OWNER’S MANUAL

MONITOR SIGNAGE

47TS50MF

Please read this manual carefully before operating the your set and

retain it for future reference.

MONITOR SIGNAGE MODELS

ENG

ENGLISH

ENG

ENGLISH

CONTENTS

3 INSTALLATIONPREPARATION

3 Accessories

4 MountingHoles

5 PortraitLayout

6 StorageMethodforPanelProtection

6 - CorrectMethod

6 - IncorrectMethod

7 PRODUCTINSTALLATION

7 InstallinganLVDSCable

8 LightingInstallation

9 InstallationinEnclosure

10 Precaution

10 - CorrectMethod

10 - IncorrectMethod

11 TROUBLESHOOTING

12 SPECIFICATIONS

14 LVDSPINMAPGUIDE

 Thewarrantywillnotcoveranydamagescausedbyusingtheproductinanexcessivelydusty

environment.

NOTE

ENG

ENGLISH

INSTALLATIONPREPARATION

Accessories

Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal

dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct

andaccessories.

 Donotuseanyunapprovedorcounterfeitpartsoraccessoriestoensurethesafetyandproductlife

span.

 Anydamagesorinjuriesbyusingunapproveditemsarenotcoveredbythewarranty.

 Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.

 Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade

ofproductfunctions.

 LVDScableisoptionalandnotprovidedwiththeproduct. PleaserefertoLVDSPinMapGuideon

pages14to15fortheLVDScableassembly.

CD(Owner'sManual)/

EasySetupGuide

CAUTION

NOTE

ENG

ENGLISH

INSTALLATIONPREPARATION

Frontoftheproduct

Rearoftheproduct

 Thisproducthasthefrontandbacksides.Makesuretheproductisinstalledwiththefrontsidefacing

forward.

 Imageisdisplayedreverselyonthebackside.

CAUTION

MountingHoles

UseM3screwstomountthemonitor.Thereare20positionsforscrewsontherearsideoftheproduct.

ENG

ENGLISH

INSTALLATIONPREPARATION

PortraitLayout

Toinstallinportraitmode,rotatethesetclockwise90degreeswhenlookingatfromthefront.

Theportraitmodeisonlyavailableonthescalerboard.(Thescalerboardshouldsupportportraitmode.)

 Thescalerboardisoptionalanditisnotpartoftheproduct.

CAUTION

ENG

ENGLISH

INSTALLATIONPREPARATION

CorrectMethod IncorrectMethod

StorageMethodforPanelProtection

Panel

Cushion

Whenlayingtheproductonaflatfloor,pititface

downonacushionorblankettopreventscratch-

inganddamage.

Ifthereisnoacushionorasoftclothavailable,

ensurethefloorisclean.Thenlaytheproduct

downcarefullywiththepanelfacingeitherupward

ordownward.Atthistime,makesurethatno

objectfallsonthepanel.

Panel

Iftheproductistiltedontothebezel,thebottomof

thepanelmaybedamaged.

Iftheproductistiltedontotheedgeofthepanel,

thepanelmaybedamaged.



ENG

ENGLISH

PRODUCTINSTALLATION

InstallinganLVDSCable

542.25mm

45mm

30mm

LVDSCable

TheLVDScableportislocatedasshowninthefigurebelow.

Wheninstallingtheproduct,makesurethereisenoughspacetoinstalltheLVDScable.

ENG

ENGLISH

PRODUCTINSTALLATION

LightingInstallation

Thisproductmustbeinstalledwithbacklighting.

Lightingmustbeinstalledbehindtheproductsothatthedisplaycanbeseenclearly.

Ifsomethingobstructsthebacklighting,additionallightingmayberequired.

Lighting

Additionallighting

Object

600luxormore

(WhentheFullScreen

isWhite.)

600luxormore

(WhentheFullScreen

isWhite.)

ENG

ENGLISH

PRODUCTINSTALLATION

 Thisproductcanbeinstalledinvarious

locationsbesidestheenclosure.

Exampleoftheproductintheenclosure

Exampleofthelightinginstallation

Lightingmustbeinstalledintheenclosure.

InstallationinEnclosure

Installtheproductintheenclosure.Wearworking

gloveswheninstallingtheproduct.Donotuse

barehands.Otherwise,itmaycausepersonal

injury.

1 Placetheproductintheenclosure.

2 Attachtheproductusingthepreparedscrew

holesandanadditionalenclosureguideframe.

NOTE

 Thepanelofthisproductissothinthatitcan

beeasilybrokenwhenitisexposedtothe

outside.Useaclearprotectivecovertokeep

theproductfromexposuretotheelements.

CAUTION

ENG

ENGLISH

PRODUCTINSTALLATION

Precaution

Donotliftuptheproductbyholdingacorner.Donotholdthescreenareawhenholdingthe

product.

Useasoftclothmoistenedwithn-hexaneto

removedustorstainsonthescreen.

CorrectMethod IncorrectMethod

 Makesurethepowerisdisconnectedbefore

movingorinstallingtheproduct.Otherwise

electricshockmayoccur.

 Wearworkinggloveswheninstallingthe

product.Donotusebarehands.Otherwise,

itmaycausepersonalinjury.

 Ifyouinstalltheproductonaceilingor

slantedwall,itmayfallandresultinsevere

injury.

 Donotfastenthescrewstootightly;thismay

causedamagetotheproductandvoidyour

warranty.

 UseM3x4mmscrewstomountthe

monitor.Anydamagesorinjuriescausedby

misuseoruseofimproperaccessoriesare

notcoveredbythewarranty.

 Ifafixedimagedisplaysonthescreenfora

longperiodoftime,itwillbeimprintedand

becomeapermanentdisfigurementonthe

screen.Thisisimageburnorburn-inandnot

coveredbythewarranty.

 Topreventimagesticking,donotplayastill

imageformorethantwohours.

 Recommendedoperationtimeforoptimum

performanceandreliabilityis12hoursor

lessperday.

CAUTION
