Connection Guide

Page 1 of 2

Connection Guide

Note: For local printing, you must install the printer software (drivers) before connecting the USB cable.

Installing printer and software for local printing using Windows

1 Launch the drivers CD that shipped with the printer.

2ClickInstall Printer and Software.

Note: Some Windows operating systems require that you have administrative access to install printer

software (drivers) on the computer.

3ClickAgree to accept the license agreement.

4 Select Suggested, and then click Next.

The Suggested option is the default installation for local setup. If you need to install utilities, change

settings, or customize device drivers, select Custom. Follow the instructions on the computer screen.

5 Select Local Attach, and click Finish.

Note: It may take a few minutes for the drivers to completely load.

6 Close the drivers CD installer application.

7 Connect the USB cable. Be sure to match the USB symbol on the cable to the USB symbol on the printer.

Note: Only Windows 98 SE, Windows Me, Windows 2000, Windows XP, and Windows Server 2003

operating systems support USB connections. Some UNIX, Linux, and Macintosh computers also

support USB connections. See the computer operating system documentation to see if your system

supports USB.

8 Plug one end of the printer power cord into the socket at the back of the printer and the other end into a

properly grounded outlet.

9 Turn on the printer.

Plugging in the USB cable and turning on the printer prompts the Windows operating system to run the plug

and play screens to install the printer as a new hardware device. The installation of printer software (drivers)

done in step 1 should satisfy the plug and play requirements. When plug and play is finished, a printer

object will appear in your Printers folder.

Note: After the printer completes its internal tests, the Ready message indicates that the printer is ready

to receive jobs. If you see a message other than Ready on the display, see the publications CD for

instructions on clearing the message.

10 Send a test page to print.

Using a parallel or serial cable

For detailed instructions, see the User Guide on the publications CD that shipped with the printer.

Local printing with Mac or UNIX/Linux

For detailed instructions, see the User Guide on the Publications CD that shipped with the printer.

Connection Guide

Page 2 of 2

Installing printer and software for network printing using Windows

1 Make sure the printer is turned off and unplugged.

2 Connect the printer to a LAN drop or hub using an ethernet cable that is compatible with your network.

3 Plug one end of the printer power cord into the socket at the back of the printer and the other end into a

properly grounded outlet.

4 Turn on the printer.

Note: After the printer completes its internal tests, the Ready message indicates that the printer is ready

to receive jobs. If you see a message other than Ready on the display, see the publications CD for

instructions on clearing the message.

5 Go to a computer on the same network, and launch the drivers CD that shipped with the printer.

6ClickInstall Printer and Software.

7ClickAgree to accept the license agreement.

8 Select Suggested, and then click Next.

9 Select Network Attach, and then click Next.

10 Select your printer model from the list, and then click Next.

11 Select your printer port from the list, and then click Finish to complete the installation. A printer object is

created in the Printers folder on the computer.

If your printer port is not listed, click Add Port. Enter the information requested to create a new printer port.

Select the option to create an Enhanced TCP/IP Network Port. Other port options will not give you full

functionality.

12 Send a test page to print.

Other network cabling options

The following may also be available as network options for the printer. More information is available in the User

Guide on the publications CD that shipped with the printer.

•Fiber optic internal print servers

•Ethernet internal print servers

•Wireless internal print servers

•Ethernet external print servers

•Wireless external print servers

Detailed instructions for installation are shipped with the product.

Network printing using Mac, UNIX/Linux, or NetWare

For information about this support, see the User Guide on the publications CD that shipped with the printer.

You can find some additional information on the drivers CD that shipped with the printer. Launch the drivers CD,

and click View Documentation.

Information guide

Page 1 of 1

Information guide

There are numerous publications available to help you

understand the printer and its functions.

Help Menu pages

There are Help Menu pages resident in the printer.

Select to print each individually, or select Print All

to print all of them.

Setup sheet

The Setup sheet packaged with the printer provides

information about setting up the printer and its options.

Publications CD

The publications CD which was shipped with your

printer contains a User’s Guide, Setup sheet, Menus

and Messages Guide, and a copy of the Help Menu

pages.

The User’s Guide provides information about loading

media, ordering supplies, troubleshooting, clearing

jams, and removing options. It also includes

administrative support information.

The Menus and Messages Guide provides information

to change the printer settings. It describes the menus

available, the menu items under each menu, and the

values available.

Lexmark’s Web site

Copies of the User’s Guide, Setup sheet, Menus and

Messages Guide, and Help Menu pages are available

on Lexmark’s Web site at www.lexmark.com.

Drivers CD

The drivers CD which was shipped with your printer

contains the necessary printer drivers to get the printer

up and running. It may also contain printer utilities,

screen fonts, and additional documentation.

Other languages

The User’s Guide, Setup sheet, Menus and Messages

Guide and Help Menu pages are also available in other

languages on the publications CD.

Menu Item: Use it to:

Print All Print all of the guides

Information Guide

(this page)

Locate additional information

Print Quality Guide Resolve print quality and

troubleshooting issues

Printing Guide Load media into the printer

Supplies Guide Order supplies

Media Guide See what types of media are

supported by the printer

Print Defects Determine which part may

be causing a repetitive

defect

Menu Map View all menus and menu

items available

Connection Guide Connect the printer as a

local or network printer

Moving Guide Safely move the printer

Media guide

Page 1 of 2

Media guide

The printer supports the following media sizes. Select custom sizes up to the maximum specified for the Universal

setting.

Legend: ✓— supported ✘— unsupported

Media size Dimensions 500-sheet trays Multipurpose

feeder 850+1150-sheet

dual input drawer

A3 297 x 420 mm

(11.7 x 16.5 in.)

✓✓✘

A4 210 x 297 mm

(8.27 x 11.7 in.)

✓✓✓

A5* 148 x 210 mm

(5.83 x 8.27 in.)

✓✓✘

JIS B4 257 x 364 mm

(10.1 x 14.3 in.)

✓✓✘

JIS B5* 182 x 257 mm

(7.17 x 10.1 in.)

✓✓✓

Letter 215.9 x 279.4 mm

(8.5 x 11 in.)

✓✓✓

Legal 215.9 x 355.6 mm

(8.5 x 14 in.)

✓✓✘

Executive 184.2 x 266.7 mm

(7.25 x 10.5 in.)

✓✓✓

Folio 216 x 330 mm

(8.5 x 13 in.)

✓✓✘

Statement 139.7 x 215.9 mm

(5.5 x 8.5 in.)

✓✓✘

Tabloid 279 x 432 mm

(11.0 x 17.0 in.)

✓✓✘

Universal** 98.4 x 89.0 mm to

297.0 x 431.8 mm

(3.9 x 3.5 in. to 11.7 x 17.0 in.)

✓✓✘

7 ¾ Envelope

(Monarch) 98.4 x 190.5 mm

(3.875 x 7.5 in.)

✘✓✘

Com 10

Envelope 104.8 x 241.3 mm

(4.12 x 9.5 in.)

✘✓✘

DL Envelope 110 x 220 mm

(4.33 x 8.66 in.)

✘✓✘

C5 Envelope 162 x 229 mm

(6.38 x 9.01 in.)

✘✓✘

Other

Envelope 98.4 x 89.0 mm to

297.0 x 431.8 mm

(3.9 x 3.5 in. to 11.7 x 17.0 in.)

✘✓✘

*This size does not appear in the Paper Size menu until Auto Size Sensing is changed. See the User’s Guide for more information.

** This size setting formats the page for 297.0 x 431.8 mm (11.7 x 17.0 in.) unless the size is specified by the software application.

Media guide

Page 2 of 2

Storing media

Use the following guidelines for proper media storage. These help avoid media feeding problems and uneven print

quality:

• For best results, store media in an environment where the temperature is approximately 21°C (70°F) and

the relative humidity is 40%.

• Store cartons of media on a pallet or shelf, rather than directly on the floor.

• When storing individual packages of media out of the original carton, make sure they rest on a flat surface

so the edges do not buckle or curl.

• Do not place anything on top of the media packages.

Avoiding jams hints

The following hints can help avoid jams:

• Use only recommended paper or specialty media (referred to as media).

• Do not overload the media sources. Make sure the stack height does not exceed the maximum height

indicated by the load line labels in the sources.

• Do not load wrinkled, creased, damp, or curled media.

• Flex, fan, and straighten media before you load it.

• Do not use media that has been cut or trimmed by hand.

• Do not mix media sizes, weights, or types in the same media source.

• Make sure the recommended print side is face-up when loading all trays for simplex (single-sided) printing.

• Keep media stored in an acceptable environment. See “Storing media”.

• Do not remove trays during a print job.

• Push all trays in firmly after loading them.

• Make sure the guides in the trays are properly positioned for the size of media loaded. Make sure the guides

are not placed too tightly against the stack of media.

• Make sure all cables that connect to the printer are correctly attached. See the Setup sheet for more

information.

• If a jam occurs, clear the entire media path. See the User’s Guide for information on the media path.

Menu map

Page 1 of 1

Menu map

A number of menus are available on the operator panel to make it easy to change printer settings. The following

menu map shows the menus and menu items available. For more information about menu items, see the Menus

and Messages Guide on the publications CD. Some menu items may not be available based on the printer model

or options installed.

Understanding the operator panel

The operator panel consists of these items:

• 160 x 64 character liquid crystal display (LCD) capable of showing text and graphics

• Eight buttons (Back, Menu, Stop, Select, <, >, ∧, and ∨)

• Indicator light

• USB port

For more information on the operator panel, see the User’s Guide on the publications CD.

Help

Print All

Print Quality

Printing Guide

Media Guide

Print Defects

Menu Map

Information Guide

Connection Guide

Moving Guide

Paper Menu

Default Source

Paper Size/Type

Configure MP

Substitute Size

Paper Texture

Paper Loading

Custom Types

Universal Setup

Bin Setup

Reports

Menu Settings Page

Device Statistics

Network Setup Page

Network [x] Setup

Page

Profiles List

Print Quick Ref

Netware Setup Page

Print Fonts

Print Directory

Print Demo

Security

Max Invalid PIN

Job Expiration

Defaults

Setup Menu

Finishing Menu

Quality Menu

Utilities Menu

PDF Menu

PostScript Menu

PCL Emul Menu

PPDS Menu

HTML Menu

Image Menu

Network/Ports

TCP/IP

IPv6

Standard Network

Network [x]

Standard USB

USB [x]

Front USB

Parallel

Parallel [x]

Serial

Serial [x]

Netware

AppleTalk

LexLink

BackMenu

Stop Navigation buttons Numeric pad

Display panel

Indicator light

USB port Select button

Moving the printer

Page 1 of 1

Moving the printer

Follow these guidelines to move the printer to another location.

CAUTION: The base printer weighs 49 kg (108 lb). It requires at least two (2) people to lift it safely. Use the

printer handholds to lift it, and make sure your fingers are not under the printer when you set it down.

CAUTION: Follow these guidelines to avoid injuring yourself or damaging the printer:

• Always use at least two people to lift the printer.

• Always turn off the printer using the power switch before moving it.

• Disconnect the power cord from the wall before disconnecting it from the printer.

• Disconnect all cords and cables from the printer before moving it.

• Remove all printer options before moving the printer. Place the options in the original packaging.

Note: Damage to the printer caused by improper moving is not covered by the printer warranty.

Moving the printer and options to another location

When the optional 500-sheet trays or the 850+1150-sheet dual input drawer is attached, the printer can be rolled

along a flat surface, as these options have casters on the bottom. However, if the printer must be moved over an

uneven surface, it should first be lifted away from these options prior to moving.

The printer and options can be safely moved to another location by following these precautions:

• Keep the printer in an upright position.

• Any cart used to move the printer must have a surface able to support the full footprint of the printer. Any

cart used to move the options must have a surface able to support the dimensions of the options.

• Severe jarring movements may cause damage to the printer and options, and must be avoided.

Printing guide

Page 1 of 4

Printing guide

Get the most from the printer by properly loading the trays, and setting the types and sizes for media.

Loading paper

General guidelines

• Do not overload the media sources.

• Make sure the stack height does not exceed the maximum height indicated by the labels on the guides.

Overloading may cause jams.

• Never mix media types within a tray.

Loading 500-sheet trays

Do not remove trays while a job prints or while Busy blinks on the operator panel. Doing so may cause a jam.

1 Pull out the tray.

Printing guide

Page 2 of 4

2 Squeeze the side guide tab, and slide the guide to outside of the tray.

3 Squeeze the front guide tab and slide the guide to the correct position for the size paper you are loading.

4 Flex the sheets back and forth to loosen them, then fan them. Do not fold or crease the paper. Straighten

the edges on a level surface.

5 Load paper in the tray with the print side up.

Note: For information about loading paper in the short-edge feed position, see the User’s Guide.

Printing guide

Page 3 of 4

6 Squeeze the side guide tab, and slide the guide until it lightly rests against the edge of the paper.

7 Insert the tray into the printer.

For loading other sources, see “For more information” on page 4.

Setting the Paper Type and Paper Size

After setting the Paper Type and Paper Size to the correct values for the type and size used in the trays, then any

trays containing the same size and type are automatically linked by the printer.

Note: If the size of the media you are loading is the same size of the media previously loaded, do not

change the Paper Size setting.

To change the Paper Size and Paper Type setting:

1 Make sure the printer is on and the Ready message appears.

2 Press ∨until ✓appears beside Paper Menu, and then press ✓.

3 Press ∨until ✓appears beside Paper Type (or Paper Size), and then press ✓.

4 Press ∨until ✓appears beside Tray x Type (or Tray x Size), and then press ✓.

5 Press ∨to scroll through a list of possible paper types (or sizes) to locate the correct type or size. Make

sure the type or size is highlighted with ✓ beside it, and then press then press ✓. This saves this setting

as the new user default type or size setting.

The message Submitting Selection appears. The printer returns to the Ready state.

Autres manuels pour W840

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Lexmark Imprimante

Lexmark

Lexmark X6100 Manuel

Lexmark

Lexmark Optra K 1220 Manuel utilisateur

Lexmark

Lexmark 12N0008 - C 910 Color LED Printer Manuel utilisateur

Lexmark

Lexmark CS410 series Manuel utilisateur

Lexmark

Lexmark 22L0176 - C 770dn Color Laser Printer Manuel utilisateur

Lexmark

Lexmark Optra N 4040-FIN Manuel utilisateur

Lexmark

Lexmark X790 series Manuel utilisateur

Lexmark

Lexmark 5770 Photo Jetprinter Manuel utilisateur

Lexmark

Lexmark C925 Manuel utilisateur

Lexmark

Lexmark M1145 Manuel technique

Lexmark

Lexmark CS410 series Guide de configuration

Lexmark

Lexmark E320/E322 Fiche d'information produit

Lexmark

Lexmark S400 Series Manuel utilisateur

Lexmark

Lexmark CX730 Manuel utilisateur

Lexmark

Lexmark E260 Series Manuel utilisateur

Lexmark

Lexmark MX611 Series Manuel utilisateur

Lexmark

Lexmark MS710 Series Manuel utilisateur

Lexmark

Lexmark C950 Series Manuel utilisateur

Lexmark

Lexmark 250d - E B/W Laser Printer Manuel utilisateur

Lexmark

Lexmark X203N series Manuel

Lexmark

Lexmark MS00321 - X 738de Color Laser Manuel utilisateur

Lexmark

Lexmark 34S0309 - E 260dtn B/W Laser Printer Manuel

Lexmark

Lexmark MX810 Series Manuel utilisateur

Lexmark

Lexmark B2338 Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Canon

Canon i70 Series Manuel utilisateur

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Canon

Canon LASER SHOT LBP-1210 Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Canon

Canon PIXMA PRO-1 Series Manuel utilisateur

Canon

Canon PIXMA G3560 Guide de configuration

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Canon

Canon CLBR 460ps Manuel utilisateur

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

Canon

Canon imagePASS-A2 Manuel utilisateur

Canon

Canon S820D Manuel utilisateur

IRA3D

IRA3D POETRY4 Manuel utilisateur
