LevelOne FCS-1010 Manuel utilisateur

LevelOne FCS-1010

P/T IP Camera

Quick Installation Guide

System Requirements

Windows 98, 98SE, Millennium Edition (ME), 2000 and XP operating systems♦

♦

PC with Pentium III 800MHz system or above is recommended

Memory Size:128MB (256 is recommended)

NOTE:

All the captured images of installation mentioned in this user’s manual

were based on Windows XP operating system. For installation on other

Windows OS, e.g. Windows 98SE, all the procedures remains the same.

1 LevelOne FCS-1010 Hardware Installation

Connect the Ethernet Cable

Please use a cross-over Ethernet cable if you connect this camera directly to a PC.

Connect an Ethernet cable to the

Ethernet connector located on

the back panel of FCS-1010.And

attach it to the newwork

Attach the External Power Supply

Attach the external

power supply to the DC

power input connecto

And connect it to an AC

power o

utlet.

Attach the AV cable(optional).

Connect the AV cable only if you wish to connect FCS-1010 to a TV set.

Attach the AV cable to the

AV out connector .

Attach the yellow RCA connector to the “Video” connector on your TV.

Attach the white RCA connector to the “Audio” connector on your TV.

Configuring your FCS-1010 with IP Installer

Insert the FCS-1010 CD

into the CD-ROM drive.

Click on “IP Installer”.

IP Installer screen shall

show up.

The IP Installer will show

a MAC address and an

IP Address of available

FCS-1010.

Highlight the MAC

address and click “Link to

selected device”.

After successful linkage, the

authentication window should pop up.

The default user name is “root”.

The default password is the MAC

address of your own FCS-1010, which

marks at the bottom label of each

device.

Please enter the MAC address in

capital letters.

3 Viewing Your LevelOne FCS-1010

The following screen would appear automatically after successful login.

Click “Yes” and proceed.

FCS-1010 should be active by now.

It is highly recommended

that set a password for

security purposes.

Click on Configuration

for setting the password.

Configuration Page

This is the page where you can change the basic settings of the FCS-1010.

Click on “Security” and

set your password and

add additional accounts

to the FCS-1010

necessary.

The basic installation and configuration of FCS-1010, P/T IP Camera, is

now complete. Please refer to the user`s manual for further configuration.
