LG 75TC3D-B Manuel utilisateur

Please read this manual carefully before operation and retain it for future

reference.

webOS 3.2

www.lg.com

USER MANUAL

LG Digital

Signage

(MONITOR SIGNAGE)

ENGLISH

CONTENTS

SETTINGS ......................................4

- Home.......................................................................................4

Global Buttons

Dashboard

Content Manager

- Ez Setting .............................................................................5

Video Wall

On/Off Scheduler

SI Server Setting

Server Setting

Fail Over

Status Mailing

Play via URL

Setting Data Cloning

Sync Mode

Multi Screen

- General................................................................................10

Language

System Information

Set ID

Time & Date

Power

Network

Safety Mode

Expert Controls

- Display .................................................................................21

Picture Mode

Aspect Ratio

Rotation

Expert Controls

- Sound ...................................................................................27

Sound Mode

Sound Out

Audio Out

Volume Increase Amount

AV Sync. Adjustment

Digital Audio Input

- Admin...................................................................................30

Lock Mode

Change PIN Code

Enterprise Settings

Reset to Initial Settings

Factory Reset

ENGLISH

CONTENT MANAGER ................ 32

- Web Login..........................................................................32

- Content Manager ..........................................................32

Player

Schedules

Template

- Group Manager 2.0 ......................................................39

- ScreenShare......................................................................42

MANAGEMENT TOOLS.............. 43

- Control Manager............................................................43

- Picture ID............................................................................44

IR CODE ...................................... 45

CONTROLLING MULTIPLE

PRODUCTS.................................. 47

- Connecting cables.........................................................47

- Communication Parameter ......................................48

- Command Reference List..........................................49

- Transmission/Reception Protocol .........................53

To obtain the source code under GPL, LGPL, MPL,

and other open source licenses, that is contained

in this product, please visit

http://opensource.lge.com.

In addition to the source code, all referred license

terms, warranty disclaimers and copyright notices

are available for download.

LG Electronics will also provide open source code

to you on CD-ROM for a charge covering the

cost of performing such distribution (such as the

cost of media, shipping, and handling) upon email

request to opensourc[email protected]. This offer is valid

for three (3) years from the date on which you

purchased the product.

ENGLISH

NOTE

•Software-related content may be changed without prior notice due to upgrades of the product functions.

•Some features described in the User Manual may not be supported in certain models.

•SNMP 2.0 is supported.

SETTINGS

Home

Global Buttons

•MOBILE URL: Provides information necessary to access the monitor set through an external device's browser.

With this feature, you can view QR code and URL information. In addition, by accessing the URL,

you can also run Content Manager and Group Manager 2.0, and Control Manager. (This featured

is optimized for Google Chrome.)

•Input: Navigate to the external input selection screen

•Settings: Navigate to the Settings screen

Dashboard

•This feature displays key information about your Signage monitor in the center of the home screen. In the Dashboard,

you can manually change settings by selecting the corresponding items.

NOTE

•If the dashboard is locked, the focus does not move.

Content Manager

•Player: Play a variety of content including images, videos, and SuperSign content.

•Scheduler: Manage schedules for content that will be played at different times.

•Template: You can create your own content using templates and media files.

•Group Manager 2.0: Distribute content schedules and setting data to the connected device.

ENGLISH

Ez Setting

Video Wall

Ez Setting Video Wall

Set Video Wall options to create a wide visual canvas.

•Tile Mode: Turn Tile Mode on or off.

•Tile Mode Setting: Display a single integrated screen on multiple Signage monitors.

•Natural Mode: Display the image excluding the area that overlaps with the monitor's bezel so that the image

displayed has a more natural feel to it.

•White Balance: Configure white balance settings (White Pattern, R/G/B-Gain, and Luminance).

•RESET: Reset to initial settings.

On/Off Scheduler

Ez Setting On/Off Scheduler

Set a schedule to use your signage by time and day of the week.

•On/Off Time Setting: Set on/off times for each day of the week.

•Holiday Setting: Set holidays by date and by day of the week.

SI Server Setting

EZ Setting SI Server Setting

Set up to connect your signage to an external SI server. Set up a server environment for SI app installation.

Server Setting

Ez Setting Server Setting

Set up to connect your signage to a SuperSign server.

•SuperSign premium servers

•SuperSign link servers

ENGLISH

Fail Over

Ez Setting Fail Over

This feature enables automatically switching to other input sources in order of priority if the primary signal is

interrupted. It also enables the automatic playback of the content stored on your device.

•On/Off: Turns Fail Over on or off.

•Input Priority: Set the priority of input sources for fail over.

•Backup via Storage: Automatically play the content stored on the device when there is no input signal.

•Capture time Interval: Set the interval at which the image/video played on the screen will be automatically

captured when Backup via Storage has been set to Auto. (30 min, 1 hour, 2 hours, and 3

hours)

Status Mailing

Ez Setting Status Mailing

This feature configures the system so that the status of the device is assessed and then notified to the administrator

by e-mail.

•On/Off: Turns Status Mailing on or off.

•Mailing Option, SCHEDULE: Sets the email sending interval.

•User E-mail Address: Set the user email address of the sender.

•Sending Server (SMTP): Set the address of the SMTP server.

•ID: Enter the account ID of the sender.

•Password: Enter the password for the sender's account.

•Recipient E-mail Address: Set the email address of the recipient.

•Message Delivery: Immediately assess the status of the device and deliver the information to the specified email

address.

ENGLISH

NOTE

•If the status regarding any of the following items changes or becomes abnormal, a status message can be sent.

- 1. Temperature: If the monitor set reaches a dangerous temperature, its current temperature is recorded, and an

email containing such information is sent.

- 2. Validity of the temperature sensor: An email is sent if there is no temperature sensor connected, if the

communication status of the temperature sensor is unknown, or if the information provided by the chip provider is

abnormal.

- 3. Network Status (Wireless/Wired): An email is sent when the network's connection status is changed. The

maximum number of network status changes that can be saved is limited to 50. The saved value is reset once the

power turns off.

- 4. Screen Fault Detection: An email is sent when a "Check Screen" triggered by the Check screen Screen Fault

Detection has failed to perform.

- 5. No Signal Check: Checks whether there is a signal. If there are no signals for more than 10 seconds, an email is

sent.

- 6. Local Contents Schedule: An email is sent if it becomes impossible to play content between the start time and

end time of the playback schedule registered in Signage. However, this does not apply when termination was made

using the remote control.

- 7. SuperSign Schedule: An email is sent if it becomes impossible to play content between the start time and end

time of the playback schedule distributed to SuperSign. However, this does not apply when termination was made

using the remote control.

•Only SMTP ports 25, 465, and 587 are supported.

ENGLISH

Play via URL

Ez Setting Play via URL

Play content you want to play automatically through the built-in web browser.

•URL Loader: Turns Play via URL on or off.

•Set URL: Enter the URL address to display automatically.

•Preview: Preview your desired website by accessing the specified URL.

•SAVE: Save the specified URL.

•Reboot to Apply: Restarts the monitor set after saving the specified URL.

NOTE

•This feature does not apply when Screen Rotation is enabled, and using this feature disables Preview.

Setting Data Cloning

Ez Setting Setting Data Cloning

This feature is used to copy and import the settings of the device to other devices.

•Export Setting Data: Export the settings of the device to another device.

•Import Setting Data: Import the settings of another device into the device.

Sync Mode

Ez Setting Sync Mode

Sync up time and content among multiple signages.

•RS-232C Sync: Sync up multiple signages connected by RS-232C.

•Network Content Sync: Sync up multiple signages connected to the same network.

ENGLISH

Multi Screen

Ez Setting Multi Screen

This feature allows you to view multiple external inputs and videos on a single screen.

NOTE

•After entering multi-screen mode, the screen may flicker and the picture may appear abnormal on certain devices

while the optimal resolution is selected automatically. If this happens, please restart the monitor.

•In multi-screen mode, the DP daisy chain feature is not supported.

Selecting Screen Layout

When you enter multi-screen mode without having set any screen layout, the screen layout selection menu appears.

When the screen layout selection menu is not displayed on the screen, go to the screen layout menu bar by pressing

the up arrow key on your remote control and select your desired screen layout. If you want to close the screen layout

menu, press the back key.

Closing Screen Layout Menu

From the screen layout menu, press the up arrow key on the remote control to go to the screen layout menu bar and

select it or press the back key to close the screen layout menu.

Changing Screen Input

Press the button on the top right of each split screen to select the desired input.

NOTE

•Inputs which have already been selected for other split screens cannot be selected again. To select them, press the

RESET button to reset the inputs for all screens first.

•PIP mode works only when External Input Rotation is set to Off and Screen Rotation is set to Off.

Playing Videos on Split Screens

Press the button on the upper right of each split screen, select Video File, and then select a storage device to view

the list of videos in the selected device. Next, select your desired video from the list to play it.

NOTE

•Videos created with HEVC, MPEG-2, H.264, or VP9 codecs can be played on split screens. When using PIP mode, the

following combinations cannot be used.

Main Sub

HEVC HEVC

H.264 HEVC

MPEG-2 HEVC

VP9 VP9

ENGLISH

General

Language

General Language

You can select the menu language to be displayed on the screen.

•Menu Language: Sets the language of your Signage monitor.

•Keyboard Language: Sets the language of the keyboard displayed on the screen.

System Information

General System Information

This feature displays information such as the device name, software version, and storage space.

Set ID

General Set ID

•Set ID (1~1000): Assigns a unique Set ID number to each product when several products are connected via RS-

232C. Assign numbers ranging from 1 to 1000 and exit the option. You can control each product

separately by using the Set ID you assigned to each product.

•Auto Set ID: Automatically assigns a unique Set ID number to each product when several products are connected

for display.

•Reset Set ID: Reset the Set ID of the product to 1.

Time & Date

General Time & Date

This feature enables you to view and change the time and date on the device.

•Set Automatically: Set Time and Date.

•Daylight Saving Time: Set the start and end times for Daylight Saving Time. The DST start/end times function only

when you set them more than one day apart from each other.

•Time Zone: Configure the continent, country/region and city.

Table des matières

Manuels Affichage numérique populaires d'autres marques

SMART-AVI

SMART-AVI SIGNAGEPRO Manuel utilisateur

KeyWest Technology

KeyWest Technology BREEZE Manuel utilisateur

XtendLan

XtendLan XL-DSP-183C Manuel utilisateur

Dynascan

Dynascan DS861LR4 Manuel utilisateur

Classic Exhibits

Classic Exhibits SEGUE DESIGNS MOD-1363 Manuel utilisateur

protech

protech KT-7290 Manuel utilisateur

WebDT

WebDT 515A Instructions de montage

Samsung

Samsung IWJ Series Manuel utilisateur

EVERI

EVERI Enrollment Kiosk Manuel utilisateur

NCR

NCR SelfServ 90 Manuel

ViewSonic

ViewSonic EP4602 Manuel utilisateur

ViewSonic

ViewSonic EP3202r Manuel utilisateur

Samsung

Samsung OM46N Manuel utilisateur

Viessmann

Viessmann 6336 Manuel utilisateur

Osram

Osram Traxon Manuel d'instructions d'installation

Philips

Philips Signage Solutions Series BDL4990VL Manuel utilisateur

ViewSonic

ViewSonic EP5012-L Manuel utilisateur

Philips

Philips CRD01/00 Manuel utilisateur
