LevelOne FCS-0031 Manuel utilisateur

Megapixel PIR Lighting

PoE Network Camera FCS-0031

H/W Version: 1

The LevelOne FCS-0031 is designed for 24hrs home

surveillance. It provides a distinct and stylish design,

with excellent features and quality, providing multiple

applications and a wide range of coverage. Users can

view the live motion image anywhere through a web

browser via the Internet. With a megapixel progressive

sensor and white LED, the FCS-0031 comes with high-

resolution quality and sharp sensitivity – an ideal

solution for your day-and-night surveillance system.

In addition, the FCS-0031 provides many advanced

features, including human detection sensor (PIR),

Micro SD card slot and Privacy button. The FCS-0031

complies with 802.3af PoE standard and supports

exible deployment, even in locations without power

outlet.

With an "Easy Installation Wizard", this LevelOne

IP camera is very user-friendly, perfect for both

home and business use. It is also embedded with

a high-performance image sensor and CPU. The

FCS-0031 supports H.264, MPEG4 and MJPEG video

compression, providing a high resolution at 640x400

or 1280x800 for high-quality video and real-time

viewing.

Key Features

- 1/4” Progressive CMOS, 1280x800

- H.264, MPEG4 and MJPEG compression

- Built-in PIR Sensor for human temperature detection

- Built-in white LED for low lux

- Built-in microphone and speaker

- Simple audio/video on/o with one-push Privacy

Button

- IEEE 802.3af compliant for easy network deployment

- Built-in Micro SD/SDHC memory card slot for local

storage

- Free 64-CH Monitoring Software (supports

iCamSecure Apple App and iOS Safari)

- Remote access with Level1DNS™ service

FSW-0503

4FE PoE + 1 FE Switch

Works Well With

POI-2002

PoE Injecter

21 3 4 5 6 10 11

1. Built-in Microphone

2. PIR Sensor

3. Illumination LED

4. LEDs

5. Speaker

6. Ethernet

7. Stand Socket

8. Reset Button

9. Power Connector

10. Privacy Button

11. Micro SD slot

87 9

Network Camera

www.level1.com

one world_one brand_one level_

Technical Specication

Image Sensor

Sensor Type : 1/4”Mega-Pixel CMOS Sensor

Sensor Resolution : 1280 x 800 pixel

Minimum Illumination :

1 Lux (without LED)

0 Lux (with LED)

White LED

LED light distance up to 6m

Triggered by Auto PIR Sensor

Lens

Lens Type: Board Lens

Focal Length: f= 3.6 mm

View Angle: H: 55.7°, V: 36.5°

Video

Image Compression: H.264 / MPEG4 / MJPEG

Auto Exposure Control / Auto White Balance /

Auto Gain Control

Image Resolution and Frame Rate:

1280 x 800: 30fps

640 x 400: 30fps

Audio

Audio Streaming: Two-way audio

Audio Code: G.711/AMR

Built-in MIC & Speaker

Zoom

Digital Zoom: 4x

Communication

Ethernet: one 10/100Mbps RJ-45

Supported Protocols: TCP/IP, UDP, ICMP, DHCP, NTP, DNS, DDNS,

SMTP, FTP, HTTP, Samba, PPPoE, UPnP, Bonjour, RTP, RTSP, RTCP

Hardware

Flash ROM: 16MB

RAM:64M DDR

Interface & Buttons

Passive infrared sensor (PIR)

Micro SD/SDHC card slot

DC Power Connector

Ethernet Cable Connector

Privacy Button

Reset Button

LEDs

Power/Ethernet states/ Privacy

Power

Output: DC12V/1 A , 802.3af PoE

Power consumption

Max Power Consumption: 2.5W

Environment

Operating Temperature: 0°C ~ 50°C (32°F ~122°F)

Operating Humidity: 10% ~ 80%

Dimension

29 (L) X60 (W) X 95 (H) mm

Software

Bundled with 64-Channel LevelOne IP CamSecure Lite

surveillance management software

Viewing System Requirement

OS: Microsoft Windows 2000/XP/Vista

Browser: IE 6.x or above

3GPP Player: Real Player 10.5 , Quick Time 6.5 or above

Certication

FCC, CE

Product Diagram

FCS-0031

Remote Viewing via Internet

Modem

Control Console

NAS

Internet/

3G Mobile

Network

Wireless Router

Remote

Viewing

via 3G

Network

FCS-0031

PoE Switch

PoE Injecter

Order Information FCS-0031: Megapixel PIR Lighting PoE Network Camera

Package Contents FCS-0031

Power Adapter

RJ45 Ethernet LAN Cable

Quick Installation Guide

CD Manual / Utility

V1.0

All mentioned brand names are registered trademarks and property of their owners. Technical specications are subject to change without notice.
