LevelOne NVR-0316 Manuel utilisateur

NVR-0316

Network Video Recorder

Quick Installation Guide v1.0

English

Português

Deutsch

Svenska

Français

Slovenščina

Español

繁體中文

Nederlands

Русский

Dansk

Polski

Italiano

Ελληνικά

H/W: 1.0

NVR-0316 Quick Installation Guide

Table of Contents

English....................................................................................... 4

Deutsch.................................................................................... 14

Français ................................................................................... 24

Español.................................................................................... 34

Nederlands................................................................................ 44

Dansk ...................................................................................... 55

Italiano..................................................................................... 66

Ελληνικά .................................................................................. 76

Português................................................................................. 86

Svenska ................................................................................... 96

Slovenščina ............................................................................ 107

繁體中文.................................................................................. 118

Русский ................................................................................. 129

Polski .................................................................................... 139

Package Contents

Network Video Recorder

Power cord/Power adapter

Quick Installation Guide

CD Manual/Utility

SATA cable x 2

HDD Case x 1

Screw for HDD case x 4

Screw for HDD x 8

Rubber foot pad x 1

NVR-0316 Quick Installation Guide

Default Settings

IP Address

DHCP address

Username

root

Password

root

If the NVR detects no DHCP server on the LAN environment,

then the NVR’s IP will be static IP [192.168.101.50]

This guide covers only the most common situations. All detailed

information is described in the user manual.

NVR-0316 Quick Installation Guide

English

System Overview

Front View

Rear View

NVR-0316 Quick Installation Guide

HDD Installation

1. Start by removing the screws on the side.

2. Push the top housing forward then lift it up.

3. Install HDD on brackets with screws

Prepare HDD brackets.

NVR-0316 Quick Installation Guide

Fix the HDD on bracket with screws. You can install two HDDs with

brackets.

4.Install SATA Cable

Prepare SATA cable.

Install SATA cables on system,

install SATA data cable. Install power cable.

NVR-0316 Quick Installation Guide

Install SATA cable on the HDD.

Install HDD brackets

Fix HDD brackets on system with screws.

NVR-0316 Quick Installation Guide

Connect to the NVR

There are various ways you can connect to the NVR and below are the

suggested methods for different network setup:

Use LevelOne Device Search Utility

If the NVR is placed in a corporate network or a local area network where a

DHCP server is already presented, run the “LevelOne Device Search” utility

from a computer that is on the same network and locate the NVR with its IP

address that is assigned by the top-level DHCP server.

To begin, launch the “Device Search” utility from the CD and proceed with the

installation:

Once the installation is complete, check the “Launch the program” option and

click “Finish”.

The search should start automatically and its status should be displayed.

NVR-0316 Quick Installation Guide

The NVR should be located and its IP address should be displayed.

Double-click on an NVR and the search program should automatically access the

NVR’s web administration page from your default browser.

You should be prompted for the NVR’s username and password. Enter its default

username “root” and password “root” and then click ”OK” to enter the system.

Access the NVR with its default IP address

Double-click

NVR-0316 Quick Installation Guide

The NVR comes with a pre-configured static IP “192.168.101.50”. However, it is

only used when there is no DHCP server presented in the network. The NVR will

turn on its DHCP server function and act as the DHCP server in the network.

To connect to the NVR, connect the PC directly to the NVR using a crossover

CAT5 Ethernet cable. Simply access the NVR from your web browser with its IP

address.

Again, you should be prompted for the username and password. Enter its default

username “root” and password “root” and then click ”OK” to enter the system.
