HAI Dock

Operation Manual

About Trademarks

Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other

countries.

iPod, iTunes, AirMac, AirPort, Macintosh, MacOS, and Safari are either registered trademarks or trademarks of Apple Computer,

Inc. in the United States and/or other countries.

Other brand or product names are registered trademarks or trademarks of their respective owners.

Document Number: 96I00-1 Rev. A

August, 2011

Regulatory Compliance Statements

FCC Notice

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, it may cause harmful interference to

radio communications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for assistance.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

EN55022 Class-B

EN55024

Safety instructions regarding the radio waves

Do not use this product near medical devices, such as a heart pacemaker. The radio waves

generated by this product may interfere with the operation of these devices.

Do not use this product near microwave ovens. The radio wave used by microwave ovens may

cause interference with this product.

Safety Precautions

Users are strongly advised to adhere to the directions and recommendations offered in this manual. Failure to do

so may result in problems during operation.

Use the following safety guidelines to help protect yourself and the

•Do not attempt to service the HAI Dock yourself.

•Always follow installation instructions closely.

•Make sure the correct voltage is being supplied before turning the power on.

•Use only the AC adapter and power cord that are approved for use with this unit.

•Do not install in a very humid environment.

•Do not install in an area exposed to sunlight or heat.

•Do not use in areas containing flammable materials like propane gas and gasoline or in areas that generate

dust. Doing so may cause an explosion or fire.

•Do not dismantle, repair, or modify the product. Doing so may cause damage or an electric shock. Refer all

servicing to qualified personnel.

•Do not use water, thinner, or organic solvent for cleaning the product exterior. Doing so may

cause damage or an electric shock. Use a dry cloth instead and turn off the power before

cleaning.

Disclaimer

•While every effort has been made to ensure that the information contained in this guide is accurate and

complete, no liability can be accepted for any errors or omissions.

•HAI reserves the right to change the specifications of the hardware and software described herein at any time

without prior notice.

•No part of this guide may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated

into any language in any form, by any means, without prior written permission of HAI.

•HAI makes no warranties for damages resulting from corrupted or lost data due to mistaken operation or

malfunction of the HAI Dock, the software, personal computers, peripheral devices, or

unapproved/unsupported devices.

iii

Table of Contents

Regulatory Compliance Statements .............................................i

Safety Precautions ........................................................................ii

Disclaimer ..................................................................................................................................................................... ii

Introducing the HAI Dock.......................................................1

Features ...........................................................................................................................................1

Package Contents ...........................................................................................................................2

Supported Operating Systems.................................................................................................................................... 2

Supported iPod Models ............................................................................................................................................... 2

HAI Dock Overview

...........................................................................................................................3

Connections to the HAI Dock .........................................................................................................5

Connecting the Network .............................................................................................................................................. 5

To router, hub, or network switch .............................................................................................................................. 5

Connecting the Power.................................................................................................................................................. 5

Connecting the Audio Output ..................................................................................................................................... 6

Getting Started

...........................................................................7

Configuring the HAI Dock...............................................................................................................7

HAI Dock Setup Utility.................................................................................................................................................. 8

HAI Dock Operation ......................................................................................................................13

Operation Modes ........................................................................................................................................................ 14

Playing Music ................................................................................................................................14

Inserting and Removing an iPod..................................................................................................15

Accessing the Web Server ...........................................................................................................15

Status........................................................................................................................................................................... 16

Configuration .............................................................................................................................................................. 17

System Information .................................................................................................................................................... 17

Reset to Factory Default ...............................................................................................................18

Interfacing with the HAI Dock ............................................19

Enabling the HAI Dock ..................................................................................................................19

Creating a New Project with the HAI Dock............................................................................................................... 19

Adding Touchscreens to the Project........................................................................................................................ 20

Adding the HAI Dock to an Existing Design ...............................................................................22

Importing the HAI Dock Pages.................................................................................................................................. 22

Discovering Touchscreens...........................................................................................................23

Adding an HAI Controller to the Design ......................................................................................24

Adding the HAI Dock to the Design .............................................................................................24

Discover the HAI Dock ............................................................................................................................................... 25

Assigning the Audio Output...................................................................................................................................... 26

Assigning a Touchscreen Page for Media

................................................................................................................. 27

Updating the Touchscreens .........................................................................................................28

Accessing Your Music ..................................................................................................................30

Browse the Media Library.......................................................................................................................................... 31

Selecting a new Music Source

.................................................................................................................................... 32

Selecting a New Audio Zone

....................................................................................................................................... 33

Specifications ..........................................................................34

Chapter 1

Introducing the HAI Dock

The HAI Dock is a product that allows you to access music and other content on an iPod, iPod Touch, or

iPhone using IP enabled devices, such as HAI OmniTouch 5.7e and 10pe Touchscreens, and Hi-Fi2

audio distribution systems. The HAI Dock connects over a wired or wireless LAN network. When used

with a supported audio distribution system, an iPod that is connected to an HAI Dock becomes an audio

source that can be played in any audio zone in the house.

Using an HAI OmniTouch 5.7e, 10p, or 10pe Touchscreen, you can browse and make music selections

by Playlists, Artists, Albums, Songs, Podcasts, Genres, Composers, and Audiobooks. Album art and

other music metadata are displayed with each selection.

Features

Works with OmniTouch 5.7e and 10pe Touchscreens when combined with an HAI controller and supported

audio distribution system (e.g. HAI Hi-Fi or Hi-Fi2, NuVo, Russound, Xantech, Speakercraft, or Proficient).

Works standalone with Hi-Fi2 audio distribution systems. VSC keypads will display iPod metadata (artist,

album, and track) and allows for control commands (play, pause, next track, and previous track) at the VSC

keypad.

HAI Dock sends iPod metadata and album artwork to IP enabled devices, such as HAI OmniTouch 5.7e and

10pe.

IP enabled devices can send control commands (play, pause, stop, next track, previous track, rewind, fast

forward, next chapter, previous chapter, etc.) to an iPod that is docked in the HAI Dock.

HAI Dock allows IP enabled devices to navigate and browse the music library on the iPod by Playlists,

Artists, Albums, Songs, Podcasts, Genres, Composers, and Audiobooks.

Connects to an existing wired 10/100 LAN network or wireless 802.11 b/g (on supported HAI Dock models)

network.

Up to 8 HAI Docks can be connected and controlled on a network.

Charges the battery in the docked iPod.

Package Contents

After opening the box, ensure the following items are present:

oHAI Dock

oPower Supply

oAudio Cable

oHAI Dock CD (Setup Utility and Manual)

oGetting Started Guide

Supported Operating Systems

oWindows 7, Windows Vista, Windows XP, Windows 2000

oMac OS X 10.2.7 to 10.4.x (PPC version)

oMac OS X 10.4.3 or later (Intel version)

Supported iPod Models

oiPod classic

oiPod Nano (3G, 4G, 5G, 6G)

oiPod touch (1st, 2G, 3G, 4G)

oiPhone (1st, 3G, 3GS, 4G)

HAI Dock Overview

This section describes the main components of the HAI Dock.

Front View

1 Infrared (IR)

Receiver

Control playback of a connected iPod

from a distance using the Apple

Remote when the HAI Dock is in Local

Mode.

2 Operation

Mode LED

The Operation Mode LED is illuminated

when the HAI Dock is in Network Mode

(running and

can be controlled via IP

enabled devices).

The Operation Mode LED is off when

the HAI Dock is in Standby Mode. In

Standby Mode the USB controller,

Ethernet PHY, and the wireless radio

(if applicable) is disabled.

3 iPod

Connector Connects the iPod to the HAI Dock.

4 Operation

Mode Button

When is Standby Mode, press this

button to start the unit

in Network

Mode.

When in Network Mode,

press and

hold for 2 seconds to put the unit into

Standby Mode.

The Operation Mode Button is also

used to reset the HAI Dock to factory

default settings.

Rear View

5 Power Jack

Connect the supplied AC power supply

to this jack to provide power to the HAI

Dock.

6 Network

Port

Use a standard network cable to

connect the Network Port to the local

network.

7 Green LED

Shows the network communication

status.

8 Orange LED

Shows the network communication

status.

9 S-Video

Output This output is currently not active.

10 Audio

Output

Connect supplied 3.5mm male stereo

patch cable between the Audio Output

on the HAI Dock and an audio input on

Hi-

Fi2 or other audio distribution

system.

3.5mm male to 2 RCA male stereo

patch cable c

an be used to connect

HAI Dock to audio equipment which

requires RCA audio inputs.

Bottom View

11 Ethernet

Address

The Ethernet (MAC) Address of the

HAI Dock is found on the label on the

bottom of the unit.

The last 6 digits of the Ethernet

Address is the HAI Dock serial

number.

For example: If the Ethernet Address

is 00:07:A6:00:11:22 (noted as

0007A6001122) then the product's

serial number is “001122”.

Table des matières

Autres manuels Leviton Station d'accueil

Leviton

Leviton Dock Manuel utilisateur

Manuels Station d'accueil populaires d'autres marques

Sony

Sony Dream Machine XDR-DS12iP Manuel utilisateur

Acer

Acer USB Type-C Dock II Manuel utilisateur

ATEN

ATEN UC-2000 Manuel utilisateur

Xcellon

Xcellon HDD-202 Manuel utilisateur

Dok

Dok CR09 Manuel utilisateur

Philips

Philips BTM630/12 Manuel utilisateur

IOGear

IOGear Travel Pro GUD3C09 Manuel utilisateur

RKI

RKI SDM-E2 Manuel utilisateur

iHome

iHome iP15 Manuel utilisateur

VITURE ONE

VITURE ONE MOBILE DOCK Manuel utilisateur

Lindy

Lindy 42984 Manuel utilisateur

CipherLab

CipherLab 8001 Manuel utilisateur

Pyle

Pyle PIPDSP2 Manuel utilisateur

Avol

Avol AS2350 Manuel utilisateur

Datalogic

Datalogic JoyaTouch Manuel utilisateur

Philips

Philips DC190/79 Manuel utilisateur

Targus

Targus DOCK315EUZ Manuel utilisateur

Akasa

Akasa DuoDockX3 AK-DK08U3-BK Manuel utilisateur
