Lexmark X646e MFP Manuel utilisateur

Clinical Assistant

Product Specifications

Part Num er 22G0910

Product Class Workgroup laser MFP

Speed Up to 50 ppm

Time to First Page As fast as 8.5 seconds

Print Resolution 1200 x 1200 dpi, 2400 image quality printing, 600 x 600 dpi

Processor 533 MHz

Memory (std./max.) 256MB/768MB

Connectivity

Standard

Optional

Option Slots

USB, Ethernet, USB Direct Interface

Parallel, Serial, Wireless, Gigabit Ethernet, Fiber Optic

DRAM DIMM slots: 1; ISP (INA) slots: 1; Firmware Card/Flash memory slots: 2

Printer Languages PostScript 3, PCL 6 and PPDS Migration Tool

Direct Print Formats jpeg, tiff, gif, bmp, png, pcx, dcx, pdf v1.5, html

Fonts PostScript: 158 scalable; PCL: 89 scalable including OCR-A, OCR-B and Code 3 of 9 bar codes, 2 bitmapped;

PPDS: 39 scalable, 5 bitmapped

In the Box

Clinical Assistant

Lexmark Clinical Assistant

• X646dte MFP

• Custom e-task interface

• 21,000-page Return Program Print

Cartridge1

• 40+GB Hard Drive

• Duplex

• Setup Sheet

• Software and Documentation CD

• Power Cord

• RJ-11 Phone Cable

Scan to EMR - Enhances the standard “scan to folder” functionality by scanning directly to a directory

used by a health institution electronic medical records system. In addition, the MFP user can scan to a

Window’s network folder. Administrators can create folder destinations, and users can select their

desired destination, browse folders and create folders.

Orders Routing - Allows additional destination device IP addresses and routing of scanned

documents directly to network printers. Scanned jobs can be marked “STAT” (urgent) or normal. An

archive feature is also available in case the users want to archive the images for historical purposes.

Card Copy - Allows healthcare workers to copy both sides of the patient’s insurance and/or other

identification cards, and have them printed on the same side of a single page.

Bookmark Forms - Places an icon on the home screen labeled “Bookmark

Forms.” This icon is a shortcut to the forms menu which allows the user to

locate and print electronic forms which reside on a remote server.

Joan Hancock

Lexmark’s Clinical Assistant is an MFP that is value rich, easy to implement and simple to use. It is designed for

mission-critical healthcare workflow applications.

The Lexmark Clinical Assistant is based on the award-winning Lexmark X646dte monochrome laser MFP platform.

Part Num ers

Supplies 32,000-page Extra High Yield Return Program Print Cartridge1X644X11A

32,000-page Extra High Yield Return Program Print Cartridge for Label Applications1X644X01A

21,000-page High Yield Return Program Print Cartridge1X644H11A

21,000-page High Yield Return Program Print Cartridge for Label Applications1X644H01A

10,000-page Return Program Print Cartridge1X644A11A

32,000-page Extra High Yield Print Cartridge1X644X21A

21,000-page High Yield Print Cartridge1X644H21A

10,000-page Print Cartridge1X644A21A

Routine Maintenance Items:

Separator Roll it 40X0454

Pick Up Assembly 40X0453

Pressure Pad Cushion 40X0466

Charge Roll it 40X0127

Transfer Roll it 40X0130

Label Fuser Wiper 40X2665

Pick Tires 40X0070

Fuser Maintenance it 40X0100

Memory Options 128MB SDRAM 13N1523

256MB SDRAM 13N1524

512MB SDRAM 13N1526

32MB Flash Card 1021208

64MB Flash Card 1021209

Furniture Low Profile MFP Stand 16C0379

MFP Stand with Cabinet 16C0369

MFP Stand 16C0389

Warranty 1-year, next business day Onsite Repair Base

1-year Onsite Repair 2348322

2-year Onsite Repair 2348323

3-year Onsite Repair 2348324

Media Specifications

Paper Capacity (sheets)

Standard

Maximum Input: 1,100 (500 + 500 + 100 MPF); Output: 500

Input: 3,100 (500 + 500 + 2000 + 100 MPF); Output: 500

Paper Sources

Standard

Maximum Input: 3; Output: 1

Input: 4; Output: 1

Media Information

Types

Size

Weight

Plain paper, paper labels, card stock, transparencies, envelopes, vinyl labels,

polyester labels, dual web and integrated labels

Letter, Legal, A4, A5, JIS B5, Executive, Folio, Statement, Universal (2.75 in. x

5 in. to 8.5 in. x 14 in), envelopes (7 3/4, 9, 10, DL, C5, B5)

Plain paper: 16 to 47 lb. (60 to 176 g/m2); Card stock: up to 110 lb. (199

g/m2)

Shipping Dimensions

Lexmark Clinical Assistant

Size: 31.3 x 27.7 x 62.8

Weight: 190 lb.

1Declared standard page yield value in accordance with ISO/IEC 19752

Product Specifications (cont’d)

Copy Speed: up to 50 ppm, reduce/enlarge (25-400%), paper saver (2-up and 4-up), collation, darkness adjustment,

original size to output size selection, copy select 1-999, job interrupt, date/time stamp, single-pass duplex,

message overlay, priority copy, copy countdown

Fax Speed: 33.6 bps max.; transmission speed: approximately 3 seconds per page; resolution: 200 x 100 dpi, 200 x

200 dpi, 300 x 300 dpi, 400 x 400 dpi; fax redirect, group fax, manual fax, fax from PC, up to 512-character

shortcuts, fax preservation, LDAP lookup, Caller ID, speed dials, block junk faxes

Scan Output resolutions: up to 600 x 600 dpi black, up to 300 x 300 dpi color; scan destinations: Network TWAIN, USB

Direct Interface, e-mail, FTP, LDSS, Scan-to-PC; File Formats: TIFF, JPG, PDF; legal-size from flatbed; simplex scanning

Operating Systems Microsoft Windows, Mac, NetWare, Unix and Linux

Acoustics Printing: 56 dBA; Copying: 57 dBA; Scanning: 52 dBA; Idle: 30 dBA

Size (WxDxH) 22 in. x 26 in. x 33 in. (560 mm x 660 mm x 850 mm)

Weight 103 lb. (47 kg)

Additional Part Num ers

1Requires USB connection

2Use of an Internal Print Server disables the Ethernet card resident in the printer

Terms & Conditions

Lexmark, Marknet and Lexmark with diamond design are trademarks of Lexmark International

, Inc., registered in the United States and/or other

countries. PCL is a

registered trademark of Hewlett Packard Company.

All other trademarks are the property of their respective owners. All

71K1219

Solutions Traditional Chinese Font Card 1021242

Japanese Font Card 1021243

orean Font Card 1021240

Simplified Chinese Font Card 1021241

Connectivity External Print Servers

N4050e Wireless 802.11g Print Server114T0145

Internal Print Servers2

MarkNetTMN8020 Gigabit Ethernet 14S0200

MarkNet N8030 Fiber Ethernet 14S0220

MarkNet N8050 802.11g Wireless 14S0165

Ca les 10-foot Parallel Cable 1021231

6-foot USB Cable 1021294

Adapters Parallel 1284-B Interface Card 1021091

RS-232C Serial Interface Card 1021092

Media Transparencies (letter) 70X7240

— 100-sheet Multipurpose Feeder (standard)

— 500-sheet Drawer (standard)

— 500-sheet Duplex Unit (standard)

— 500-sheet Drawer (standard)

— 10-inch Spacer Cabinet (22G0551)

— Printer Base (22G0544)

Options Not Pictured

250-sheet Drawer 20G0889

250-sheet Tray 20G0879

500-sheet Tray 20G0884

250-sheet Universally Adjustable Drawer 20G1223

400-sheet Universally Adjustable Drawer 20G1218

250-sheet Universally Adjustable Tray 20G1224

400-sheet Universally Adjustable Tray 20G1217

2000-sheet Drawer (letter only) 20G0892

85-sheet Envelope Feeder 20G0891
