Lenovo Tab P11 Pro Comment utiliser

Lenovo

Tab P11 Pro

Safety, Warranty

& Quick Start Guide

Lenovo TB-J706F

Lenovo TB-J706L

English/Čeština/Slovenčina

Contents

English............................................................................................................1

Čeština...........................................................................................................19

Slovenčina.................................................................................................... 37

Read this guide carefully before using your device.

All information labeled with * in this guide only refers to the WLAN + LTE model.

https://support.lenovo.com

https://forums.lenovo.com

Reading before using your device

Reading ﬁrst - regulatory information

Device models equipped with wireless communications comply with the radio

frequency and safety standards of any country or region in which it has been approved

for wireless use. In addition, if your product contains a telecom modem, it complies with

the requirements for connection to the telephone network in your country.

Be sure to read the Regulatory Notice for your country or region before using

the wireless devices contained in your device. To obtain a PDF version of the

Regulatory Notice, go to https://support.lenovo.com.

Getting support

To get support on network services and billing, contact your wireless network

operator. To learn how to use your device and view its technical speciﬁcations, go

to https://support.lenovo.com.

Accessing your User Guide

Your User Guide contains detailed information about your device. To download

the publications for your device, go to https://support.lenovo.com and follow the

instructions on the screen.

Legal notices

Lenovo and the Lenovo logo are trademarks of Lenovo in the United States, other

countries, or both.

Other company, product, or service names may be trademarks or service marks of

others.

Dolby, Dolby Audio, Dolby Vision, Dolby Atmos, and the double-D symbol are

trademarks of Dolby Laboratories. Manufactured under license from Dolby

LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered

pursuant a General Services Administration “GSA” contract, use, reproduction, or

disclosure is subject to restrictions set forth in Contract No. GS-35F-05925.

English

Device overview

Model Version

Lenovo TB-J706F WLAN

Lenovo TB-J706L WLAN + LTE

1Volume up button 2Volume down button 3Microphones

4Front camera 5Light sensor 6ToF sensor

7Speakers 8USB-C connector 9Touch screen

10 Card tray 11 Power button/Fingerprint

sensor 12 Flashlight

13 Rear camera 14 Wide-angle camera

15 4-point pogo-pin smart connector (for the compatible keyboard and Smart

Charging Station)

• The WLAN version does not have a Nano-SIM card slot.

• USB-C connector only supports the USB-C to 3.5mm digital adapter to

connect a 3.5mm audio plug.

• All pictures and illustrations in this document are for your reference only and

may differ from the final product.

4 5 6 4

1 2 3 3

12 13 14

Preparing your device

Installing cards

Install the cards as shown in the ﬁgure.

• Power o the device before inserting or removing a card.

• Note that the WLAN version does not have a Nano-SIM card slot.

Charging your device

Connect your device to a power

outlet using the USB cable and

power adapter provided.

microSD

SIM

Turning on

Press and hold the Power button until

the Lenovo logo appears.

Logging in with your ﬁngerprint

Touch the ﬁngerprint sensor to quickly unlock the screen.

It is recommended to follow the

onscreen instructions and register

your ﬁngerprint when powering

on your device for the ﬁrst time.

You can also go to Settings >

Security > Fingerprint to register

a ﬁngerprint.

Before using fingerprint functions, you need to set a lock screen password. Go to

Settings > Security > Screen lock to set up.

Accessories (optional)

The accessories do not come with all models, and are sold separately.

Keyboard pack

Keyboard Stand Cover

Keyboard layouts vary from country to country. The Keyboard layout in this

document is for reference only and your Keyboard may differ.

1Keyboard connector 2Keyboard 3Trackpad

4Hinge 5Kickstand

Attaching the Keyboard pack

Keyboard pack conﬁgurations

Attach the stand cover and keyboard to the tablet as shown in the following

ﬁgure.

The Tablet can be used with the entire Keyboard pack attached, or with the

Stand Cover alone.

1 2

• When you are attaching the Stand Cover to the Tablet, make sure

that the camera hole is aligned with the tablet’s rear cameras.

Opening and adjusting the Kickstand

You can adjust the Tablet angle using the Stand Cover. Grasp either side of

the kickstand and gently open it until you reach the desired angle.

2 3

To prevent damage, do not apply excessive pressure to the Stand Cover or force

the Kickstand beyond its natural range of motion.

• Do not overtilt or apply excessive pressure to the Stand Cover,

doing so may damage the hinges.

• Adjust the tablet angle by opening the Kickstand and changing the

position of the tablet until the desired angle is found.

• The Tablet, Keyboard, and Stand Cover all contain magnetic

materials. To avoid loss of magnetism, avoid exposing the Tablet,

Keyboard, and Stand Cover to high temperatures or direct sunlight.

• To prevent demagnetization of credit cards and other items with magnetic

data, keep them away from the Tablet, Keyboard, and Stand Cover.

Overview

Charging the pen

Lenovo Precision Pen 2

You can use the Lenovo Precision Pen 2 in place of your ﬁngers for a better

experience, such as working with speciﬁc applications to write or draw on

the screen.

1. Remove the pen cap in the direction

shown in the ﬁgure.

2. Connect the pen to a charger with a

USB-C cable.

3. Replace the pen cap on the pen.

You can start to use the pen after

charging.

• The indicator light will have an amber glow while charging the pen

and a white glow after it is fully charged.

• Please be cautious when using the pen. The pen contains sensitive

electronic components. Dropping it may cause damage.

1Pen cap

2Indicator LED

3Upper button

4Lower button

5Tip

1 2 3

Replace tip

1. Pinch the tip with tweezers or another suitable tool.

2. Remove the tip.

3. Install the replacement tip (supplied).

Store the Pen

Method one:

1. Slide the pen into the pen case.

2. Remove the transparent ﬁlm on the back of the pen case.

3. Stick the pen case to the plastic panel.

4. Thread the ring through the X-shaped hole in the top of the plastic panel.

1 2 3 4
