Adjust vertically from inside of fixture.

8. Junction Box: 14 ga. steel, 4" (102mm) x 3 ½" (89mm x 2"

(51mm) box, allows inspection from below. UL “c/us” listed for

through branch circuit wiring with maximum of 8 no. 12, 90º C

conductors.

9. Screws: Stainless steel, Philips head.

Mounting

Recessed, Non-IC Type (non thermal insulation contact).

Luminaire Weight: 5 lbs.

Electrical

Ballast: Electronic Program Rapid Start T4 quad lamp ballast.

Universal voltage “U” ballast automatically detect 120 volts or

277 volts operation. No visible flicker on starting, internally

fused and protection circuit for lamp end of life. Sound rated “A”.

Designed for removal without tools from inside of luminaire for

easy field inspection or service replacement.

TE: 26/32W TTT non-dimming

PM: 26/32W TTT Powerspec dimming HDF by Lightolier-

Controls

TQ: 26/32W TTT MARK-10 dimming by Advance

Lampholder: GX24q-3 base, 4 Pin.

Options and Accessories

Mounting Bars:

1950, set of 2, 18" (457mm) long.

1951, set of 2, 30" (762mm) long.

T-Bar Anchor Clips:

1956, set of 4, for anchoring mounting bars to T-Bar runners.

Labels

cULus Listed. Suitable for wet locations.

SL205B

Decorative, Spectral, Floating Paper, Optic Forms

Page 3 of 3

Philips Lightolier

e: [email protected]

t: (508) 679-8131

w: www.lightolier.com

SL205B February 23, 2012

Specifications are subject to change without notice.

Job Information Type:

Report No: LSC8923

Cat. No: SL205BTEU

1 x 32W TTT at 2400 lumens

Efficiency:39%

Spacing Ratio: 1.2

60°

30°

0º

110

180º

90°

Room Cavity Ratio

Coefficients Of Utilization - Zonal Cavity Method

Effective Floor Cavity Reflectance = .20

RC 80 70 50 30 10 0

RW 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

0 .46 .46 .46 .46 .45 .45 .45 .45 .43 .43 .43 .41 .41 .41 .39 .39 .39 .39

1 .42 .41 .39 .38 .41 .40 .39 .37 .38 .37 .36 .37 .36 .35 .35 .35 .34 .33

2 .39 .36 .34 .32 .38 .36 .33 .32 .34 .32 .31 .33 .32 .30 .32 .31 .30 .29

3 .36 .32 .30 .27 .35 .32 .29 .27 .31 .28 .27 .30 .28 .26 .29 .27 .26 .25

4 .33 .29 .26 .24 .33 .29 .26 .24 .28 .25 .23 .27 .25 .23 .26 .24 .23 .22

5 .31 .26 .23 .21 .30 .26 .23 .21 .25 .22 .20 .24 .22 .20 .24 .22 .20 .19

6 .28 .24 .20 .18 .28 .23 .20 .18 .23 .20 .18 .22 .20 .18 .21 .19 .15 .17

7 .26 .21 .18 .16 .26 .21 .18 .16 .20 .18 .16 .20 .17 .15 .19 .17 .15 .15

8 .24 .19 .16 .14 .24 .19 .16 .14 .19 .16 .14 .18 .16 .14 .18 .15 .14 .13

9 .23 .18 .15 .12 .22 .17 .14 .12 .17 .14 .12 .17 .14 .12 .16 .14 .12 .12

10 .21 .16 .13 .11 .21 .16 .13 .11 .16 .13 .11 .15 .13 .11 .15 .13 .11 .10

Determined in accordance with current IES published procedures

Luminaire input watts = 35.0

Candlepower summary

Angle Mean Lumens

0 365

5 365 35

10 363

15 355 100

20 341

25 323 148

30 300

35 275 171

40 244

45 214 165

50 185

55 158 141

60 128

65 97 97

70 70

75 49 52

80 31

85 14 15

90 1

Zonal Lumens and Percentages

Zone Lumens %Lamp %Fixt

0-30 283 11.81 30.64

0-40 454 18.92 49.10

0-60 760 31.67 82.17

0-90 925 38.54 100.00

40-90 470 19.62 50.90

60-90 164 6.87 17.83

90-180 0 0.00 0.00

0-180 925 38.54 100.00

ROOM SURFACE REFLECTANCES

80% Ceiling; 50% Wall; 20% Floor

2400 Lumens Per Lamp

RCR = 1 (Rm. width = 10 x mtg. ht. above work plane)

RCR = 5 (Rm. width = 2 x mtg. ht. above work plane)

RCR = 10 (Rm. width = mtg. ht. above work plane)

10 20 30 40 50 60 70 80 90

This quick calculator chart determines the number and spacing of 1 lt. - 32W TTT units

with Clear Alzak reflector, for any level of illumination.

AREA PER FIXTURE IN SQUARE FEET

CENTER TO CENTER DISTANCE OF FIXTURES IN FEET

INITIAL FOOTCANDLES

4 5 6 7 8 9 10

Quick Calculator

◄
