LG 47WV30-BAAM Guide de démarrage rapide

1. Model Description

MODEL BRAND

Printing Specification

Part No.

Easy Setup Guide Specification

Changes

REV.

NO. MM/DD/YY SIGNATURE CHANGE NO. CHANGE CONTENTS

SUFFIX

Special Instructions3.

Product Name Signage

담 당 관리자

47WV30-BAAMLG MFL67420101

(1107-REV00)

(1) Origin Notification

* LGEIN : Printed in Indonesia * LGEWA : Printed in U.K * LGEMA : Printed in Poland

* LGESP : Printed in Brazil * LGEMX : Printed in Mexico

* LGEND : Printed in China * LGEIL : Printed in India

World Wide

* This part contain Eco-hazardous substances (Pb, Cd, Hg, Cr6+, PBB, PBDE, etc.) within LG

standard level, Details should be followed Eco-SCM management standard[LG(56)-A-2524].

Especially, Part should be followed and controlled the following specification.

(1) Eco-hazardous substances test report should be submitted

when Part certification test and First Mass Production.

(2) Especially, Don’t use or contain lead(Pb) and cadmium(Cd) in ink.

H.J LEE

11.07.22

SG KIM

11.07.22

JO KIM

11.07.22

1. Trim Size (Format) : 172 mm x 243 mm

2. Printing Colors

Cover : 1 COLOR (BLACK)

Inside : 1 COLOR (BLACK)

3. Stock (Paper)

Cover : Coated paper, Snow White 150 g/㎡

Inside : Uncoated paper, 백상지 60 g/㎡

4. Printing Method : Off-set

5. Bindery : Perfect bind

6. Language : English/Czech/Spanish/French/German/Greek/Italian/Polish/Slovak/Portuguese (10)

7. Number of pages : 200 pages (Including blank 10 pages)

Pagination sheet

Front cover

218

English

ESPAÑOL

ČESKY

FRANÇAIS

ΕΛΛΗΝΙΚΑ

DEUTSCH

…Blank

POLSKI

ITALIANO

218

…Blank

218

…Blank

218

…Blank

218

…Blank

218

…Blank

218

…Blank

218

…Blank

Total pages : 200 pages

Pagination sheet

Pagination sheet Total pages :200 pages

Back cover

SLOVENČINA

PORTUGUÊS

218

…Blank

218

…Blank

www.lg.com

Easy Setup Guide

SIGNAGE DISPLAY

47WV30

Please read this manual carefully before operating the your set and

retain it for future reference.

SIGNAGE DISPLAY MODELS

ENG

ENGLISH

P/NO : MFL67420101 (1107-REV00)

Printed in Korea

ENG

ENGLISH

ASSEMBLING AND PREPARING

Unpacking

Check your product box for the following items. If there are any missing accessories, contact the local

dealer where you purchased your product. The illustrations in this manual may differ from the actual product

and accessories.

 Do not use any pirated items to ensure the safety and product life span.

 Any damages or injuries by using pirated items are not covered by the warranty.

 The accessories supplied with your product may vary depending on the model.

 Product specifications or contents in this manual may be changed without prior notice due to upgrade

of product functions.

CAUTION

NOTE

INPUT

ENERGY

SAVING

MARK

ARC

OFF



. , !



ABC



DEF



GHI



JKL



MNO



PQRS



TUV



1/a/A



- * #

WXYZ

CLEAR

MONITOR

PSM

AUTO

MUTE

BRIGHT

NESS

POWER

S.MENU

BACK TILE

ON OFF

EXIT

Remote control and Batteries

Power Cord DVI Cable

IR Receiver Guide bracket

M4 x 10L

Screw (4ea)

Power cable holder U-shaped fixture

Screw (4ea)

Ring Core

Cable holder

(2ea)

CD (Owner's Manual) /

Card

RGB Cable

ENG

ENGLISH

ASSEMBLING AND PREPARING

Dimensions (Width x Height x Depth) / Weight

To view the User’s guide

“Insert CD ROM” in Computer

CD-ROM will open automatically.(for Window only)

My computer ➙Digital_LG(CD-ROM) ➙Index.htm Open

My computer ➙Digital_LG(CD-ROM) ➙Manual folder ➙User's Guide Open

1047 mm x 592 mm x 91.1 mm / 29 kg

ENG

ENGLISH

ASSEMBLING AND PREPARING

Remove L-brackets before

Installation

Remove the L-brackets from each corner of the

monitor before installing it.

Keep the removed L-brackets and use them

when moving the monitor later.

NOTE

How to Join Sets - Installing Set 1

Tiling Displays

*Example of 2 x 2 tiling

 The numbers assigned in this example (#1,

#2, #3, #4) are used to demonstrate the

installation procedure to ensure it is easy to

follow. These numbers have nothing to do

with the Set ID that is used to operate the

remote control.

 Set the guide bracket into the bracket groove

using screws and mount the set to the wall

mount plate or the wall.

 The wall mount plate is shaded in gray in the

illustration to help you see it.

Guide bracket

Screws for ﬁxing the

VESA wall mount

Wall mount plate

Screws for fixing the

guide bracket

Guide bracket

Wall mount plate

 When you connect Monitor sets for

multivision, you may find that the screen

color is not the same across all the Monitor

sets. If you want to adjust the screen color

manually, please refer to the Installation

Manual.

 When you install multiple Monitor sets onto

a wall, attach the IR Receiver to all the

sets, or use an RS-232C cable to connect

them and then attach the IR Receiver to the

first set.

CAUTION

ENG

ENGLISH

ASSEMBLING AND PREPARING

<The sets joined with the guide

brackets>

<The sets after removing the guide

brackets>

<Removing the guide bracket through

the side gap>

How to Join Sets - Installing Set 2 How to remove the guide brackets

 Unscrew the guide bracket screws from

the rear of the set and remove the guide

brackets.

 Once the screws are removed, the guide

brackets will drop. You need to remove them

through the gap on the sides of the set.

 This can be done only when there is enough

space between the set and the wall mount

plate or the wall to unscrew the screws.

(Please check whether there is enough

space to remove the screws before fixing the

guide brackets.)

 Join Set 2 to Set 1 using the guide brackets

on the top side of Set 1 and mount the two

sets to the wall mount plate or the wall.

 Remove the guide brackets after mounting

the sets.

Guide bracket

<Rear view of the set with the wall

mount plate>

Remove the

guide brackets

ENG

ENGLISH

ASSEMBLING AND PREPARING

U-shaped ﬁxture

Fix the guide brackets to Set 3 following the steps above, and loosely mount the set to the wall mount

plate or the wall.

Minimize the space between the sides of the sets using the U-shaped fixture.

When the sets are joined with the minimum amount of space between them, ﬁrmly mount them to the wall

mount plate or the wall.

When the sets are firmly mounted to the wall, remove the U-shaped fixtures.

How to Join Sets - Installing Set 3

#1 #3

ENG

ENGLISH

ASSEMBLING AND PREPARING

Set 4 joined to the rest of the sets

(2 x 2 tiling)

Wall mount plate or wall

Display set

Loosely mount Set 4 to the wall mount plate or the wall and minimize the space between the sets using

the U-shaped fixtures.

When Set 4 is firmly mounted to the wall, remove the U-shaped fixtures.

Remove the guide brackets. See <How to Join Sets - Installing Set2,3>.

Now the 2 x 2 tiling is complete.

You can tile in various combinations, such as 3 x 3.

How to Join Sets - Installing Set 4

 The guide brackets for tiling should only be used to join sets and should be removed once they are joined.

 The guide brackets should only be used as the assisting tool when tiling sets. The load applied to each set

should be supported by the wall mount plate or the wall using a VESA wall mount (800 x 400).

 (Each set must be firmly mounted to the wall mount plate or the wall.)

 The guide brackets must be removed once the sets are joined. When joining the sets without removing the

guide brackets, extra caution is required to prevent damage due to the set weight.

 The U-shaped fixtures must also be removed after mounting the set to the wall mount plate or the wall.

 You may mount the set without using the guide brackets or the U-shaped ﬁxtures; this does not affect the

performance of the device.

NOTE
