OWNER’S MANUAL

CINEMA 3D MONITOR

Please read this manual carefully before operating

your set and retain it for future reference.

CINEMA 3D MONITOR MODEL

ENG

ENGLISH

TABLE OF CONTENTS

CONTENTS

3 ASSEMBLINGANDPREPAR-

ING

3 Unpacking

4 Partsandbuttons

5 SettinguptheMonitorset

5 - AttachingtheStandBase

6 - DetachingtheStandBase

7 - Mountingonatable

7 - Usingthecableholder

9 USINGTHEMONITORSET

9 ConnectingtoaPC

9 - D-SUBconnection

9 - DVI-Dconnection

9 - HDMIconnection

11 CUSTOMIZINGSETTINGS

12 CustomizingSettings

12 - MenuSettings

13 -PICTURE

14 -COLOR

15 -DISPLAY

15 -VOLUME

16 -OTHERS

17 -FUNC.Settings

17 -3DSETTINGS

18 -SettingDualPlay

19 -PICTUREMODE

20 -SUPER+RESOLUTION

21 -SUPERENERGYSAVING

22 TROUBLESHOOTING

24 TROUBLESHOOTINGWHEN

USING3DMODE

25 D2792P

26 PresetModes(Resolution)

27 Indicator

28 SAFETYPRECAUTIONS

28 - Precautionstotakewhenviewing3D

images

28 - Whenusing3DGlasses

29 PROPERPOSTURE

29 ProperpostureforusingtheMonitorset.

29 Precautionstotakewhenviewing3Dim-

ages

ENG

ENGLISH

ASSEMBLING AND PREPARING

ASSEMBLINGANDPREPARING

Unpacking

Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal

dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct

andaccessories.

 Donotuseanyunapprovedaccessoriestoensurethesafetyandproductlifespan.

 Anydamagesorinjuriesbyusingunapprovedaccessoriesarenotcoveredbythewarranty.

 Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.

 Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade

ofproductfunctions.

CAUTION

NOTE

StandBase

CD(Owner'sManual)/

Card D-SUBCable

DVI-DCable

(Thiscableisnotincluded

inallcountries.)

(Dependingonthecountry) (Dependingonthecountry)

PowerCord AC-DCAdapter AC-DCAdapter

or

TwoScrews

Thenumberandtypeof3Dglassesmaydifferdependingonthemodelofcountry.

or

3DGlasses

(Normaltype)

3DGlasses

(Normaltype)

3DGlasses

(Normaltype)

3DGlasses

(Clip-ontype)

ENG

ENGLISH

ASSEMBLING AND PREPARING

Partsandbuttons

PowerIndicator

 LightingOn:Turnedon

 LightingOff:Turnedoff

Connectionpanel(Seep.9)

Button(Seep.11)

(PowerButton)

ENG

ENGLISH

ASSEMBLING AND PREPARING

UsethreescrewstofixtheStandBodyand

monitorset.

SettinguptheMonitorset

AttachingtheStandBase

1 PlacetheMonitorsetwiththescreenside

downonaflatandcushionedsurface.

Layafoammatorsoftprotectiveclothonthe

surfacetoprotectthescreenfromdamage.

Tightenthescrewsfirmlytopreventthe

monitorfromtiltingforward.Donotover

tighten.

CAUTION

2

Ifyoudon`tfastenthescrewtightly,monitor

willfalldownandgetdamaged.

WARNING

ENG

ENGLISH

ASSEMBLING AND PREPARING

 Thisillustrationdepictsthegeneralmodelof

connection.Yourmonitormaydifferfromthe

itemsshowninthepicture.

 Donotcarrytheproductupsidedownholding

onlythestandbase.Theproductmayfall

andgetdamagedorinjureyourfoot.

CAUTION

DetachingtheStandBase

1 PlacetheMonitorsetwiththescreenside

downonaflatandcushionedsurface.

2 Removethreescrewsandpulloutthe

StandBodyfromthemonitorset.

ENG

ENGLISH

ASSEMBLING AND PREPARING

Mountingonatable

1 LiftandtilttheMonitorsetintoitsupright

positiononatable.

Leavea10cm(minimum)spacefromthewall

forproperventilation.

Usingthecableholder

2 ConnecttheAC-DCAdapterandPowerCord

toawalloutlet.

3 Press (Power)buttononthebottomswitch

paneltoturnthepoweron.

10 cm

Unplugthepowercordbeforemovingthe

Monitortoanotherlocation.Otherwiseelectric

shockmayoccur.

CAUTION

ENG

ENGLISH

ASSEMBLING AND PREPARING

UsingtheKensingtonsecuritysystem

TheKensingtonsecuritysystemconnectoris

locatedatthebackoftheMonitorset.Formore

informationofinstallationandusing,refertothe

manualsuppliedwiththeKensingtonsecurity

systemorvisit

http://www.kensington.com

ConnecttheKensingtonsecuritysystemcable

betweentheMonitorsetandatable.

TheKensingtonsecuritysystemisoptional.

Youcanobtainitfrommostelectronicsstores.

NOTE

Whenyouadjusttheangle,donotholdthe

bottomoftheMonitorsetframeasshownon

thefollowingillustration,asmayinjureyour

fingers.

Donottouchorpressthescreenwhen

adjustingtheangleofthemonitor.

Donotholdthissetlikebelowpicture.Monitor

screencandetachfromstandbaseandinjure

yourbody.

WARNING

Tiltfrom+20to-5degreesupordowntoadjust

theangleoftheMonitorsettosuityourview.

NOTE

Front Rear

ENG

ENGLISH

USING THE MONITOR SET

USINGTHEMONITORSET

ConnectingtoaPC

 YourMonitorsetsupportsPlug&Play*.

*Plug&Play:APCrecognizesaconnected

devicethatusersconnecttoaPCandturn

on,withoutdeviceconfigurationoruser

intervention.

D-SUBconnection

TransmitsanalogvideofromyourPCtothe

Monitorset.ConnectthePCandtheMonitorset

withthesuppliedD-sub15pinsignalcableas

showninthefollowingillustrations.

 Macadapter

ForAppleMacintoshuse,aseparateplug

adapterisneededtochangethe15pin

highdensity(3row)D-SUBVGAconnector

onthesuppliedcabletoa15pin2row

connector.

 WhenusingaD-Subsignalinputcable

connectorforMacintosh

 IfyouuseHDMIPC,itcancausecompatibility

problem.

NOTE

DVI-Dconnection

TransmitsadigitalvideosignalfromyourPCto

theMonitorset.ConnectthePCandtheMonitor

setwithaDVIcableasshowninthefollowing

illustrations.

HDMIconnection

Transmitsthedigitalvideoandaudiosignalsfrom

yourPCorA/VtotheMonitorset.ConnectthePC

orA/VandtheMonitorsetwiththeHDMIcableas

showninthefollowingillustrations.

ENG

ENGLISH

USING THE MONITOR SET

 WhenyouwanttousetwoPCinourMonitor,

pleaseconnectthesignalcable(D-SUB/

DVI-D/HDMI)respectivelyinMonitorset.

 IfyouturntheMonitorsetonwhileitiscold,

thescreenmayflicker.Thisisnormal.

 Somered,green,orbluespotsmayappear

onthescreen.Thisisnormal.

 "SelfImageSetting"Function.

Thisfunctionprovidestheuserwithoptimal

displaysettings.Whentheuserconnects

themonitorforthefirsttime,thisfunction

automaticallyadjuststhedisplaytooptimal

settingsforindividualinputsignals.(Only

supportedinAnalogMode)

 ‘AUTO’Function.

Whenyouencounterproblemssuchas

blurryscreen,blurredletters,screenflicker

ortiltedscreenwhileusingthedeviceor

afterchangingscreenresolution,pressthe

AUTOfunctionbuttontoimproveresolution.

(OnlysupportedinAnalogMode)

NOTE NOTE

 Connectthesignal

inputcableandtighten

itbyturningthescrews

clockwise.

 Donotpressthescreenwithyourfingerfor

alongtimeasthismayresultintemporary

distortiononthescreen.

 Avoiddisplayingafixedimageonthe

screenforalongperiodoftimetoprevent

imageburn.Useascreensaverifpossible.

CAUTION SelfImageSettingFunction

Pressthepowerbuttononthebottompanelto

turnthepoweron.Whenmonitorpoweristurned

on,the"SelfImageSetting"Functionisexecuted

automatically.(OnlysupportedinAnalogMode)
