Lenovo ThinkVision E22-20 Manuel utilisateur

ThinkVision E22-20

User Guide

Machine Types: 62A4-MAR4-WW

Product No.

62A4-MAR4-WW

First Edition (April 2020)

LENOVO products, data, computer software, and services have been developed exclusively at private expense

restricted rights to use, reproduction and disclosure.

LIMITED AND RESTRICTED RIGHTS NOTICE: If products, data, computer software, or services are

delivered pursuant a General Services Administration "GSA" contract, use, reproduction, or disclosure is

subject to restrictions set forth in Contract No. GS-35F-05925.

H20215FE0

Power Management Modes

Serice information

Customer responsibilities

Service parts

Accessibility information

iii

Safety information

General Safety guidelines

For tips to help you use your computer safely, go to:

http://www.lenovo.com/safety

Before installing this product, read the Safety Information.

DANGER

To avoid shock hazard:

•Do not remove the covers.

•Do not operate this product unless the stand is attached.

•Do not connect or disconnect this product during an electrical storm.

•The power cord plug must be connected to a properly wired and grounded power outlet.

•Any equipment to which this product will be attached must also be connected to

properly wired and grounded power outlets.

•To isolate the monitor from the electrical supply, you must remove the plug from the

power outlet. The power outlet should be easily accessible.

To take special precautions to avoid the introduction of hazards when operating, installing,

servicing, transporting or storing equipment, the necessary instructions shall be made

available.

To reduce the risk of electric shock, do not perform any servicing other than that contained

Handling:

•If your monitor weighs more than 18 kg (39.68 lb), it is recommended that it be moved

or lifted by two people.

Make sure the light bar is located downside when you install in the way of VESA.

To prevent possible hearing damage, do not listen at high volume levels for long periods.

Warning for excessive sound pressure from earphones and headphones. Excessive sound

pressure fromearphones and headphones can cause hearing loss. Adjustment of the equalizer

to maximum increases the earphones and headphones output voltage and therefore the sound

pressure level.

A third-party certification according to ISO 14024

Say hello

to a more sustainable product

IT products are associated with a wide range of sustainability risks

throughout their life cycle. Human rights violations are common in the

factories. Harmful substances are used both in products and their

manufacture. Products can often have a short lifespan because of poor

ergonomics, low quality and when they are not able to be repaired or

upgraded.

This product is a better choice. It meets all the criteria in TCO Certified,

the world’s most comprehensive sustainability certification for IT

products. Thank you for making a responsible product choice, that help

drive progress towards a more sustainable future!

Criteria in TCO Certified have a life-cycle perspective and balance

environmental and social responsibility. Conformity is verified by

independent and approved verifiers that specialize in IT products, social

responsibility or other sustainability issues. Verification is done both

before and after the certificate is issued, covering the entire validity

period. The process also includes ensuring that corrective actions are

implemented in all cases of factory non-conformities. And last but not

least, to make sure that the certification and independent verification is

accurate, both TCO Certified and the verifiers are reviewed regularly.

Want to know more?

Read information about TCO Certified, full criteria documents, news and

updates at tcocertified.com. On the website you’ll also find our Product

Finder, which presents a complete, searchable listing of certified

products.

Toward sustainable IT products

Stand (with four screws)

Information Flyer

Flat Panel Monitor

Power Cord

HDMI Cable

Base

HDMI

Chapter 1. 1-2

Notice for use

To set up your monitor, please see the illustrations below.

Note: Do not touch the screen of monitor, which can be damaged easily by rub or pressure

because it is made of glass.

2. Assemble the bracket on the base and tighten the screws on the base.

3. Assemble the bracket base on the back of the monitor, align the screw hole and tighten the screw.

Notes: To install a VESA mount, please see "Wall Mounting (Optional)" on page 2-9.

Don’t press hard screen(screen arch up).

Put your monitor with the screen face down on a soft flat surface.

Chapter 1. 1-3

Product overview

This section will provide information on adjusting monitor positions, setting user controls,

and using the cable lock slot.

Types of adjustments

Tilt

Please see the illustration below for an example of the tilt range.

-5

Chapter 1. 1-4

Height Adjustment

For height adjustment, user needs to press down or lift up the monitor.

Pivot

Before the monitor is displayed in the vertical direction, it should be fully lift up and fully

tilted to avoid collisions.

90°

155mm
