LG LG800G Manuel utilisateur

User Guide

LG800G

P/N :

MFL67107201 (1.0)

www.lg.com

E N G L I S H

ESPAÑOL

(Printed in China)

LG800G_TRF_Cover_1.0_0211.indd 1 2011.2.25 11:50:39 AM

Bluetooth QD ID B016850

LG800G_TRF_Cover_1.0_0211.indd 2 2011.2.25 11:50:40 AM

LG800G User Guide - English

Some of the contents in this manual may differ from your phone

depending on the software of the phone or your service provider.

LG800G_ENG_FULL_1.0_110225.indd 1 2011.2.25 11:17:30 AM

Installing the SIM Card

When you subscribe to a

cellular network, you are

provided with a SIM card loaded

with your subscription details,

such as your PIN, any optional

services available and many

others.

Important!

The SIM card can be easily

damaged by scratches or

bending, so be careful when

handling, inserting or removing

the card. Keep all SIM cards out

of the reach of small children.

Installing the SIM card and the handset battery

LG800G_ENG_FULL_1.0_110225.indd 2 2011.2.25 11:17:31 AM

2 31

4 5 6

Illustrations

Always switch the device off

and disconnect the charger

before removing the battery.

1Remove the back cover by

sliding it downwards.

2Lift the battery up and

remove it using the fingertip

cutout near the bottom of

the battery compartment.

3Insert the SIM card. Make

sure the gold area is facing

downwards.

4Align the battery contacts

with the phone terminals

near the top of the battery

compartment and insert the

battery into place.

5Align the back cover and

slide it upwards until it clicks

into place.

6 Connect the small end of

the charger to the phone

and the other end to a wall

outlet.

LG800G_ENG_FULL_1.0_110225.indd 3 2011.2.25 11:17:36 AM

Phone Components

Earpiece

Lets you listen to the caller or

automated prompts.

Call key

Dials a phone number and answers

incoming calls.

End key

Ends a call or returns to the Home

screen.

Clear key

Go back to a previous screen.

Volume keys

•When the screen

is at the Home

screen: Controls

the ring tone and

touch tone volume.

•During a call:

Controls the

earpiece volume.

•Down volume key:

Press and hold to

activate/ deactivate

Silent mode.

Handsfree or Stereo

earphone connector

Power/Lock key

•Short press to turn on/off the

screen.

•Long press for power on/off.

LG800G_ENG_FULL_1.0_110225.indd 4 2011.2.25 11:17:38 AM

Phone Components

Touch screen tips

•To select an item, touch the

center of the icon.

•Do not press too hard. The

touchscreen is sensitive

enough to pick up a light, firm

touch.

•Use the tip of your finger to

touch the option you require.

Be careful not to touch any

other keys.

•Whenever your LG800G is not

in use, it will return to the lock

screen.

Control the touch screen

The controls on the LG800G

touch screen change

dynamically depending on the

task you are carrying out.

Home Screen Shortcuts

Call Opens the dial pad

and allows you to make

calls.

Contacts Opens your list

of contacts.

Messages Opens the

Messages menu.

Menu Opens the phone’s

main menu.

Using your touch screen

LG800G_ENG_FULL_1.0_110225.indd 5 2011.2.25 11:17:39 AM

Screen 1

Prepaid

Contacts

Messages

Voice Call

Recent Calls

Camera

Gallery

Music

Games & Apps

Alarms

Browser

Settings

Screen 2

My Stuff

Voice Recorder

Calendar

Tasks

Memo

Profiles

Bluetooth

Calculator

World Clock

Stopwatch

Unit Converter

Menu Map

Note

To switch between the screens,

swipe your finger from right to

left and vice versa.

LG800G_ENG_FULL_1.0_110225.indd 6 2011.2.25 11:17:39 AM

Calls

Making a Call

1Touch to open the

keypad.

2Enter the number using the

keypad.

3Touch to initiate the call.

TIP! To enter + for making

an international call, press

and hold 0+.

Press the Power/Lock key to

lock the touchscreen to prevent

calls being made by mistake.

Making a call from your

contacts

1From the Home screen,

touch to open Contacts.

2Touch the Search field at the

top of the screen and enter

the first few letters of the

contact you would like to call

using the keypad.

3From the filtered list, touch

the Call icon next to

the contact you want to call.

The call will use the default

number if there is more than

one for that contact.

Touch the contact name and

select the number to use

if there is more than one

number available. You can

also touch to initiate the

call to the default number.

Answering and rejecting

a call

When your phone rings, press

key to answer the call.

To mute the ringing, touch the

Silent tab in the incoming call

screen. This is useful if you

forgot to change your profile

to Silent for a meeting. Touch

the Reject tab to reject an

incoming call in the incoming

call screen.

LG800G_ENG_FULL_1.0_110225.indd 7 2011.2.25 11:17:39 AM

Changing the Common

Settings

1Touch , then Settings

and Call.

2Touch Common Settings.

The following settings are

available:

•Call Reject - Slide the switch

left for ON. You can touch

Reject List to choose All

Calls, Contacts, Groups,

All Unknown Callers and

All Unknown Numbers and

reject those type of calls.

•Send My Number - Choose

whether to display your

number on an outgoing call.

•Auto-Redial - Slide the

switch left for ON or right

for OFF.

•Answer Mode

Press Send Key: Allows you

to only answer an incoming

call by pressing the key.

Press Any Key: Allows you to

answer an incoming call by

pressing any key, except the

key and Volume keys.

•Minute Minder - Slide the

switch left to ON to hear a

tone every minute during

a call.

•BT Answer Mode

To Answered Device: Allows

you to answer a call using

an earpiece or a Bluetooth

headset. You can press

key to answer a call using an

earpiece or you can press the

answer key on a Bluetooth

headset.

Always to Handsfree: Allows

you to answer a call using a

Bluetooth headset.

Always to Handset: Allows

you to answer a call using the

phone.

•Save New Number - Select

ON or OFF to prompt you to

save a number when you

receive a call from a number

not stored in your contacts or

when a new number is dialed.

LG800G_ENG_FULL_1.0_110225.indd 8 2011.2.25 11:17:40 AM
