LG M2362DP-EM Manuel utilisateur

Make sure to read the Safety Precautions before

using the product.

Keep the User's Guide(CD) in an accessib e p ace

for furture reference.

See the abe attached on the product and give the

information to your dea er when you ask for service.

OWNER’S MANUAL

MM22226622DD

MM22336622DD

MM22776622DD

PREPARATION

FRONT PANEL CONTROLS

■

This is a simp ified representation of the front pane . The image shown may be somewhat different from your

set.

INPUT

Button

INPUT

VOL

ENTER

Button

ENTER

Button

VOLUME

Buttons

CHANNEL

Buttons

Power

Button

Headphone

Jack

IR receiver

(Remote contro er

receiver)

LLiigghhtt SSeennssoorr

This is ens for ight sensor

se ect outside uminance,

when setting AUTO

BRIGHT ON.

PPoowweerr IInnddiiccaattoorr

i uminates b ue when the

set is switched on.

Note:You can adjust

Power indicator in the

OPTION menu.

PREPARATION

BACK PANEL INFORMATION

■

This is a simp ified representation of the back pane . The image shown may be somewhat different from your

set.

AV 1 AV 2

AC IN

VIDEO

COMPONENT

AV-IN

VIDEO

S-VIDEO

AUDIO

RS-232C IN

(CONTROL & SERVICE)

SERVICE

ONLY

RGB IN (PC)

DVI-D IN (PC)

HDMI IN

OPTICAL

DIGITAL

AUDIO OUT

AC IN

AUDIO IN

(RGB/DVI)

ANTENNA/

CABLE IN

AUDIO

(MONO)

910 11

87 12

3 4

Power Cord Socket

This set operates on AC power. The vo tage is indicated

on the Specifications page. Never attempt to operate

the set on DC power.

HDMI Input

High definition inputs. These two inputs accept TV

Video, not PC Video. They a so accept TV Video from a

DVI connection when using an adapter. The HDMI

inputs support video and audio. When using an adapter

for DVI, they on y accept video.

DVI-D Input

Digita PC input.

RS-232C IN (CONTROL & SERVICE) PORT

Seria port used for externa contro or service.

RGB INPUT (PC)

Ana og PC input. A so known as VGA.

S-Video Input

Standard definition (480i), but better qua ity than

standard A/V input.

SERVICE ONLY PORT

RGB/DVI Audio Input

This is the audio input for the RGB and DVI-D video

inputs.

Optica Digita Audio Out

Use this to export audio to an externa amp ifer.

Component Input

High definition ana og input.

Audio/Video Input

Standard definition input.

Antenna Input

Connect over-the-air or cab e signa s to this jack.

PREPARATION

STAND INSTALLATION

■

The image shown may be somewhat different from your set.

Carefu y p ace the product screen side down on a

cushioned surface that wi protect product and

screen from damage.

Insert the ssttaanndd bbaasseeinto the product

Turn the Stand Base Lock through 90°to fix the Stand Base to the Stand Body.

BBaassee LLoocckk

<<LLoocckkeedd>>

4 5

<<MM22226622DD//MM22336622DD>>

PREPARATION

STAND INSTALLATION

■

The image shown may be somewhat different from your set.

Carefu y p ace the product screen side down on a

cushioned surface that wi protect product and

screen from damage.

Insert the ssttaanndd bbaasseeinto the product

Attach the monitor to the Stand Base by turning the screw to the right.

*Turn the screw by using the screw hand e

<<MM22776622DD>>

PREPARATION

DETACHING STAND

■

The image shown may be somewhat different from your monitor.

P ace the set screen side down on a cushion or

soft c oth.

Detach the monitor to the Stand Base by turn-

ing the screw to the eft.

Turn the Stand Base Lock through 90°to separate the Stand Base from the Stand Body.

Pushing Latch inside, Take the stand base from stand body.

LLaattcchh

<<MM22226622DD//MM22336622DD>>

PREPARATION

DETACHING STAND

■

The image shown may be somewhat different from your monitor.

P ace the set screen side down on a cushion or

soft c oth.

Detach the monitor to the Stand Base by

turning the screw to the eft.

Turn the screw by using the screw hand e. 4Pu the stand base.

<<MM22776622DD>>

PREPARATION

<<MM22776622DD>>

DETACHING STAND BODY

1. Remove the screw 4 point.

2. Pu the stand body.

1. Remove the screw 2 point.

2. Pu the stand body.

■

The image shown may be somewhat different from your set.

■

Remove the Stand Body in the same way as the fo owing when using it as a Wa Hook.

<<MM22226622DD//MM22336622DD>>

PREPARATION

DESKTOP PEDESTAL INSTALLATION

For proper venti ation, a ow a c earance of 4 inches on each side and from the wa .

WALL MOUNT: HORIZONTAL INSTALLATION

For proper venti ation, a ow a c earance of 4 inches on each side and from the wa . Fo ow the instructions

inc uded with the wa mount.

4 inches

4 inches 4 inches

4 inches

PREPARATION

POSITIONING YOUR DISPLAY

■

The image shown may be somewhat different from your set.

Adjust the position of the pane in various ways for maximum comfort.

•• TTiitt rraannggee

LOCATION

Position your set so that no bright ight or sun ight fa s direct y onto the screen. Care shou d be taken not to expose

the set to any unnecessary vibration, moisture, dust or heat. A so, ensure that the set is p aced in a position to a ow a

free f ow of air. Do not cover the venti ation openings on the back cover.

If you intend to mount the set to a wa , attach the wa mounting interface (optiona parts) to the back of the set.

When you insta the set using the wa mounting interface (optiona parts), attach it carefu y so it wi not drop.

- Be sure to use screws and a wa mount that meet VESA standards.

- Using screws onger than those recommended might damage the product.

- Using screws that do not meet VESA standards might either damage the product or resu t in it coming away from the

wa . We wi not be he d responsib e for any damage resu ting from fai ure to fo ow these instructions.

< Screw Mounting Interface Dimension >

MM22226622DD//MM22336622DD: 100mm x 100mm ho e spacing

MM22776622DD : 200mm x 100mm ho e spacing

* Wa mount interface(LG) : RW120

WWaarrnniinngg::

When adjusting the ang e of the

screen, do not put your finger(s)in

between the head of the monitor

and the stand body. You can hurt

your finger(s).

RW120

-5
