www.lg.com

OWNER’S MANUAL

MONITOR SIGNAGE

55WV70MS

55WV70BS

Please read this manual carefully before operating the your set and

retain it for future reference.

MONITOR SIGNAGE MODELS

ENG

ENGLISH

ENG

ENGLISH

TABLE OF CONTENTS

CONTENTS

4 LICENSES

5 ASSEMBLING AND

PREPARING

5 Accessories

6 Parts

7 ToinstallinaPortraitLayout

7 RemoveL-bracketsbeforeInstallation

8 STORAGEMETHODFORPANEL

PROTECTION

8 - CorrectMethod

8 - IncorrectMethod

9 Installingonawall

10 EXTERNALEQUIPMENTSETUP

10 - IRRECEIVER

11 TilingDisplays

11 - HowtoMounttheSet

12 - HowtoJoinSets

13 REMOTE CONTROL

15 Displayingthedevicenameconnectedto

aninputport

16 USING THE MONITOR SET

16 ConnectingtoaPC

16 - RGBconnection

17 - DVIconnection

17 - HDMIconnection

18 - DPconnection

18 - IRReceiverconnection

19 Adjustingthescreen

19 - Selectinganimagemode

19 - Customizingimageoptions

20 - CustomizingPCdisplayoptions

20 Adjustingthesound

20 - Selectingansoundmode

21 - Customizingsoundoptions

21 Usingadditionaloptions

21 - Adjustingaspectratio

23 - Usingtheinputlist

24 ENTERTAINMENT

24 - Connectingtoawirednetwork

25 - NetworkStatus

26 - ConnectingUSBstoragedevices

27 - Browsingfiles

29 - Viewingmovies

32 - Viewingphotos

35 - Listeningtomusic

37 - ViewingtheContentsList

38 - DivX®VODGuide

39 - UsingPIP/PBP

40 CUSTOMIZING SETTINGS

40 Accessingmainmenus

41 - PICTUREsettings

44 - AUDIOsettings

45 - TIMEsettings

46 - OPTIONsettings

51 PictureID

52 - NETWORKsettings

53 MAKING CONNECTIONS

54 ConnectingtoaHDreceiver,DVD,

Camcorder,Camera,GamingDeviceor

VCRplayer

54 - DVIconnection

54 - HDMIconnection

55 - Componentconnection

55 - AV(COMPOSITE,CVBS)connection

56 ConnectingtotheLAN

56 - LANconnection

56 ConnectingtoaUSB

57 DaisyChainMonitors

ENGLISH

LICENSES

57 - RGBCable

57 - DVICable

58 TROUBLESHOOTING

61 SPECIFICATIONS

63 IR CODES

64 CONTROLLING THE MULTIPLE

PRODUCT

64 Connectingthecable

64 RS-232CConfigurations

64 CommunicationParameter

65 Commandreferencelist

67 Transmission/Receivingprotocol

ENGLISH

4LICENSES

LICENSES

Supportedlicensesmaydifferbymodel.Formoreinformationofthelicenses,visitwww.lg.com.

HDMI,theHDMIlogoandHigh-DefinitionMultimediaInterfacearetrademarks

orregisteredtrademarksofHDMILicensingLLC.

ABOUTDIVXVIDEO:DivX isadigitalvideoformatcreatedbyDivX,LLC,a

subsidiaryofRoviCorporation.ThisisanofficialDivXCertified devicethat

playsDivXvideo.Visitdivx.comformoreinformationandsoftwaretoolsto

convertyourfilesintoDivXvideos.

ABOUTDIVXVIDEO-ON-DEMAND:ThisDivX

Certified devicemustberegisteredinordertoplaypurchasedDivXVideo-

on-Demand(VOD)movies.Toobtainyourregistrationcode,locatethe

DivXVODsectioninyourdevicesetupmenu.Gotovod.divx.comformore

informationonhowtocompleteyourregistration.

DivXCertified toplayDivX videouptoHD1080p,includingpremium

content.

DivX ,DivXCertified andassociatedlogosaretrademarksofRovi

Corporationoritssubsidiariesandareusedunderlicense.

CoveredbyoneormoreofthefollowingU.S.patents:7,295,673;7,460,668;

7,515,710;7,519,274

ManufacturedunderlicensefromDolbyLaboratories.“Dolby”andthe

double-DsymbolaretrademarksofDolbyLaboratories.

ENG

ENGLISH

ASSEMBLING AND PREPARING

 Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.

 Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade

ofproductfunctions.

 How to Use a Ring Core

AringcorereduceselectromagneticwavesemittedfromtheIRreceiver.

Loopthecablethroughthecoreonce,beforeusingitasillustrated.

ASSEMBLING AND PREPARING

Accessories

Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal

dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct

andaccessories.

INPUT

ENERGY

SAVING

MARK

ARC

OFF



. , !



ABC



DEF



GHI



JKL



MNO



PQRS



TUV



1/a/A



- * #

WXYZ

CLEAR

MONITOR

PSM

AUTO

MUTE

BRIGHT

NESS

POWER

S.MENU

BACK TILE

ON OFF

EXIT

Remote control and Batteries

Power Cord DVI Cable

IR Receiver

M4 x 6L

Screw (4ea)

Screw (4ea) Ring Core

CD (Owner's Manual, SuperSign

Elite-w Program/SuperSign

Manual) / Card

RGB Cable

RS-232C Cable Tiling Guide

(2ea)

 Donotuseanypirateditemstoensurethesafetyandproductlifespan.

 Anydamagesorinjuriesbyusingpirateditemsarenotcoveredbythewarranty.

CAUTION

NOTE

RingCore

ENG

ENGLISH

ASSEMBLING AND PREPARING

Parts

USB DP LAN

COMPOSITE

DVI IN DVI OUT

/DVI SPEAKER

RGB

/COMPONENT OUT

RGB

/COMPONENT IN

AUDIO

REMOTE

CONTROL IN

Connection panel (Seep.54top.56)

ENG

ENGLISH

ASSEMBLING AND PREPARING

To install in a Portrait Layout

WheninstallinginaPortraitLayout,rotatethemonitorclockwise90degrees(whenfacingthescreen).

Remove L-brackets before Installation

RemovetheL-bracketsfromeachcornerofthemonitorbeforeinstallingit.

KeeptheremovedL-bracketsandusethemwhenmovingthemonitorlater.

NOTE

ENG

ENGLISH

ASSEMBLING AND PREPARING

Correct Method Incorrect Method

STORAGE METHOD FOR PANEL PROTECTION

Panel

Cushion

Iftheproductneedstobesetupright,holdboth

sidesoftheproduct,andtiltbackwardcarefully

for.Donotletthepanelnottotouchthefloor.

Whenlayingdowntheproduct,layacushionona

flatfloor.Puttheproductonitwiththepanelof

theproductfacingdown.

Ifthereisnotacushionavailable,ensuretheflooris

cleanandthenlaytheproductdowncarefullywiththe

panelfacingeitherupwardordownward.

Atthistime,

becarefulforobjectsnottofallonthepanel.

Panel

Iftheproductistiltedontothebezel,thebottomof

thepanelmaybedamaged.

Iftheproductistiltedontotheedgeofthe panel,

thepanelmaybedamaged.

ENG

ENGLISH

ASSEMBLING AND PREPARING

 Disconnectthepowercordfirst,andthen

moveorinstalltheMonitorset.Otherwise

electricshockmayoccur.

 IfyouinstalltheMonitorsetonaceilingor

slantedwall,itmayfallandresultinsevere

injury.

 Donotovertightenthescrewsasthismay

causedamagetotheMonitorsetandvoid

yourwarranty.

 Usethescrewsandwallmountsthat

meettheVESAstandard.Anydamages

orinjuriesbymisuseorusinganimproper

accessoryarenotcoveredbythewarranty.

CAUTION

NOTE

Donotinstalltheproductinaplacewith

noventilation(e.g.,onabookshelforina

closet)oronacarpetorcushion.Ifthereis

nootheroptionbuttomounttheproducton

thewall,makesurethatsufcientventilation

isprovidedbeforeinstallation.

-Failuretodosomayresultinaredueto

theincreaseintheinternaltemperature.

Installthemonitoratleast10cmawayfromthe

wallandleaveabout10cmofspaceateachside

ofthemonitortoensuresufficientventilation.

Usethewallmountplateandscrewsthatcomply

withtheVESAstandard.

Installing on a wall

To install the Monitor on a wall (optional),

usetheVESAscrewsprovidedasaccessoriesto

fastenit.

Pleaserefertop11onHowtoMounttheSet.

10cm

10cm 10cm

20cm

ENG

ENGLISH

ASSEMBLING AND PREPARING

EXTERNAL EQUIPMENT SETUP

IR RECEIVER

Thisallowsaremotecontrolsensortobeplaced

inacustomlocation.Thenthatdisplaycancontrol

otherdisplaysviaanRS-232cable.

AUDIO

REMOTE

CONTROL IN
