Quick Start Guide

Use your phone for more than just talking

• Music Player with External Touch Pad

• CV

• 1.3 Megapixel Camera with Video Record

• Video ShareTM

TRAXQSG/AT&T MCDD0006205(2.0)

Optional Accessories

Stereo Headset USB Data Cable microSD™ Card

Vehicle Power Charger

Bluetooth® Headset

Accessories for productivity, convenience,

and fashion are available at att.com/wireless.

CE110

Getting to Know Your Phone

Visit att.com/DeviceSupport for more information.

Right

Soft

Key

Multitasking

Key

Power/End

Key

OK/Web Key

Clear

& Back

Key

Camera

Left

Soft

Key

Volume

Up/Down

Headset/

USB/

Charging

Port

Send Key

Navigation

Key

AT&T

Music Key

Camera/

Video Key

Music

Touch Pad

microSD™

Port

Playing Music

To listen to music that you have transferred to your phone,

follow these quick and easy steps:

Playing Music with the Flip Open

1. Press the Key, select Music Player (1), then

All Songs (1) or Playlists (2). Select a song or playlist.

2. Press to play/pause. Press up or down on the Navigation

Key to change the volume, and left or right to go to the

previous or next song.

3. Press the Left Soft Key for Minimize to access other phone

functionality while music is playing.

Playing Music with the Flip Closed

1. Press and hold either Volume Key and the touch pad will

light up to show that it’s active.

2. Tap the Music Touch Pad twice to go to the music player.

AT&T Mobile Music

AT&T Mobile Music provides the ultimate music experience with

the push of the music button. Listen to your favorite music,

watch the latest music videos, and stay in the know with music

news and more.

INTEGER JOB#:

JOB NAME:

CLIENT CODE: SIZE:

DATE:

NOTES:

CGM 20257.25.06 DAT MS P 0306 0456

MUSIC UMBRELLA DATAICON

FINAL ART

Transfer and listen to your music with the integrated

Music Player

INTEGER JOB#:

JOB NAME:

CLIENT CODE: SIZE:

DATE:

NOTES:

CGM 20257.25.06 DAT MS P 0306 0456

MUSIC UMBRELLA DATAICON

FINAL ART

Stream dozens of commercial-free music stations

with XM Radio

INTEGER JOB#:

JOB NAME:

CLIENT CODE: SIZE:

DATE:

NOTES:

CGM 20257.25.06 DAT MS P 0306 0456

MUSIC UMBRELLA DATAICON

FINAL ART

Watch the latest music videos by clicking on

Music Videos

INTEGER JOB#:

JOB NAME:

CLIENT CODE: SIZE:

DATE:

NOTES:

CGM 20257.25.06 DAT MS P 0306 0456

MUSIC UMBRELLA DATAICON

FINAL ART

Personalize with ringtones and Answer Tones™ under

Shop Music

INTEGER JOB#:

JOB NAME:

CLIENT CODE: SIZE:

DATE:

NOTES:

CGM 20257.25.06 DAT MS P 0306 0456

MUSIC UMBRELLA DATAICON

FINAL ART

Instantly ID the title and artist of a song with

MusicID

INTEGER JOB#:

JOB NAME:

CLIENT CODE: SIZE:

DATE:

NOTES:

CGM 20257.25.06 DAT MS P 0306 0456

MUSIC UMBRELLA DATAICON

FINAL ART

Get the latest music news, charts, and concert info

from The Buzz

CV brings your phone to life. Watch news, sports, weather, and

entertainment clips on the go.

1. From standby mode, press the Right Soft Key for Options,

and press to connect.

2. Once connected, select the program or category you wish to

view and press .

Personalize your CV Home Page

1. From the CV home page, select EDIT and press .

2. Select the content you would like added or deleted

from your CV home page and press .

Note: Parental Controls available. See box insert for details.

Access to CV requires a MEdia™ Max plan.

Taking a Picture/Recording a Video

Capture everything around you in vivid detail via the

1.3 megapixel camera with video. Then share it instantly

with friends via multimedia messaging.

Taking a Picture

1. Short press the side Key.

2. Press left or right on the Navigation Key to adjust brightness

and up or down for zoom.* Press the Right Soft Key to adjust

other options.

3. Press to take the picture. Press the Left Soft Key to send.

Recording a Video

1. To record a video, press and hold the side Key.

2. Select Record Video (2). Adjust video settings as above.

3. Press to start and stop recording. Press the Left Soft Key

to send.

Note: To use the camera with the flip closed, short press the

Key for camera or long press for video. Press again to take

the photo or to start/stop a video. Pictures and video clips are

saved under My Stuff (7) > Graphics (4) or Video (5).

*Camera resolution of

1280 x 960 does not

support zoom function.

Transferring Music

Listen to music on your phone. Transfer your favorite tunes

today!

1. You must convert your music to MP3, WMA, AAC, AAC+, or

eAAC+ format using the media player of your choice.

2. Insert the microSD™ card* (gold contacts facing up) into the

slot on the right side of the phone.

3. Power on the phone and connect it to your PC using a USB

data cable.*

4. Once the Media Player screen pops up on your PC, click OK.

5. From within the Windows Media Player application, songs will

populate on the left side of the screen.

6. CU575 Music Sync Player should be the destination

location for the songs on the right side of the screen.

7. Check or drag** the songs you want to transfer, and click the

Start Sync button to sync the selected songs to trax.

8. When finished, press the End Key on the phone, select Yes (1),

and disconnect the USB cable.

**Steps may vary depending on Windows Media Player version.

Warning! Do not disconnect phone while file transfer is in progress.

Note: The number of files you

can store depends on the size

and format of the memory card.

**microSD card and USB data cable sold separately; go to

att.com/wireless.

Requirement:

Windows Media®

Player 10 or higher.

Not compatible with

Mac OS or iTunes.
