OWNER’S MANUAL

MONITOR SIGNAGE

42WL30MS

47WL30MS

55WL30MS

60WL30MS

Please read this manual carefully before operating the your set and

retain it for future reference.

MONITOR SIGNAGE MODELS

ENG

ENGLISH

TABLE OF CONTENTS

4 LICENSES

5 ASSEMBLING AND

PREPARING

5 Accessories

6 OptionalAccessories

7 PartsandButtons

8 ConnectingtheStand

8 ConnectingtheSpeaker

9 UsingtheMountingCableTie

10 UsingtheIRReceiver

10 PortraitLayout

11 MountingonaWall

13 REMOTE CONTROL

15 USING THE MONITOR

15 ConnectingtoaPC

15 - RGBConnection

16 - DVIConnection

16 - HDMIConnection

17 - DisplayPortConnection

17 - IRReceiverConnection

18 AdjustingtheScreen

18 - SelectinganImageMode

18 - CustomizingImageOptions

19 - CustomizingPCDisplayOptions

19 AdjustingtheSound

19 - SelectinganSoundMode

20 - CustomizingSoundOptions

20 UsingAdditionalOptions

20 - UsingtheInputList

21 - AdjustingAspectRatio

23 ENTERTAINMENT

23 UsingtheNetwork

23 - ConnectingtoaWiredNetwork

24 - NetworkStatus

25 UsingtheMyMedia

25 - ConnectingUSBStorageDeviceand

UsingSignageDevice

27 - BrowsingFiles

29 - ViewingMovies

32 - ViewingPhotos

35 - ListeningtoMusic

38 - ViewingtheContentsList

39 - DivX®VODGuide

40 - UsingPIP/PBP

41 CUSTOMIZING SETTINGS

41 AccessingMainMenus

42 - PICTURESettings

45 - AUDIOSettings

46 - TIMESettings

47 - OPTIONSettings

51 - PictureIDSettings

52 - NETWORKSettings

53 MAKING CONNECTIONS

54 ExternalDeviceConnection

54 - AV(CVBS)Connection

54 - COMPONENTConnection

55 - HDMIConnection

55 - DVIConnection

56 USBConnection

56 LANConnection

57 DaisyChainConnection

57 - DVImode

58 TROUBLESHOOTING

ENG

ENGLISH

TABLE OF CONTENTS

61 SPECIFICATIONS

74 IR CODES

75 CONTROLLING THE MULTIPLE

PRODUCT

75 ConnectingtheCable

75 RS-232CConfigurations

75 CommunicationParameter

76 CommandReferenceList

78 Transmission/ReceivingProtocol

ENGLISH

4LICENSES

LICENSES

Supportedlicensesmaydifferbymodel.Formoreinformationofthelicenses,visitwww.lg.com.

ThetermsHDMIandHDMIHigh-DefinitionMultimediaInterface,andthe

HDMIlogoaretrademarksorregisteredtrademarksofHDMILicensingLLC

intheUnitedStatesandothercountries.

ABOUTDIVXVIDEO:DivX isadigitalvideoformatcreatedbyDivX,LLC,a

subsidiaryofRoviCorporation.ThisisanofficialDivXCertified devicethat

playsDivXvideo.Visitdivx.comformoreinformationandsoftwaretoolsto

convertyourfilesintoDivXvideos.

ABOUTDIVXVIDEO-ON-DEMAND:ThisDivX

Certified devicemustberegisteredinordertoplaypurchasedDivXVideo-

on-Demand(VOD)movies.Toobtainyourregistrationcode,locatethe

DivXVODsectioninyourdevicesetupmenu.Gotovod.divx.comformore

informationonhowtocompleteyourregistration.

DivXCertified toplayDivX videouptoHD1080p,includingpremium

content.

DivX ,DivXCertified andassociatedlogosaretrademarksofRovi

Corporationoritssubsidiariesandareusedunderlicense.

CoveredbyoneormoreofthefollowingU.S.patents:7,295,673;7,460,668;

7,515,710;7,519,274

 Thewarrantywillnotcoveranydamagescausedbyusingtheproductinanexcessivelydusty

environment.

NOTE

ManufacturedunderlicensefromDolbyLaboratories.Dolbyandthedouble-D

symbolaretrademarksofDolbyLaboratories.

ENG

ENGLISH

ASSEMBLING AND PREPARING

Accessories

Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal

dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct

andaccessories.

 Donotuseanypirateditemstoensurethesafetyandproductlifespan.

 Anydamagesorinjuriesbyusingpirateditemsarenotcoveredbythewarranty.

 Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.

 Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade

ofproductfunctions.

CAUTION

NOTE

Remote Control and

Batteries

Power Cord

CD (Owner's Manual,

SuperSign Program/ Manual)/

Cards

D-sub 15-pin Signal Cable

Mounting Cable Tie

*Twocabletiesareprovidedwith

the60WL30MSmodel.

IR Receiver Magnetic sheet

ENG

ENGLISH

ASSEMBLING AND PREPARING

Optional Accessories

Withoutpriornotice,optionalaccessoriesaresubjecttochangetoimprovetheperformanceoftheproduct,

andnewaccessoriesmaybeadded.Theillustrationsinthismanualmaydifferfromtheactualproductand

accessories.

 Cableholder/cabletiemaynotbeavailableinsomeareasorforsomemodels.

 Optionalaccessoriesarenotincludedforallmodels.

NOTE

Stand

ST-420T(42WL30MS)

ST-470T(47WL30MS)

ST-550T(55WL30MS)

ST-550T(60WL30MS)

Cable holder/

Cable Tie

Screws

Diameter4.0mmxPitch0.7mmx

Length14mm(IncludedSpringWasher)

Speaker

SP-2100

Stand kit Speaker kit

Screws CD(Owner's Manual)/

Cards

Media Player

NC1000/NC1100

NA1000/NA1100

Media Player kit

Screws

Diameter4.0mmx

Pitch0.7mmxLength

8mm(IncludedSpring

Washer)

Screws

Diameter4.0mmx

Pitch1.6mmxLength

10mm

ENG

ENGLISH

ASSEMBLING AND PREPARING

Parts and Buttons

Connection PanelScreen Buttons

No. Description

1Movestheselectionupanddown.

2Adjuststhevolumelevel.

3Displaysthecurrentsignalandmode.

Pressthisbuttontoadjustthescreenautomatically(availableonlyinRGBmode)

4Accessesthemainmenus,orsavesyourinputandexitsthemenus.

5Changestheinputsource.

6Turnsthepoweronoroff.

ENG

ENGLISH

ASSEMBLING AND PREPARING

2 Usethescrewstosecurethestandontherear

sideoftheproductasshowninthediagram.

Connecting the Stand Connecting the Speaker

-Onlyonsomemodels.

1 Placeasoftclothonthetableandputthe

productwiththescreenfacingdownward.

-Onlyonsomemodels.

1 Connecttheinputsignalcabletothemonitor

beforeinstallingthespeakers.Useacabletie

toorganizethecables.

3 Thenconnectthespeakercable.Afterinstalling

yourspeakers,useholdersandcabletiesto

organizethespeakercables.

2 Mountthespeakerbyusingascrewasshown

inthefollowing.Makesurethepowercableis

disconnected.

ENG

ENGLISH

ASSEMBLING AND PREPARING

Using the Mounting Cable

Tie

First,connecttheinputsignalcabletobeused.

Insertthecabletieintothebottomholeonthe

backasshowninthefiguretoorganizecables.

42WL30MS

47WL30MS

55WL30MS

60WL30MS

ENG

ENGLISH

ASSEMBLING AND PREPARING

Portrait Layout

Toinstallinportraitmode,rotatetheset

counterclockwise90degreeswhenlookingatfrom

thefront.

Using the Kensington security system

TheKensingtonsecuritysystemconnectoris

locatedatthebackofthemonitorset.Formore

informationofinstallationandusing,refertothe

manualsuppliedwiththeKensingtonsecurity

systemorvisit

http://www.kensington.com

ConnecttheKensingtonsecuritysystemcable

betweenthemonitorsetandatable.

 TheKensingtonsecuritysystemisoptional.

Youcanobtainadditionalaccessoriesfrom

mostelectronicsstores.

NOTE

Using the IR Receiver

Thisallowsaremotecontrolsensortobeplaced

inacustomlocation.TheIRreceiverismade

withamagnet.Attachthemagneticsheettothe

desiredpositionontheproduct.Itisrecommended

toattachittothelocationillustratedinthefigure

below.
