LG 32LM561CBTC Manuel utilisateur

1. Model Name: 32LM561CBTC

2. Sux: TR

3. Part No: MFL71833948

4. REV REV00

5. Number of pages 8

6. Folded/Unfolded 2 Folded

7. Trim size (W x H)_Unfolded (mm) 420 x 296 (+/- 5)

8. Trim size (W x H)_folded (mm) 210 x 148

9. Bindery -

10. Color (Cover) -

11. Paper (Cover) -

12. Weight (cover) (g/㎡) -

13. Color (inner) 1

14. Paper (inner) Wood free

15. Weight (inner) (g/㎡) 70 (+/- 10)

16. Coating No

17. Thomson No

18. Sub-material No

[Country Name]

LGERS/ LGEMX : Mexico

LGEKR: Korea

Changes the Country name. LGEMA: Poland

Printed in [Country Name] LGEIL: India

Others: Each Country name.

[Restriction of Hazardous Substances ]

Hazardous substances on this product should be satised by substance regulation of Level A-I, A-II, SVHC according to LG(52)B5011 standard.

(1) Hazardous substances test report should be submitted when part certication test and rst mass production.

(2) Especially, Don’t use or contain lead (Pb) and cadmium (Cd) in ink.

REV07

REV06

REV05

REV04

REV03

REV02

REV01

Checked Aditya.K

Approved Nitin.H

Rev. Number Date ECO Number Owner Aditya.K

COVER

INNER

3 . Hist ory

Description

NOTE Especially, Part should be followed and controlled the following specication.

05/04/2022

Printing Specication

1 . Specif ication 1 .1 Folding / Cover

Models

SIZE

REV00

2 . Or igin N ot ificat ion

ENG

19. Languages

Front

Folded Step

Back

Folded

296 mm

Barcode

420 mm

296 mm

420 mm

148 mm

210 mm

Front Folded Barcode

(2207-REV00)

LM56*

Head

washer

Head

washer

Head

washer

Head

washer

x 2

(M4 x L16)

AAA

Head

washer

: fWARNING To prevent injury, this apparatus must be securely attached to the desk/wall in accordance with theSafety and Re erence.

*M F L 7 1 8 3 3 9 4 8*

Unpacking

Check your product box for the following items. If there are

any missing accessories, contact the local dealer where you

purchased your product. The illustrations in this manual may

differ from the actual product and item.

Images shown in manual may vary depending on model

Quick Start Guide

: Depending on country

Depending on model

RVIDEO/Y P

L/MONO AUDIO

VIDEO AUDIO

RVIDEO/Y P

L/MONO AUDIO

VIDEO L/MONO AUDIOR

AB C D E F F G

32LM561CBTC 739 472 168 441 84 4.90 4.85

AC 100-240 V~ 50/60 Hz

VIDEO/Y P

L/MONO AUDIO

VIDEO AUDIO

VIDEO/Y P

L/MONO AUDIO

VIDEO L/MONO AUDIOR

90°

Head

washer

Do not look into the optical

output ports, looking at the

laser beam may damage

your vision

Audio with ACP (Audio Copy

Protection)function may

block digital audio output.

Some USB Hubs may not

work, if a USB device con-

nected using a USB Hub is

not detected, connect it to

the USB port on the TV

directly

Connect the external power

source if your USB is needed.

An external audio device that supports SIMPLINK and ARC

must be connected using HDMI IN eARC/ARC port

When connected with a high-speed HDMI cable, the

external audio device that supports ARC outputs SPDIF

audio without additional audio cable and supports the

SIMPLINK function

ARC (Audio Return Channel)

Image shown may vary

depending on model .

All connection cables &

devices shown in the

picture are not included

along with the product.
