Print quality guide

Many print quality problems can be solved by replacing a supply or maintenance item that is approaching the end of its intended

life. Check the printer control panel for a message about a printer supply.

Print irregularities

Try one or more of the following:

LOAD PAPER FROM AFRESH PACKAGE

The paper may have absorbed moisture due to high humidity. Store paper in its original wrapper until you use it.

CHECK THE PAPER TYPE AND WEIGHT SETTINGS

Make sure the paper type and weight settings match the paper loaded in the tray or feeder:

1From the printer control panel Paper menu, check the Paper Type and Paper Weight settings.

2Before sending the print job, specify the correct paper type setting:

•For Windows users, specify the paper type from Print Properties.

•For Macintosh users, specify the paper type from the Print dialog.

AVOID TEXTURED PAPER WITH ROUGH FINISHES

MAKE SURE THERE IS NO DEFECTIVE PRINT CARTRIDGE

Replace the worn or defective print cartridge.

MAKE SURE THE TRANSFER BELT IS NOT DEFECTIVE

Replace the defective transfer belt. For more information, see the instruction sheet that came with the replacement part.

MAKE SURE THE FUSER IS NOT DEFECTIVE

Replace the defective fuser. For more information, see the instruction sheet that came with the replacement part.

Print quality guide

Page 1 of 10

Repeating defects appear on prints

Try one or more of the following:

REPLACE THE PRINT CARTRIDGE

Replace the print cartridge of the color with the repeating defect, if the print defects occur in the following instances:

•in every 37.7 mm (1.48 in.) of the page

•in every 41.6 mm (1.64 in.) of the page

•in every 42.7 mm (1.68 in.) of the page

•in every 94.3 mm (3.71 in.) of the page

REPLACE THE FUSER

Replace the fuser if print defects occur in the following instances:

•in every 95.0 mm (3.74 in.) of the page

•in every 146.7 mm (5.78 in.) of the page

Light colored line, white line, or incorrectly colored line appears on prints

ABCDE

Try one or more of the following:

MAKE SURE THERE IS NO DEFECTIVE PRINT CARTRIDGE

Replace the defective print cartridge.

MAKE SURE THE TRANSFER BELT IS NOT DEFECTIVE

Replace the defective transfer belt. For more information, see the instruction sheet that came with the replacement part.

Print quality guide

Page 2 of 10

Streaked horizontal lines appear on prints

ABCDE

Try one or more of the following:

SELECT ANOTHER TRAY OR FEEDER

•From the printer control panel Paper Menu, select Default Source.

•For Windows users, select the paper source from Print Properties.

•For Macintosh users, select the paper source from the Print dialog and pop-up menus.

MAKE SURE THERE IS NO WORN, DEFECTIVE, OR EMPTY PRINT CARTRIDGE

Replace the worn, defective, or empty print cartridge.

Uneven print density

ABCDE

MAKE SURE THERE IS NO DEFECTIVE OR WORN PRINT CARTRIDGE

Replace the worn or defective print cartridge.

Print is too dark

Try one or more of the following:

Print quality guide

Page 3 of 10

LOAD PAPER FROM AFRESH PACKAGE

The paper may have absorbed moisture due to high humidity. Store paper in its original wrapper until you use it.

AVOID TEXTURED PAPER WITH ROUGH FINISHES

CHECK THE PAPER TYPE SETTING

Make sure the Paper Type setting matches the paper loaded in the tray or feeder:

•From the printer control panel Paper menu, check the Paper Type setting.

•For Windows users, check this setting from Print Properties.

•For Macintosh users, check this setting from the Print dialog.

MAKE SURE THERE IS NO DEFECTIVE PRINT CARTRIDGE

Replace the defective print cartridge.

Print is too light

Try one or more of the following:

LOAD PAPER FROM AFRESH PACKAGE

The paper may have absorbed moisture from high humidity. Store paper in its original wrapper until you use it.

AVOID TEXTURED PAPER WITH ROUGH FINISHES

CHECK THE PAPER TYPE SETTING

Make sure the Paper Type setting matches the paper loaded in the tray or feeder:

•From the printer control panel Paper menu, check the Paper Type setting.

•For Windows users, check this setting from Print Properties.

•For Macintosh users, check this setting from the Print dialog.

Print quality guide

Page 4 of 10

MAKE SURE THE PRINT CARTRIDGE IS NOT LOW ON TONER

When 88.xx [color] cartridge low appears, make sure the toner is distributed evenly within the print cartridge.

1Remove the print cartridge.

Warning—Potential Damage: Be careful not to touch the photoconductor drum. Doing so may affect the print quality of

future print jobs.

2Firmly shake the cartridge side-to-side and front-to-back several times to redistribute the toner.

3Reinsert the print cartridge.

Note: If print quality does not improve, then replace the print cartridge.

If the problem continues, then the printer may need to be serviced. For more information, contact customer support.

MAKE SURE THERE IS NO DEFECTIVE PRINT CARTRIDGE

Replace the defective print cartridge.

Transparency print quality is poor

Try one or more of the following:

CHECK THE TRANSPARENCIES

Use only transparencies that meet the printer specifications.

CHECK THE PAPER TYPE SETTING

Make sure the paper type setting is set to Transparency:

1From the printer control panel Paper menu, check the Paper Type setting.

2Before sending the job to print, specify the correct type setting:

•For Windows users, specify the type from Print Properties.

•For Macintosh users, specify the type from the Print dialog.

Gray background on prints

ABCDE

MAKE SURE THERE IS NO WORN OR DEFECTIVE PRINT CARTRIDGE

Replace the worn or defective print cartridge.

Print quality guide

Page 5 of 10

Shadow images appear on prints

Try one or more of the following:

CHECK THE PAPER TYPE AND WEIGHT SETTINGS

Make sure the paper type and weight settings match the paper loaded in the tray or feeder:

1From the printer control panel Paper menu, check the Paper Type and Paper Weight settings.

2Before sending the print job, specify the correct paper type setting:

•For Windows users, specify the paper type from Print Properties.

•For Macintosh users, specify the paper type from the Print dialog.

MAKE SURE THE PRINT CARTRIDGE IS NOT LOW ON TONER

When 88.xx [color] cartridge low appears, make sure that toner is distributed evenly among all four print cartridges

or whichever color has the shadow images.

1Remove the print cartridge.

Warning—Potential Damage: Be careful not to touch the photoconductor drum. Doing so may affect the print quality of

future print jobs.

2Firmly shake the cartridge side-to-side and front-to-back several times to redistribute the toner.

3Reinsert the print cartridge.

Note: If print quality does not improve, replace the print cartridge of the color that is giving a shadow.

If the problem continues, the printer may need to be serviced. For more information, contact customer support.

Toner fog or background shading appears on a page

Try one or more of the following:

MAKE SURE PRINT CARTRIDGES ARE INSTALLED CORRECTLY AND ARE NOT DEFECTIVE

Reinstall or replace the print cartridge.

MAKE SURE THE TRANSFER BELT IS NOT WORN OR DEFECTIVE

Replace the transfer belt. For more information, see the instruction sheet that came with the replacement part.

Print quality guide

Page 6 of 10

MAKE SURE THE FUSER IS NOT WORN OR DEFECTIVE

Replace the fuser. For more information, see the instruction sheet that came with the replacement part.

MAKE SURE THERE IS NO TONER IN THE PAPER PATH

Clean any visible toner from the paper path. If the problem persists, then contact customer support.

RECALIBRATE THE PRINTER

Perform color adjust from the printer control panel Quality menu.

CHECK THE SOFTWARE PROGRAM OR APPLICATION

The software program or application may have specified an off-white background.

Toner rubs off

Try one or more of the following:

CHECK THE PAPER TYPE AND WEIGHT SETTINGS

Make sure the paper type and weight settings match the paper loaded in the tray or feeder:

1From the printer control panel Paper menu, check the Paper Type and Paper Weight settings. Change the Paper Weight

setting from Normal to Heavy.

2Before sending the print job, specify the correct paper type setting:

•For Windows users, specify the paper type from Print Properties.

•For Macintosh users, specify the paper type from the Print dialog.

CHECK THE PAPER TEXTURE SETTING

From the printer control panel Paper menu, make sure the Paper Texture setting matches the paper loaded in the tray or feeder.

If necessary, change the Paper Texture setting from Normal to Rough.

MAKE SURE THE FUSER IS NOT WORN OR DEFECTIVE

Replace the worn or defective fuser. For more information, see the instruction sheet that came with the replacement part.

Print quality guide

Page 7 of 10

Clipped images

Try one or more of the following:

CHECK THE GUIDES

Move the width and length guides in the tray to the correct positions for the paper size loaded.

CHECK THE PAPER SIZE SETTING

Make sure the paper size setting matches the paper loaded in the tray:

1From the printer control panel Paper menu, check the Paper Size setting.

2Before sending the job to print, specify the correct size setting:

•For Windows users, specify the size from Print Properties.

•For Macintosh users, specify the size from the Page Setup dialog.

Skewed print

These are possible solutions. Try one or more of the following:

CHECK THE PAPER GUIDES

Move the length and width guides in the tray to the correct positions for the paper size loaded.

•Make sure the guides are not too far from the paper stack.

•Make sure the guides are not pressing too lightly against the paper stack.

CHECK THE PAPER

Make sure you are using paper that meets the printer specifications.

Incorrect margins

These are possible solutions. Try one or more of the following:

CHECK THE PAPER GUIDES

Move the guides in the tray to the correct positions for the paper size loaded.

Print quality guide

Page 8 of 10

CHECK THE PAPER SIZE SETTING

Make sure the paper size setting matches the paper loaded in the tray:

1From the printer control panel Paper menu, check the Paper Size setting.

2Before sending the job to print, specify the correct size setting:

•For Windows users, specify the size from Print Properties.

•For Macintosh users, specify the size from the Page Setup dialog.

Printer is printing blank pages

Try one or more of the following:

MAKE SURE THERE IS NO PACKING MATERIAL LEFT ON THE TONER OR PRINT CARTRIDGE

Remove the cartridge and make sure the packing material is properly removed. Reinstall the cartridge.

MAKE SURE THE TONER OR PRINT CARTRIDGE IS NOT LOW ON TONER

When 88.xx [color] cartridge low appears, make sure that toner is distributed evenly among all four cartridges:

1Remove the cartridge.

Warning—Potential Damage: Be careful not to touch the photoconductor drum. Doing so may affect the print quality of

future print jobs.

2Firmly shake the cartridge side-to-side and front-to-back several times to redistribute the toner.

3Reinsert the cartridge.

Note: If print quality does not improve, then replace the cartridge of the color that is not printing.

If the problem continues, then the printer may need to be serviced. For more information, contact customer support.

Solid color or black pages appear on prints

Print quality guide

Page 9 of 10

MAKE SURE THE PRINT CARTRIDGES ARE INSTALLED CORRECTLY, ARE NOT DEFECTIVE AND NOT LOW ON

TONER

•Remove the print cartridges.

Warning—Potential Damage: Be careful not to touch the photoconductor drum. Doing so may affect the print quality of

future print jobs.

•Reinsert the print cartridges.

Note: If the quality does not improve, replace the print cartridges.

•If the problem continues, the printer may need to be serviced. For more information, contact customer support.

Paper curl

Try one or more of the following:

CHECK THE PAPER TYPE AND WEIGHT SETTINGS

Make sure the paper type and weight settings match the paper loaded in the tray or feeder:

1From the printer control panel Paper menu, check the Paper Type and Paper Weight settings.

2Before sending the print job, specify the correct paper type setting:

•For Windows users, specify the paper type from Print Properties.

•For Macintosh users, specify the paper type from the Print dialog.

LOAD PAPER FROM AFRESH PACKAGE

Paper absorbs moisture due to high humidity. Store paper in its original wrapper until you use it.

Print quality guide

Page 10 of 10

Autres manuels pour C792 Family

Table des matières

Autres manuels Lexmark Imprimante

Lexmark

Lexmark MX611 Series Manuel utilisateur

Lexmark

Lexmark X925 7541-03 series Manuel utilisateur

Lexmark

Lexmark Color Jetprinter Z13 Manuel utilisateur

Lexmark

Lexmark 22Z0000 Manuel utilisateur

Lexmark

Lexmark T420 Manuel de service

Lexmark

Lexmark 101 Manuel utilisateur

Lexmark

Lexmark OPTRA 4069-XXX Manuel utilisateur

Lexmark

Lexmark M1145 Manuel technique

Lexmark

Lexmark C925 Manuel utilisateur

Lexmark

Lexmark Optra Optra T Manuel utilisateur

Lexmark

Lexmark C746 Manuel utilisateur

Lexmark

Lexmark W850n Manuel utilisateur

Lexmark

Lexmark X5100 Series Manuel utilisateur

Lexmark

Lexmark 17J0050 - C 752n Color Laser Printer Manuel de service

Lexmark

Lexmark S500 Manuel utilisateur

Lexmark

Lexmark C 750 Fiche d'information produit

Lexmark

Lexmark Color Jetprinter Z42 Manuel

Lexmark

Lexmark Optra SC 1275 Manuel utilisateur

Lexmark

Lexmark MX610 Series Manuel utilisateur

Lexmark

Lexmark T650 Manuel utilisateur

Lexmark

Lexmark T630 - Printer - B/w Instructions de montage

Lexmark

Lexmark 3200 Color Jetprinter Manuel utilisateur

Lexmark

Lexmark T632 Manuel utilisateur

Lexmark

Lexmark MS610dn Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Canon

Canon i70 Series Manuel utilisateur

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Canon

Canon LASER SHOT LBP-1210 Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Canon

Canon PIXMA PRO-1 Series Manuel utilisateur

Canon

Canon PIXMA G3560 Guide de configuration

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Canon

Canon CLBR 460ps Manuel utilisateur

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

Canon

Canon imagePASS-A2 Manuel utilisateur

Canon

Canon S820D Manuel utilisateur

IRA3D

IRA3D POETRY4 Manuel utilisateur
