Introduction

1.0 INTRODUCTION

The Liebert OpenComms™ EM is a compact, half-duplex device designed to monitor temperature,

humidity, water detection and contact closure and notify personnel when those conditions exceed

user-defined limits.

The OpenComms EM is available in several models, which vary in size and number and types of

ports. All models have sensor ports to monitor temperature, humidity, water detection and contact

closure, and all models have either an external or built-in temperature/humidity sensor:

Sensor Ports

The OpenComms EM has sensor ports capable of monitoring temperature, humidity, water detection

and contact closure through sensors that may be purchased separately (see Table 3). The unit’s auto-

sensing capability can determine which type of sensor is connected, making the unit ready to plug

into your operation. Default settings for alarm limits may be changed through a Web interface.

Ethernet Ports

The unit has an Ethernet port for connection to a network, which provides access to the Web interface

and the capability of receiving alerts when monitored conditions reach alarm status. The

OpenComms EM may also be configured to send e-mail alerts and SNMP traps over the network.

Modem Port

A modem port provides the capability of sending pager messages to notify personnel of alarm condi-

tions in the monitored area.

Web Interface

A Web interface makes it easy to view monitoring data in tabular and graphic formats, configure the

device for alarm thresholds and set up automatic e-mail and pager notifications when a level in a

monitored area crosses a predefined threshold.

Serial Ports (EM PDU / vEM-14 Controllers)

EM PDU and vEM-14 controllers have two serial ports that are ideal for monitoring Liebert Managed

Power (MP) Advanced Power Strips. Power, voltage, current and temperature levels can be monitored

with user-configured alarm thresholds. In addition, some MP Advanced Power Strip models allow

each receptacle on the power strip to be turned on or off through the Web interface.

Typical Applications

An OpenComms EM is highly useful in monitoring:

•Enclosures, particularly those housing electronic equipment such as servers or telephone

switching equipment sensitive to temperature, humidity and power fluctuations

•Process Areas, such as areas where environmentally sensitive chemical reactions occur

•A closet or an area of a room where temperature levels are important, for example, an area

that houses many servers, where you want to verify the area or closet doesn’t get too hot

•EM

Controller

•hastwo sensor ports

•shipswithan external sensor to detect temperature only (TMNET kit) or

both temperature and humidity (THCMNET kit)

• has no serial ports

• takes up zero U rack space

•EM PDU

Controller

•hastwo sensor ports

•shipswithan external sensor to detect temperature only (TMPDUNET kit) or

both temperature and humidity (THCMPDUNET kit).

•hastwo serial ports to monitor Liebert MP Advanced Power Strips

• takes up zero U rack space

•vEM-14

Controller

•hasfour sensor ports

• has a built-in temperature and humidity sensor

•hastwo serial ports to monitor Liebert MP Advanced Power Strips

•has10 dry contact inputs

• takes up 1U rack space

Introduction

1.1 Overview

The OpenComms EM features indicator lights on the front, as shown in Figure 1.

Figure 1 Front view (EM PDU & vEM-14 controllers shown)

1.1.1 Dimensions and Mounting Overview - EM & EM PDU Controllers

• The unit is 4.75" wide, x 2.5" deep x 1.625" high (120.7 x 63.5 x 41.3mm).

• The unit may be placed on a flat surface or mounted on a wall, using mounting holes on the bot-

tom of the unit. See 2.2.1 - Mounting the Unit on a Wall (EM / EM PDU Controllers) for

more information.

1.1.2 Dimensions and Mounting Overview - vEM-14 Controllers

• The unit is 17" wide x 5" deep x 1.75" high (431.8 x 127 x 44.5mm).

• The unit may be placed in a rack-mount or desktop orientation.

Power Link Serial

ModemSerial

Sensor

A - Power and port indicators

(see Table 1)

EM PDU

CONTROLLER

vEM-14

CONTROLLER

Introduction

1.1.3 Connectors on Back of Unit

The back of the OpenComms EM, shown in Figure 2, has an input power source, sensor ports, a

modem port and an Ethernet port. The EM PDU and vEM-14 controllers have serial ports, and

vEM-14 controllers also have 10 dry contact inputs.

Figure 2 Rear view

Table 1 Description of indicators and connectors

Item Description For more information, see:

A - Power and

port indicators

Indicators on the front of the unit show the status of input power

and other connections (see Figure 1). 1.2: Indicators

B - Sensors

Sensor ports to connect compatible sensors:

• Temperature sensor

(provided with TMNET & TMPDUNET kits)

• Temperature & humidity combination sensor

(provided with THCMNET & THCMPDUNET kits)

• Humidity, water detection or dry-contact sensor

(available separately)

2.3.4: Connect Sensors

5.3: Sensors Window

C - Modem Port for connection to a modem.

• Requires RJ45 cable (customer-supplied) 2.3.3: Connect to a Modem

D - Serial

devices

Serial 1 and Serial 2 ports to connect serial devices

(EM PDU and vEM-14 controllers).

• Requires serial cable (one provided)

2.3.5: Connect Serial Devices

(EM PDU/vEM-14 Controllers)

5.4: Power Window (EM PDU &

vEM-14 Controllers)

5.7.4: Serial Ports

E - Ethernet Port for connection to an Ethernet network.

• Requires RJ45 cable (customer-supplied)

2.3.2: Connect to an Ethernet Network

5.7.1: Network Connectivity

F - Power Power connection for the OpenComms EM.

• Requires 9VDC 2.3.1: Connect Power to the Unit

G - Dry

contact inputs

10 dry contact inputs for auxiliary devices (vEM-14 controller).

• Requires Form C dry contacts

—

Sensor

1 Modem DCNEthernet

CONTROLLER

F - Power

B - Sensors C - Modem

EM PDU

CONTROLLER

Sensor

Serial

ModemDCN Ethernet

F - Power

D - Serial

devices E - Ethernet

vEM-14

CONTROLLER

F - Power

B - Sensors C - Modem D - Serial

devices E - Ethernet

G - Dry

contact

inputs

Introduction

1.2 Indicators

The front of the OpenComms EM has indicators that show input power to the unit and the status of

various connections, as shown in Figure 3 and described in Table 2.

Figure 3 Indicators on front of unit

EM CONTROLLER

EM PDU CONTROLLER

vEM-14 CONTROLLER

Table 2 Indicators summary

Indicator

Type

Indicator Label on Model:

Color DescriptionEM EM PDU vEM-14

Power Power Power On Red Power is connected and powering the OpenComms EM.

Ethernet Link Link Cx/Tx Yellow The OpenComms EM is connected to an active network.

Sensor

port

Sensor 1 Sensor 1 Sensor 1 Green A sensor is connected to the Sensor 1 port.

Sensor 2 Sensor 2 Sensor 2 Green A sensor is connected to the Sensor 2 port.

— — Sensor 3** Green A sensor is connected to the Sensor 3 port.

— — Sensor 4** Green A sensor is connected to the Sensor 4 port.

Serial

port*

— Serial 1 Serial 1 Green A device is connected to the Serial 1 port.

— Serial 2 Serial 2 Green A device is connected to the Serial 2 port.

Modem Activity Modem Mdm Green A modem is connected.

* EM PDU and vEM-14 controllers

** vEM-14 controllers

Power Link Activity Sensor

Sensor

Power Link Serial

ModemSerial

Sensor

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Liebert Instrument de mesure

Liebert

Liebert Liqui-tect MC68HC16Z1 Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
