GS390GS390 User Guide

Some of the contents in this

manual may differ from your phone

depending on the software of the

phone or your service provider.

Part 15.21 statement

" Change or Modifications that are not expressly approved by the manufacturer could void

the user's authority to operate the equipment. “

Part 15.105 statement

This equipment has been tested and found to comply with the limits for a class B digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in

a residential installation. This equipment generates uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful interference or

television reception, which can be determined by turning the equipment off and on, the user

is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

Part 15 Class B Compliance

This device and its accessories comply with part15 of FCC rules.

Operation is subject to the following two conditions:

(1) This device & its accessories may not cause harmful interference.

(2) This device & its accessories must accept any interference received,

including interference that may cause undesired operation.

Body-worn Operation

This device has been tested for typical body-worn operations

with the distance of 0.79inches (2.0cm) from the user’s body.

To comply with FCC RF exposure requirements, a minimum separation distance

of 0.79inches(2.0cm) must be maintained from the user's body.

Additionally, Belt clips, holsters & other body-worn accessories may not contain

metallic components.

LG GS390 | User Guide

Your Phone

Phone Components

1. Handsfree or Stereo earphone

connector

2. Earpiece: Lets you hear the caller

and automated prompts.

Rea

Exte

lens

SIM

Batt

3. Main LCD: Displays phone status

icons, menu items, web items,

web information, pictures and

more in full color. You can select

menu items by touching the

corresponding icons on the

touchpad.

4. SEND key: Press this key in

standby mode to quickly access

the most recent, missed, dialed

and received calls.

5. END / Power: Ends or rejects a call.

Turns the phone on/off. Press once

to return to the standby screen.

6. Multi-tasking key

7. Side volume keys

• When on the Standby screen:

Ring tone and key tone volume.

• During a call: Earpiece volume.

• When playing background

music: Allows you to change the

music volume.

8. microSD™ memory card socket

9. Charger, cable

10. Lock/Unlock key

11. Camera key: Press to start the

Camera function. Press and

hold to start the Video record

function.

Rear View

External camera

lens

SIM Card Tray

Battery

Battery cover

tus

call.

once

me.

the

LG GS390 | User Guide

Installing the SIM Card and Battery

1 Remove the battery cover

Slide the battery cover towards

the bottom of the phone and

away from it.

2 Remove the battery

Hold the top edge of the battery

and using your fingernail, lift

the battery from the battery

compartment.

3 Install the SIM card

Slide the SIM card into the SIM

card holder making sure that the

gold contact area on the card is

facing downwards. Please make

sure the battery is removed from

the phone before installing the

SIM card. To remove the SIM card,

pull it gently outwards.

4 In

5 Ch

“B

Getting Started

WARNING: Do not remove

the battery when the phone is

switched on, as this may damage

the phone.

the

ard,

4 Install the battery

Insert the top of the battery first

into the top edge of the battery

compartment. Ensure that the

battery contacts align with the

terminals on the phone. Press the

bottom of the battery down until

it clips into place.

5 Charging your phone

Lift the charger port cover on the

top side of your LG GS390. Insert

the charger connector to the

phone (‘B’ side of the connector

has to be facing up when

connecting to the phone) and

then plug into the wall socket.

Your LG GS390 will need to be

charged until a message reading

“Battery full. Please unplug

charger to save energy.” appears

on the screen.

Important! : You should insert the

battery before charging.

WARNING: Use of

unauthorized accessories could

damage your phone and void your

warranty.To use the travel charger

provided with your phone:

LG GS390 | User Guide

Installing a memory card

You can expand the memory

available on your phone by using

a microSD™ memory card. The LG

GS390 will support up to a 16 GB

microSD™ memory card.

Tip: A memory card is an optional

accessory.

1Lift the memory card cover and

insert a microSD™ card with

the gold contact area facing

downwards. Close the memory

card cover so that it clicks shut.

Note: If your memory card has

existing content it will automatically

be filed in the correct folder.

For example, videos will be

accessible from the Videos folder.

If your memory card has protected

content (i.e. content such as songs

or graphics with Digital Rights

Management copywriting loaded

from another device), it will not

work. You will need to reformat the

memory card prior to using it with

this device.

On-

The t

that

ICO

INDIC

Getting Started

ally

On-Screen Icons

The table below describes various display indicators or icons

that appear on the phone's display screen.

ICON/

INDICATOR DESCRIPTION

Multitasking

Network signal strength

(number of bars will vary)

No network signal

Battery empty

New text message

New email

An alarm is set

Normal profile in use

Silent profile in use

3G available

Bluetooth

is active

The browser is active

Vibration mode

ICON/

INDICATOR DESCRIPTION

Speakerphone

Call in Progress

Voicemail

Battery Full

Battery Charging

Flight Mode

LG GS390 | User Guide

Touch Calibration

Set your touch screen for ease of

use. Touch and press the ‘+’

markers to calibrate the screen.

•Once you’ve finished calibrating

your screen, Save the settings.

Note : To reset the touch calibration,

touch , and the tab. Touch

, and choose Touch Calibration.

Sta

Afte

batte

you

scree
