LG M2794DJ Manuel utilisateur

Order Number : GETEC-C1-09-100 FCC Class B Certification

Test Report Number : GETEC-E3-09-048 Page 1 / 1

EUT Type: LCD TV/Monitor

FCC ID.: BEJM2794DJ

APPENDIX H

: USER’S MANUAL

Make sure to read the Safety Precautions before

using the product.

Keep the User's Guide(CD) in an accessib e p ace

for furture reference.

See the abe attached on the product and give the

information to your dea er when you ask for service.

OWNER’S MANUAL

MM22779944DD

PREPARATION

FRONT PANEL CONTROLS

■

This is a simp ified representation of the front pane . The image shown may be somewhat different from your

set.

INPUT MENU VOL CHENTER

CHANNEL

Buttons

VOLUME

Buttons

Button

ENTER

Button

INPUT

Button

Power

Button

Headphone

Output

PREPARATION

BACK PANEL INFORMATION

■

This is a simp ified representation of the back pane . The image shown may be somewhat different from your

set.

AC IN

AUDIO IN

(RGB/DVI) OPTICAL

DIGITAL

AUDIO OUT

VIDEO

COMPONENT

AV-IN

VIDEO

S-VIDEO

AUDIO

RS-232C IN

(CONTROL & SERVICE)

SERVICE

ONLY

RGB IN (PC)

DVI-D IN (PC)

HDMI IN

AC IN

ANTENNA/

CABLE IN

AUDIO

(MONO)

910 11

87 1

3 4

Power Cord Socket

This set operates on AC power. The voltage is indicat-

ed on the Specifications page. Never attempt to

operate the set on DC power.

HDMI Input

High definition inputs. These two inputs accept TV

Video, not PC Video. They also accept TV Video from

a DVI connection when using an adapter. The HDMI

inputs support video and audio. When using an

adapter for DVI, they only accept video.

RGB/DVI Audio Input

This is the audio input for the RGB and DVI-D video

inputs.

Optical Digital Audio Out

Use this to export audio to an external amplifer.

RGB INPUT (PC)

Analog PC input. Also known as VGA.

S-Video Input

Standard definition (480i), but better quality than

standard A/V input.

SERVICE ONLY PORT

DVI-D Input

Digital PC input.

RS- 3 C IN (CONTROL & SERVICE) PORT

Serial port used for external control or service.

Component Input

High definition analog input.

Audio/Video Input

Standard definition input.

Antenna Input

Connect over-the-air or cable signals to this jack.

PREPARATION

STAND INSTALLATION

■

The image shown may be somewhat different from your set.

Carefu y p ace the product screen side down on a

cushioned surface that wi protect product and

screen from damage.

Insert the ssttaanndd bbaasseeinto the product

Attach the monitor to the Stand Base by turning

the screw to the right.

* Turn the screw by using the screw hand e

Screw

PREPARATION

DETACHING STAND

P ace the set screen side down on a cushion or

soft c oth.

Detach the monitor from the Stand Base by

turning the screw to the eft.

Turn the screw by using the screw hand e 4

Pu the stand base.

■

The image shown may be somewhat different from your monitor.

PREPARATION

DESKTOP PEDESTAL INSTALLATION

For proper ventilation, allow a clearance of 4 inches on each side and from the wall.

WALL MOUNT: HORIZONTAL INSTALLATION

For proper ventilation, allow a clearance of 4 inches on each side and from the wall. Follow the instructions

included with the wall mount.

4 inches

4 inches 4 inches

4 inches

PREPARATION

■For optimum picture qua ity, adjust antenna direction.

■An antenna cab e and converter are not supp ied.

■To prevent equipment damage, never p ug in any power cords unti you have finished connecting a equipment.

Multi-family D ellings/Apartments

(Connect to all antenna socket)

Single-family D ellings /Houses

(Connect to all jack for outdoor antenna)

Outdoor

Antenna

(VHF, UHF)

Wall

Antenna

Socket

RF Coaxial Wire (75 ohm)

ANTENNA CONNECTION

Antenna

UHF

VHF

■In poor signa areas, to get better picture qua ity, insta a signa amp ifier to the antenna as shown above.

■If signa needs to be sp it for two TVs, use an antenna signa sp itter for connection.

AC IN

ANTENNA/

CABLE IN

AC IN

ANTENNA/

CABLE IN

Signal

Amplifier

EXTERNAL EQUIPMENT SETUP

Connect the SET-TOP outputs to the CCOOMMPPOONNEENNTT IINN

VVIIDDEEOOsockets (YP

BPR) on the set.

Connect the audio cab e from the SET-TOP to CCOOMMPPOO--

NNEENNTT IINNAAUUDDIIOOsockets of the set.

Press the IINNPPUUTTbutton to se ect Component.

HD RECEIVER SETUP

■To prevent the equipment damage, never plug in any power cords until you have finished connecting all equipment.

■

The image shown may be somewhat different from your set.

When connecting ith a component cable

Signa

480i

480p

576p

720p/1080i

1080p

Component

Yes

HDMI

Yes

VIDEO

COMPONENT

AUDIO

EXTERNAL EQUIPMENT SETUP

When connecting ith a HDMI

Connect the HDMI output of the digita set-top box to the

HHDDMMII IINNjack on the set.

Connect the digita set-top box to HHDDMMII IINN jack on

the set.

Connect the audio output of the digita set-top box to

the AAUUDDIIOO IINN ((RRGGBB//DDVVII)) jack on the set.

Turn on the digita set-top box. (Refer to the owner’s

manua for the digita set-top box.)

When connecting ith a HDMI to DVI cable

HDMI IN

DVI OUTPUT

AUDIO

AUDIO IN

(RGB/DVI)

HDMI IN

NOTE

GGHDMI Input does not support PC mode. If it is connected PC, the screen may not disp ay proper y.
