LG GD880 Manuel utilisateur

GD880 User Guide

Some of the contents in this manual may

differ from your phone depending on

the software of the phone or your service

provider.

Part 15.21 statement

" Change or Modifications that are not expressly approved by the manufacturer could void

the user's authority to operate the equipment. “

Part 15.105 statement

This equipment has been tested and found to comply with the limits for a class B digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in

a residential installation. This equipment generates uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful interference or

television reception, which can be determined by turning the equipment off and on, the user

is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

This device is not intended for sale in the USA.

Part 15 Class B Compliance

This device and its accessories comply with part15 of FCC rules.

Operation is subject to the following two conditions:

(1) This device & its accessories may not cause harmful interference.

(2) This device & its accessories must accept any interference received,

including interference that may cause undesired operation.

Body-worn Operation

This device has been tested for typical body-worn operations

with the distance of 2.0cm from the user’s body.

To comply with FCC RF exposure requirements, a minimum separation distance

of 2.0cm must be maintained from the user's body.

Additionally, Belt clips, holsters & other body-worn accessories may not contain

metallic components.

LG GD880 | User Guide

Getting to know your phone

Smart key

• Accepts and ends a call.

• Goes to home screen directly.

Power/Lock key

• Long press for power on/off.

• Short press to turn on/off the screen.

WARNING: Placing a heavy object on the phone or sitting on it

while it is in your pocket can damage the phone’s LCD and touch screen

functionality.

Side keys

• When the screen is at the

Home screen: Ring tone

and key tone volume.

• During a call: Earpiece

volume.

Charger, cable and

handsfree connector

Camera/Multi-tasking key

• Long press to use the

camera.

• Short press to use multi-

tasking.

External camera lens

MicroSD Card Slot

SIM Card Tray

Battery

Battery cover

Open view

LG GD880 | User Guide

Installing the SIM and battery

1 Remove the battery cover

Slide the battery cover towards the

bottom of the phone and away

from it.

2Install the SIM card

Slide the SIM card into the SIM card

holder making sure that the gold

contact area on the card is facing

downwards. Please make sure the

battery is removed from the phone

before installing the SIM card. To

remove the SIM card, pull it gently

outwards.

3Install the battery

Insert the left side of the battery

into the top edge of the battery

compartment first.

Ensure that the battery contacts

align with the phone’s terminals.

Press the right side of the battery

until down it clicks into place.

WARNING: Do not remove

the battery when the phone is

switched on, as this may damage

the phone.

WARNING: Do not use your

ngernail to remove the battery.

Charging your phone

Remove the charger socket cover

on the side of your GD880. Connect

the Travel Adapter (Charger) and the

included USB cable. Connect the USB

cable into the phone and plug it into

a power socket. Your GD880 must

be charged until the“Battery full“

message appears on the screen.

NOTE: The battery must be fully

charged initially to improve battery

lifetime. Disregard the first“Battery

full” message and keep the phone on

charge overnight.

PCB-100 Solar Cell battery cover sold

separately, available from selected

retailers or from

www.lge.co.uk/mobileshop

* It may not be available in all shops based upon

availability

LG GD880 | User Guide

Memory card

Installing a memory card

You can expand the memory space

on your phone by using a MicroSD

memory card.

NOTE: A memory card is an optional

accessory.

Remove the battery cover.

Push the microSD card slot to

release lock.

Flip up the slot.

Put the microSD card on the card

tray. Make sure the gold colour

contact area is facing downwards.

Flip down then push the slot to

lock.

Replace the cover.

Formatting the memory card

Your memory card may already be

formatted. If it isn’t, you will need to

format it before you can start to use it.

From the Home screen select ,

then Phone settings in SETTINGS

tab.

Touch Memory info then choose

External memory.

Touch Format and then confirm

your choice.

Enter the password, if one is set.

Your card will then be formatted

and ready to use.

NOTE: If there is existing content

on your memory card, the folder

structure may be different after

formatting since all files will have

been deleted.

COMMUNICATION

Contacts

Recent history

Messaging

E-mail

Dialling

Contact search

Speed dials

New message

Menu map

Touch in the Home screen to open a Top menu. From here you can access

further menus by scrolling through the icons:

COMMUNICATION, ENTERTAINMENT, UTILITIES and SETTINGS.

UTILITIES

Browser

Google search

Alarms

Organiser

Memo

Voice recorder

Tools

Drawing panel

SETTINGS

Profiles

Screen settings

Phone settings

Call settings

Bluetooth

Touch settings

Connectivity

Message settings

ENTERTAINMENT

Camera

Gallery

My stuff

Music

Games & Apps

FM radio

Video camera

Muvee studio

LG GD880 | User Guide

Using your touch screen

Touch screen tips

• To select an item, touch the centre

of the icon.

• Do not press too hard. The

touchscreen is sensitive enough to

pick up a light, firm touch.

• Use the tip of your finger to touch

the option you require. Be careful

not to touch any other keys.

• Whenever your GD880 is not in use,

it will return to the lock screen.

Control the touch screen

The controls on the GD880 touch

screen change dynamically

depending on the task you are

carrying out.

Opening Applications

To open any application, simply touch

its icon.

Scrolling

Drag from side to side to scroll.

On some screens, such as the call

history list, you can also scroll up or

down.
