Lenovo ThinkCentre M60q Chromebox Manuel utilisateur

ThinkCentre M60q Chromebox / ThinkCentre

M60q Chromebox Enterprise

User Guide

Read this first

Before using this documentation and the product it supports ensure that you read and understand the

following:

• Safety and Warranty Guide

• Generic Safety and Compliance Notices

• Setup Guide

First Edition (November 2022)

LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services

Administration “GSA” contract use reproduction or disclosure is subject to restrictions set forth in Contract No. GS-

35F-05925.

Contents

Dis over your Lenovo Chromebox . . . iii

Chapter 1. Meet your Chromebox. . . . 1

Front . . . . . . . . . . . . . . . . . . . . 1

Rear . . . . . . . . . . . . . . . . . . . . 2

Features and specifications . . . . . . . . . . . 3

USB specifications . . . . . . . . . . . . . . 3

Chapter 2. Explore your

Chromebox. . . . . . . . . . . . . . . . 5

Connect an external display . . . . . . . . . . . 5

Use the keyboard shortcuts . . . . . . . . . . . 5

Lock your Chromebox . . . . . . . . . . . . . 6

Set the power plan . . . . . . . . . . . . . . 6

Purchase accessories . . . . . . . . . . . . . 7

Shut down your Chromebox . . . . . . . . . . . 7

Chapter 3. Help and support . . . . . . 9

Frequently asked questions . . . . . . . . . . . 9

Get help from Google . . . . . . . . . . . . 10

Call Lenovo . . . . . . . . . . . . . . . . 10

Before you contact Lenovo . . . . . . . . 10

Lenovo Customer Support Center . . . . . . 11

Chapter 4. CRU repla ement . . . . . 13

CRU list . . . . . . . . . . . . . . . . . . 13

Remove or replace a CRU . . . . . . . . . . . 14

Power adapter and power cord . . . . . . . 14

Power adapter bracket . . . . . . . . . . 15

VESA mount bracket . . . . . . . . . . . 16

Vertical stand . . . . . . . . . . . . . . 16

External Wi-Fi antenna . . . . . . . . . . 17

Front cover . . . . . . . . . . . . . . . 18

System fan and heat sink . . . . . . . . . 19

ThinkCentre LED cable . . . . . . . . . . 20

Reset board kit . . . . . . . . . . . . . 20

Board-to-Board module. . . . . . . . . . 21

Bottom cover . . . . . . . . . . . . . . 22

M.2 solid-state drive . . . . . . . . . . . 22

Memory module . . . . . . . . . . . . . 23

Appendix A. Complian e

information . . . . . . . . . . . . . . . 27

Appendix B. Noti es and

trademarks . . . . . . . . . . . . . . . 31

ii ThinkCentre M60q Chromebox / ThinkCentre M60q Chromebox Enterprise User Guide

Dis over your Lenovo Chromebox

Thank you for hoosing a Lenovo® Chromebox! We are dedi ated to delivering the best solution to

you.

Before starting your tour read the following information:

• Illustrations in this documentation might look different from your product.

• Depending on the model some optional accessories features software programs and user interface

instructions might not be applicable to your Chromebox.

• Documentation content is subject to change without notice. To get the latest documentation go to https://

pcsupport.lenovo.com.

iv ThinkCentre M60q Chromebox / ThinkCentre M60q Chromebox Enterprise User Guide

Chapter 1. Meet your Chromebox

Front

Item Des ription Item Des ription

1 ThinkCentre® LED 2 Power button with power indicator

3Storage drive activity indicator 4USB-C® (3.2 Gen 2) monitor connector

5 USB-A 3.2 Gen 2 connectors 6 Headset connector

* for selected models

Statement on USB transfer rate

Depending on many factors such as the processing capability of the host and peripheral devices file

attributes and other factors related to system configuration and operating environments the actual transfer

rate using the various USB connectors on this device will vary and will be slower than the data rate listed

below for each corresponding device.

USB devi e Data rate (Gbit/s)

3.2 Gen 1 5

3.2 Gen 2 10

3.2 Gen 2 × 2 20

Thunderbolt 3 40

Thunderbolt 4 40

Related topi s

“USB specifications” on page 3.

Rear

Item Des ription Item Des ription

1Emergency reset hole 2Security-lock slot

3Optional connector* 4 Wi-Fi® antenna slot

5 Ethernet connector 6 USB-A 3.2 Gen 1 connectors

7 HDMI™ out connector 8 USB-A 3.2 Gen 1 connector

9DisplayPort™ out connector 10 Power adapter connector

* for selected models

Optional onne tor

Depending on the Chromebox model the connector might be a DisplayPort out connector a USB-C

connector or an HDMI™ out connector.

Related topi s

• “Lock your Chromebox” on page 6.

• “Connect an external display” on page 5.

• “USB specifications” on page 3.

2ThinkCentre M60q Chromebox / ThinkCentre M60q Chromebox Enterprise User Guide

Features and spe ifi ations

For detailed specifications of your Chromebox go to https://psref.lenovo.com.

Spe ifi ation Des ription

Dimensions

• Width: 179.0 mm (7.0 inches)

• Height: 36.5 mm (1.4 inches)

• Depth: 182.9 mm (7.2 inches)

Weight (without pa kaging) Maximum configuration as shipped: 1.07 kg (2.35 lb)

Power supply • 65-watt automatic voltage-sensing power supply

• 90-watt automatic voltage-sensing power supply

Ele tri al input • Input voltage: From 100 V ac to 240 V ac

• Input frequency: 50/60 Hz

Memory

Double data rate 4(DDR4) small outline dual in-line memory module (SODIMM)

Maximum memory capacity: 32 GB

Storage devi e M.2 solid-state drive*

Video features

The integrated graphics card supports the following:

• DisplayPort out connector

• HDMI out connector

• USB-C (3.2 Gen 2) monitor connector

Expansion • Memory slots

• M.2 solid-state drive slot*

Network features

• Bluetooth

• Ethernet LAN

• Wireless LAN

* for selected models

USB spe ifi ations

Note: Depending on the model some USB connectors might not be available on your Chromebox.

Chapter 1.Meet your Chromebox 3

Conne tor name Des ription

• USB-A 3.2 Gen 1 connector

• USB-A 3.2 Gen 2 connector

Connect USB-A compatible devices such as a USB-A

keyboard USB-A mouse USB-A storage device or USB-

A printer.

• USB-C (3.2 Gen 2) connector

• Charge USB-C compatible devices with the output

voltage and current of 5 V and 3 A.

• Connect to USB-C accessories to help expand your

Chromebox functionality. To purchase USB-C

accessories go to https://www.lenovo.com/accessories.

4ThinkCentre M60q Chromebox / ThinkCentre M60q Chromebox Enterprise User Guide
