Owner's Manual

IPS LED MONITOR

LED LCD MONITOR

(LED MONITOR*)

ENG

ENGLISH

TABLE OF CONTENTS

CONTENTS

3 LICENSE

4 ASSEMBLINGANDPREPAR-

ING

4 Unpacking

6 Partsandbuttons

7 MovingandLiftingtheMonitor

8 SettinguptheMonitorset

8 - AttachingtheStandBase

9 - DetachingtheStandBase

10 - Mountingonatable

10 - Usingthecableholder

12 - Mountingonawall

13 USINGTHEMONITORSET

13 ConnectingtoaPC

13 - D-SUBconnection

13 - DVI-Dconnection

14 - HDMIconnection

14 ConnectingtoAVDevices

14 - HDMIconnection

15 ConnectingtoExternalDevices

15 - Peripheraldeviceconnection

16 CUSTOMIZINGSETTINGS

17 CustomizingSettings

17 - MenuSettings

19 -Picture

20 -Color

21 -Display

21 -Audio

22 -Others

23 READERSetting

24 FUNC.Setting

24 -SMARTENERGYSAVING

25 -PictureMode

26 -ColorWeakness

27 TROUBLESHOOTING

29 SPECIFICATIONS

39 PresetModes(Resolution)

40 Indicator

41 PROPERPOSTURE

41 ProperpostureforusingtheMonitorset.

ENG

ENGLISH

LICENSE

Eachmodelhasdifferentlicenses.Visitwww.lg.comformoreinformationonthelicense.

ThetermsHDMIandHDMIHigh-DefinitionMultimediaInterface,andthe

HDMIlogoaretrademarksorregisteredtrademarksofHDMILicensingLLC

intheUnitedStatesandothercountries.

ThefollowingcontentisonlyappliedtothemonitorwhichissoldinEuropemarketandwhichneedsto

meettheErPDirective:

*Thismonitorissettobeturnedoffautomaticallyin4hoursafteryouturnedondisplayifthereisnoadjust-

menttodisplay.

*Tomakethissettingbedisabled,changetheoptionto‘Off’inOSDmenuof“AutomaticStandby”.

20M38H 22M38H 24M38H 27MP38VQ 27MP38HQ

ENG

ENGLISH

ASSEMBLING AND PREPARING

ASSEMBLINGANDPREPARING

Unpacking

Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal

dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct

andaccessories.

CD(Owner'sManual)/

Card

(Dependingonthecountry) (Dependingonthecountry)

PowerCord AC-DCAdapter AC-DCAdapter

or

D-SUBCable

(Thiscableisnotincludedinall

countries.)

HDMICable

StandBody StandBase

StandBase

DVI-DCable

(Thiscableisnotincludedinall

countries.)

(Thiscableisnotincludedinall

countries.)

StandBody TwoScrews

ENG

ENGLISH

ASSEMBLING AND PREPARING

 Donotuseanyunapprovedaccessoriestoensurethesafetyandproductlifespan.

 Anydamagesorinjuriesbyusingunapprovedaccessoriesarenotcoveredbythewarranty.

 Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.

 Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade

ofproductfunctions.

CAUTION

NOTE

ENG

ENGLISH

ASSEMBLING AND PREPARING

Partsandbuttons

PowerIndicator

 LightingOn:Turnedon

 LightingOff:Turnedoff

Connectionpanel(Seep.13~15)

Button(Seep.16)

(PowerButton)

ENG

ENGLISH

ASSEMBLING AND PREPARING

MovingandLiftingtheMonitor

Whenmovingorliftingthemonitor,followthese

instructionstopreventthemonitorfrombeing

scratchedordamagedandtoensuresafetrans-

portationregardlessofitsshapeorsize.

 Asfaraspossible,avoidtouchingthemoni-

torscreen.Thismayresultindamagetothe

screenorsomeofthepixelsusedtocreate

images.

 Itisadvisabletoplacethemonitorinthe

originalboxorpackingmaterialbeforeat-

temptingtomoveit.

 Beforemovingorliftingthemonitor,discon-

nectthepowercordandallcables.

 Holdthetopandbottomofthemonitorframe

firmly.Donotholdthepanelitself.

 Whenholdingthemonitor,thescreenshould

faceawayfromyoutopreventitbeing

scratched.



 Whenmovingthemonitor,avoidanystrong

shockorvibrationstotheproduct.

 Whenmovingthemonitor,keepitupright,

neverturnthemonitoronitssideortiltit

sideways.

CAUTION

ENG

ENGLISH

ASSEMBLING AND PREPARING

SettinguptheMonitorset

AttachingtheStandBase

1 PlacetheMonitorsetwiththescreenside

downonaflatandcushionedsurface.

Layafoammatorsoftprotectivecloth

onthesurfacetoprotectthescreenfrom

damage.

CAUTION

2

StandBase

StandBody

StandBase

19M38A 20M38A 22M38A 24M38A

19M38D 20M38D 22M38D 24M38D

20M38H 22M38H 24M38H

27MP38VQ 27MP38HQ

AttachtheStandBodytothemonitorset.

AttachtheStandBase.

Tightenthescrewtotherightwithacoin.

AttachtheStandBodytothemonitorset.

UsetwoscrewstofixtheStandBodyand

monitorset.

AttachtheStandBase.

Tightenthescrewtotherightwithacoin.

StandBody

ENG

ENGLISH

ASSEMBLING AND PREPARING

DetachingtheStandBase

1 PlacetheMonitorsetwiththescreenside

downonaflatandcushionedsurface.

StandBase

StandBody

 Thisillustrationdepictsthegeneralmodelof

connection.Yourmonitormaydifferfromthe

itemsshowninthepicture.

 Donotcarrytheproductupsidedownholding

onlythestandbase.Theproductmayfall

andgetdamagedorinjureyourfoot.

CAUTION

StandBody

StandBase

219M38A 20M38A 22M38A 24M38A

19M38D 20M38D 22M38D 24M38D

20M38H 22M38H 24M38H

27MP38VQ 27MP38HQ

PullouttheStandBodyandStandBase

fromthemonitorset.

Turnthescrewtotheleftwithacoin.

PullouttheStandBase.

Turnthescrewtotheleftwithacoin.

PullouttheStandBasefromtheStandBody.

RemovetwoscrewsandpullouttheStand

Bodyfromthemonitorset.

ENG

ENGLISH

ASSEMBLING AND PREPARING

Mountingonatable

1 LiftandtilttheMonitorsetintoitsupright

positiononatable.

Leavea10cm(minimum)spacefromthewall

forproperventilation.

Usingthecableholder

2 ConnecttheAC-DCAdapterandPowerCord

toawalloutlet.

3 Press (Power)buttononthebottomswitch

paneltoturnthepoweron.

10 cm

Unplugthepowercordbeforemovingthe

Monitortoanotherlocation.Otherwiseelectric

shockmayoccur.

CAUTION

Cableholder

or
