Liesegang Dv475 Manuel utilisateur

Bedienungsanleitung

User Manual

dv475

Liesegang Unternehmensgruppe

Table of contents

Before use 2

1. Scope of Delivery 7

1.1 Disposal of packing material 7

2. Parts Name of the Projector 8

3. Quick Setting Up 9

3.1 Setting up and connecting the projector 9

3.2 Projection distance and image size 9

4. Connections 10

4.1 Connecting a computer or a notebook pc 10

4.2 Connecting video equipments 10

5. Starting Up the Projector 12

5.1 First Steps 12

5.2 Adjustment 13

5.3 Standby mode 14

5.4 Projector power down 14

6. Using System Menus 15

6.1 On-Screen menu 15

6.2 List of functions 15

7. Infrared Remote Control 18

7.1 How to use the infrared remote control 18

7.2 General function keys 18

7.3 Mouse keys 18

7.4 Hot keys 18

7.5 Battery replacement 19

8. Cleaning and Replacing the Air Filter 19

9. Replacing Projection Lamp 20

10. Lamp counter 20

11. Troubleshooting Problems and Solutions 21

12. Resetting the Projector to Factory Default Settings 21

13. FCC Compliance Statement for United States Users 21

14. Service Hotline 22

15. Product Manufacturer 22

16. Glossary of Terms 23

17. Specifications 24

17.1 Optical 24

17.2 Electrical 24

17.3 Mechanical 24

18. Warranty terms 25

Before use

User Manual Data Video Projector 2

Before use – Please read the user manual

The following notes are intended to be a help for handling the product in accordance

with its designated purpose.

Attention:

A person could be killed or injured if the wrong operation is done by ignoring this indication.

__________________________________________________________________

Do not install this unit

in an unstable place.

Avoid placing it in an unstable place such as a weak base, an inclined floor, etc. This may cause the

projector to drop or fall over, resulting in injury.

Do not remodel

this unit.

Do not remodel this unit. It may cause a fire, an electric shock, etc.

Never use

the projector in a humid

environment.

Never use the projector in a humid environment, e.g. bathroom or close to cookers or humidifiers. This

could cause a fire, an electric shock, etc.

Only connect

to the specified mains voltage.

The projector must only be operated with the alternating current specified on the identification plate.

Please immediately check whether the supplied mains connection cable coincides with wall outlets at

the installation location.

Do not forget

the protective conductors.

Only use extension leads or cables with a minimum cross-section of 1.5 mm² and protective conduc-

tors.

Do not apply any shock.

If you drop this unit or if the casing is broken, turn off the power switch, disconnect the power plug and

contact your dealer. If you use it as it is, it may cause a fire, an electric shock, etc.

Before use

3 Data Video Projector User Manual

If any abnormality occurs.

It there is abnormal smell or smoke, if you use this unit as it is, this could cause a fire or an electric

shock, etc. Immediately turn off the power switch and pull out the power plug. Contact your dealer to

repair the unit. Do not repair it yourself, as it is very dangerous.

Do not use this unit as it is after trouble has occurred. Immediately turn off the power switch and pull

out the power plug, then contact your dealer to have it repaired.

If water, etc., enters the unit, turn it off, pull out the power plug and contact your dealer to have it re-

paired.

Be careful with the power cord.

Do not scratch, damage or modify the power cord. Do not bend it forcibly. Also do not put a heavy

object on it, do not heat it and do not pull it. If you do, the power cord may be damaged and it may

cause fire, electric shock, etc.

If the power cord is damaged (exposed or disconnected wire, etc.), replace it. It may otherwise cause

a fire, an electric shock, etc.

Make sure that no dirt adheres to the power plug and insert it until it stops. If dirt adheres or the con-

nection is incomplete it may cause a fire, an electric shock, etc.

Do not look directly into the lens

when the lamp is switched on.

Do not look directly into the lens when the lamp is switched on. Since a powerful lamp is used, it could

damage your vision, etc.

Do not put a container, etc,

with liquid on this unit.

Do not put a vase, flower pot, cosmetic container, medicine or water on this unit. If liquid spills and

enters the unit, it may cause fire, electric shock, etc.

Never leave the projector

switched on unsupervised.

Never leave the projector switched on unsupervised or let children play with it as unusual conditions

may occur which can cause a fire, an electric shock, etc.

Before use

User Manual Data Video Projector 4

Caution !

Non-observance can lead to injury or damage.

___________________________________________________________________

Caution

when carrying the unit.

When the unit is to be moved, be sure to disconnect the power plug and check that all external con-

nection cords are removed before moving it. If not, the cord may be damaged and it may cause a fire,

an electric shock, etc.

Do not place this unit

where it gets hot.

Be careful if you place the unit outdoors, in a place exposed to direct sunlight or near a heating device,

the casing and parts could be affected.

Cleaning the projector.

Handle the projector as you would do any other device with glass components. Avoid impact or drop-

ping. Before cleaning the device disconnect the mains plug.

The casing can be cleaned with a soft, slightly moistened cloth and mild detergent. Avoid the ingress

of moisture into the inside of the equipment. Never use solvents or abrasive cleaners. Do not leave

cleaners inside the projector.

Handle the power cord carefully.

Do not bring the power cord near a heating device. The cord’s shield may melt and it may cause a fire,

an electric shock, etc.

Do not insert / disconnect the power plug with wet hands. It may cause an electric shock.

Do not pull the power cord when the power plug is to be disconnected. The power cord may be dam-

aged and it may cause a fire, an electric shock, etc. Be sure to seize the power plug.

Do not step on this unit.

Do not put a heavy object on it.

Do not step on this unit or put a heavy object on it. Pay attention when children are present. If you do,

the unit may fall over or may be broken causing an injury.

Never block

the ventilation slots.

Never block the openings for the ventilation or place objects in the projector. Heat may accumulate in

side the projector and it may catch fire.

Before use

5 Data Video Projector User Manual

Temperature between 5°C and 35°C.

Do not use the unit while the temperature is high or varies greatly. The unit must be used at between

5°C (41°F) and 35°C (95°F).

Set the caster stoppers.

When this unit is installed on a table with casters, set the caster stoppers. If the table moves, it may

fall over, causing an injury.

If you do not use

the unit for a long time.

If you do not use the unit for an extended period of time, be sure to pull out the power plug from the

power outlet.

Replacing the lamp.

Switch off the projector and disconnect the mains plug before replacing the lamp. Let the device cool

down, as the lamp and other components in the projector casing have heated up during operation,

which can cause injury when touched.

Do not place this unit

in a moist or dusty place.

Do not place this unit in a moist or dusty place. It may cause a fire, an electric shock, etc. Do not place

this unit where it would be exposed to soot or steam, near a cooking stove or humidifier, etc. It may

cause a fire, an electric shock, etc.

Volume.

Use a volume level that does not bother persons in the neighborhood. Especially, since the sound is

likely to carry well at nighttime even at a low volume, be careful to choose a suitable level.

Clean the projector inside

at least once a year!

Ask your dealer to clean the unit inside once a year. If the unit is left with too much dust inside it may

cause fire.

Use of batteries.

Do not use batteries not specified for this unit. Do not use new batteries mixed with old ones. This may

cause a fire, injury due to burst of battery, liquid leakage.

Before use

User Manual Data Video Projector 6

When inserting batteries in this unit, pay attention to the direction of the + and - polarities and insert

the batteries correctly. If the polarities are confused, it may cause injury or damage near the unit due

to burst batteries, liquid leakage, etc.

Scope of Delivery / Disposal of Packing Material

7 Data Video Projector User Manual

1. Scope of Delivery

Your projector should come with the items shown below. Check to make sure that all the

items are included. Contact your dealer if anything is missing.

Following accessories available:

Spare lamp kit Order-No.: ZU 0201044010

Air filter Order-No.: EK 0201011150

USB mouse cable Order-No.: ZU 0260700008

Soft-Case Order-No.: ZU 0201980010

Ceiling mount kit Order-No.: ZU 0201750009

In case of extreme operating conditions:

In case of extreme operating conditions – examples: >8-hour-operation, severe vibra-

tions, great temperature fluctuations, heavy nicotine or other aggressive smoke, heights

exceeding 3000 m – please contact your dealer. We recommend that you conclude a

maintenance contract.

Important note:

The projector features its own electronic multi-range power supply with automatic switch-

ing. It must only be operated with 100 V - 240 V AC with a frequency of 50 Hz to 60 Hz.

The unit must only be connected to a

properly

installed network with protective conduc-

tor. Please check immediately whether the supplied mains cable is compatible with the

mains sockets on-site. Please contact your supplier if a different power supply cable is

required for use abroad.

1.1 Disposal of Packing Material

The transport packing consist only of materials which may be disposed.

Remark:

The transport packing offers perfect protection for the product and should be kept for fur-

ther transport etc.

Projector

Remote control

AAA battery (2x)

Bedienungsanleitung

User Manual

FREEZE

VOLUME ZOOM

AUTO

MUDE

LASER

ENTER

POWER

ESC

SOURCE MENU

Parts Name of the Projector

User Manual Data Video Projector 8

2 Parts Name of the Projector

Front, side and top

Bottom and rear side

Lens

Lens Cover

Exhaust Vents

Adjuster Leg Main Power Switch

Power Input Socket (AC IN)

Handle

Remote

Sensor

( Front )

Speaker

Focus Ring

Zoom Ring

Control Panel and Indicators

Power

Source

Keystone

Auto

Esc

Volume

Lamp Temp

Enter

Adjuster Legs

ir Filter

Lamp Cover

Remote Sensor

( Rear )

Cooling Fans and Ventilation Slot

Connector Panel

Video

S-Video

Audio

Cb/Pb

Cr/Pr

DVI-D

RGB out

Rs232 USB RGB in 2

RGB in 1

Quick Setting Up

9 Data Video Projector User Manual

3. Quick Setting Up

3.1

Setting up and connecting the projector

These instructions are intended to get you going fast.

To avoid damage to the equipment, all power to projector and input sources

must be turned off during cable hook up.

It is imperative that you ensure that the device is inclined in the direction of the

projection at an angle not exceeding +30°. In all other directions, the projector can be

tilted at around ±5°. Please keep these values in order to avoid damage to the device.

1. Place the projector on a rigid, non-slip surface.

2. Connect the power cord.

3. Connect the audio and computer/video input cables to the projector input terminals.

4. For mouse emulation, connect the mouse and, in case of PS/2 and USB, the appro-

priate adapter.

5. Power up the projector then the computer and the video sources.

6. Move the projector nearer or further away from the screen to obtain the best image

size or adjust the image size with the Zoom buttons of the remote control.

3.2 Projection distance and image size

The distance from projector lens to the screen will determine the size of the projected im-

age. The maximum image size is about 8 – 10m diagonally at a distance of 15 meter.

Please refer to the table below for the image size projected. For further information about

image size calculator please have a look on our website: www.Liesegang.com.

„Wide“ and „Tele“ means the maximum and minimum image size diagonally at the same

distance by adjusting lens to zoom.

Projection

Distance (L=m)

Table des matières

Autres manuels Liesegang Projecteur

Liesegang

Liesegang 212 Manuel utilisateur

Liesegang

Liesegang ddv 1800 Manuel utilisateur

Liesegang

Liesegang dv 481 Manuel

Liesegang

Liesegang dv350 Manuel utilisateur

Liesegang

Liesegang ddv 2500 Manuel utilisateur

Liesegang

Liesegang ddv 2500 Manuel utilisateur

Liesegang

Liesegang dv 900 Manuel utilisateur

Liesegang

Liesegang Solid Cinema 215 Manuel utilisateur

Liesegang

Liesegang 278 Manuel utilisateur

Liesegang

Liesegang dv335 Manuel utilisateur

Liesegang

Liesegang ddv 2100 Manuel d'instructions

Liesegang

Liesegang e-motion 4100 Manuel d'instructions

Liesegang

Liesegang DV610 Manuel utilisateur

Liesegang

Liesegang ddv 3200 Manuel d'instructions

Liesegang

Liesegang ddv 2000 Manuel utilisateur

Liesegang

Liesegang Mayfair Manuel utilisateur

Liesegang

Liesegang dv445 Manuel utilisateur

Liesegang

Liesegang DV 880 Manuel utilisateur

Liesegang

Liesegang dv 420 Manuel utilisateur

Liesegang

Liesegang 251 Manuel utilisateur

Liesegang

Liesegang 266 Manuel utilisateur

Liesegang

Liesegang 294 Manuel utilisateur

Liesegang

Liesegang DV 470 Manuel utilisateur

Liesegang

Liesegang dv 465 Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur

Liesegang dv475 Manuel utilisateur

Manuels Projecteur populaires d'autres marques
