BL20/BL42 User Manual

This document is the user guide for the LG BL20/BL42 3G

Video Mobile Phone. All rights for this document are

reserved by LG Electronics. Copying, modifying and

distributing this document without the consent of LG

Electronics are prohibited.

Disposal of your old appliance

1. When this crossed-out wheeled bin symbol is attached to a product it means the

product is covered by the European Directive 2002/96/CE.

2. All electrical and electronic products should be disposed of separately from the

municipal waste stream via designated collection facilities appointed by the

government or the local authorities.

3. The correct disposal of your old appliance will help prevent potential negative

consequences for the environment and human health.

4. For more detailed information about disposal of your old appliance, please contact

your city office, waste disposal service or the shop where you purchased the product.

Part 15.21 statement

" Change or Modifications that are not expressly approved by the manufacturer could void

the user's authority to operate the equipment. “

Part 15.105 statement

This equipment has been tested and found to comply with the limits for a class B digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in

a residential installation. This equipment generates uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful interference or

television reception, which can be determined by turning the equipment off and on, the user

is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

This device is not intended for sale in the USA.

Part 15 Class B Compliance

This device and its accessories comply with part15 of FCC rules.

Operation is subject to the following two conditions:

(1) This device & its accessories may not cause harmful interference.

(2) This device & its accessories must accept any interference received,

including interference that may cause undesired operation.

Body-worn Operation

This device has been tested for typical body-worn operations

with the distance of 0.79inches (2.0cm) from the user’s body.

To comply with FCC RF exposure requirements, a minimum separation distance

of 0.79inches(2.0cm) must be maintained from the user's body.

Additionally, Belt clips, holsters & other body-worn accessories may not contain

metallic components.

Parts of the phone

Open view

BL20/BL42 Features

BL42 Features

Earpiece

OK (Conrm) key

Navigation keys

vIn standby mode:

Profiles popup

Write Text message

Quick menu

Contact list

vIn menu: Navigates

menus.

Multitasking key

VGA camera

LCD screen

vTop: Icons showing signal

strength, battery level and

various other functions

vBottom: Soft key indications

Camera Hot key

vGo to Camera preview

Alpha numeric keys

vIn standby mode:

Input numbers to dial.

Hold down:

for international calls.

to dial voice mail centre.

for speed dials.

vIn editing mode: Enter

numbers & characters.

BL42 Features

Clear key

You can delete a letter or go back to

previous menu.

Left soft key/ Right soft key

Performs the function indicated at the

bottom of the display.

Send key

vDials a phone number and answers a call.

vIn standby mode: Shows a history of calls

made, received, and missed.

Call End key

vYou can end a call.

vYou can go back to standby mode by

pressing this key when activating the

menu.

Right side view Left side view

BL42 Features

Headset/Charger/

Cable connector

Side keys

Handstrap Hole

microSD card slot

BL42 Features

Rear view

Battery cover

Battery

External

camera lens

USIM card

socket

Getting Started

Installing the USIM card

and battery

1. Installing the USIM card.

Your USIM card contains your phone

number, service details and contacts

and must be inserted into your handset.

If your USIM card is removed then your

handset becomes unusable (except

for emergency calls) until a valid one is

inserted. Always disconnect the charger

and other accessories from your handset

before inserting and removing your USIM

card. Slide the USIM card into the USIM

card holder. Make sure that the USIM card

is properly inserted and the gold contact

area on the card is facing downwards. To

remove the USIM card, press down lightly

and pull it in the reverse direction.

To insert the USIM card

To remove the USIM card

Note

vThe metal contact of the USIM card

can easily be damaged by scratches.

Pay special attention to the USIM

card while handling. Follow the

instructions supplied with the USIM

card.

vAfter removing the battery, insert

USIM card.

Getting Started

2. Installing the battery.

Slide the battery upwards until it snaps

back into place.

3. To remove the battery.

Turn the power off. (If the power is left on,

there is a chance you could lose the stored

telephone numbers and messages.)

Press and hold down the battery release

button and slide the battery down.

Getting Started

Charging the Battery

Before connecting the travel adapter to the

phone you must first install the battery.

1. With the arrow facing you as shown in

the diagram push the plug on the battery

adapter into the socket on the right side

of the phone until it clicks into place.

2. Connect the other end of the travel

adapter to the mains socket.

Note

vOnly use the charger included in the

box.

3. The moving bars on the battery icon will

stop after charging is complete.

4. Ensure the battery is fully charged before

using the phone for the first time.

CAUTION!

• Do not force the connector as this may

damage the phone and/or the travel

adapter.

• If you use the battery pack charger when

abroad, use an attachment plug adaptor

for the proper configuration.

• Do not remove your battery or the USIM

card while charging.

WARNING!

• Unplug the power cord and charger

during lightning storms to avoid electric

shock or fire.

• Make sure that no sharp-edged items such

as animal teeth or nails, come into contact

with the battery. This may cause a fire.
