LG 19EB13T Manuel utilisateur

www.lg.com

OWNER’S MANUAL

Please read this manual carefully before operating your set and

retain it for future reference.

ENGLISH

LED MONITOR

LED MONITOR MODEL

19EB13T

Accessories

!!! Thank for selecting LGE products !!!

Please make sure the following items are included with your

monitor. If any items are missing, contact your dealer.

User's Guide/Cards Power Cord

15-pin D-Sub Signal Cable

(To set it up, this signal cable may be

attached to this product before

shipping out.)

DVI-D Signal Cable

(This feature is not available in all

countries.)

NOTE

This accessories may look different from those shown here.

User must use shielded signal interface cables (D-sub 15 pin cable, DVI-D cable) with ferrite

cores to maintain standard compliance for the product.

Connecting the Display

Before setting up the monitor, ensure that the power to the monitor, the computer

system, and other attached devices is turned off.

Connecting the stand

1. Place the monitor with its front facing downward on a soft cloth.

2. Assemble the Stand Body into the

product in the correct direction as shown in

the picture. Make sure you push it until you

hear it “click”.

3. Assemble the Stand Base(Front,

Rear) into the Stand Body in the

correct direction.

4. Tie down the base lock to perpendicularity direction.

5. Once assembled take the monitor up carefully and face the front side.

Important

This illustration depicts the general model of connection. Your monitor may differ from

the items shown in the picture.

Do not carry the product upside down holding only the stand base. The product may

fall and get damaged or injure your foot.

Stand Body

Hinge Body

Stand Body

Stand Base

Connecting the Display

Disassembling the stand

1. Put a cushion or soft cloth on aflat

surface.

3. Change your lock on the product as it follows and turn it in the arrow direction.

2. Place the monitor face Down on the

cushion or soft cloth.

If you can't release the stand base even the locking knob is at a release

position, Please push the indicated knob down and retry it.

Connecting the Display

Pull out the Stand to remove.

Pushing the PUSH button, Take the stand body from hinge body.

Good Position Bad Position

Warning:

You can hurt your finger.

Connecting the Display

Before setting up the monitor, ensure that the power to the monitor,

the computer system, and other attached devices is turned off.

Positioning your display

-After installation, adjust the angle as shown below.

1. Adjust the position of the panel in various ways for maximum comfort.

Tilt Range : -5˚ to 15˚

ERGONOMIC

It is recommended that in order to maintain an ergonomic and comfortable viewing position,

the forward tilt angle of the monitor should not exceed 5 degrees.

Do not touch or press the screen when

adjusting the angle of the monitor.

When adjusting the angle of the screen, do

not put your finger(s) in between the head of

the monitor and the stand body. You can

hurt your finger(s).

Connecting the Display

NOTE

‘ Self Image Setting Function’? This function provides the user with optimal display

settings.When the user connects the monitor for the first time, this function automatically adjusts

the display to optimal settings for individual input signals.

‘AUTO’ Function? When you encounter problems such as blurry screen, blurred letters, screen

flicker or tilted screen while using the device or after changing screen resolution, press the

AUTO function button to improve resolution.

Connect DVI-D(Digital signal) Cable

Connect D-sub(Analog signal) Cable

1. Before setting up the monitor, ensure that the power to the monitor, the computer

system, and other attached devices is turned off.

Connect signal input cable and power cord in order, then tighten the screw

of the signal cable.

Connecting with the PC

NOTE

This is a simplified representation of the rear view.

This rear view represents a general model; your display may differ from the view as shown.

Power Button

Connect the signal

input cable and tighten

it up by turning in the

direction of the arrow

as shown in the figure.

Wall-outlet type

Mac adapter : For Apple Macintosh use, a

separate plug adapter is needed to change the

15 pin high density (3 row) D-sub VGA

connector on the supplied cable to a 15 pin 2

row connector.

When using a D-Sub signal input cable connector

for Macintosh

Varies according to model.

DVI-D (This feature is not available in all countries.)

3. Press the power button on the front panel to turn the power on. When monitor power is

turned on, the 'Self Image Setting Function' is executed automatically.

(Only Analog Mode)

Control Panel Functions

Front Panel Controls

MENU Button

OSD LOCKED/UNLOCKED

This function allows you to lock the current control

settings, so that they cannot be inadvertently changed.

Press and hold the MENU button for several seconds.

The message "OSD LOCKED" should appear.

You can unlock the OSD controls at any time by pushing

the MENU button for several seconds. The message

"OSD UNLOCKED" should appear.

Control Panel Functions

AUTO Button

AUTO IMAGE ADJUSTMENT

When adjusting your display settings, always press the

AUTO button before entering the On Screen

Display(OSD). (Only Analog Mode)

This will automatically adjust your display image to the

ideal settings for the current screen resolution size

(display mode).

The best display mode is

19EB13T:1366 x 768

INPUT Button

Use this button to turn the display on or off.

The power indicator stays white if the display is running

properly (On Mode). If the display is in Sleep Mode

(Energy Saving), the power indicator is blinking white.

Power Button &

Power Indicator

When two input signals are connected, you can select the

input signal (D-SUB/DVI) you want. When only one signal

is connected, it is automatically detected. The default

setting is D-Sub.

(SOURCE Hot key)

Exit the OSD(On Screen Display).

EXIT Button

SUPER ENERGY

SAVING Button

Use this button to enter

SUPER ENERGY SAVING

menu.For more information, refer to page 14.

On Screen Display (OSD) Control Adjustment

Screen Adjustment

Making adjustments to the image size, position and operating

parameters of the display is quick and easy with the On Screen

Display Control system.

A short example is given below to familiarize you with the use of the

controls. The following section is an outline of the available

adjustments and selections you can make using the OSD.

To make adjustments in the On Screen Display, follow these steps:

Press the discretionary Button, then the main menu of the OSD appears.

To access a control, use the corresponding Buttons.

Use the / Buttons to adjust the image to the desired level.

Use the Button to select other sub-menu items.

Press the EXIT Button to exit from the OSD.
