LENCO MES-212 Manuel utilisateur

USER'S MANUAL

MES-212

For information and supportWWW.lenco.com

17,5 cm (7”) portable dvd player

Before connecting, operating or adjusting this product,

please read this user's manual carefully and completely.

Important Safety Instructions

Warning: To reduce the risk of electric shock, do not remove the

cover or back. There are no user-serviceable parts inside. Refer

servicing to qualified personnel.

Warning: To prevent fire or electric shock hazard, do not expose

the unit to rain or moisture.

Do not expose the Adaptor and portable DVD to water (dripping or

splashing) and no objects filled with liquids, such as vases, should

be placed on the unit.

Keep the portable DVD away from direct sunlight and heat source

such as radiators or stoves.

Do not block the ventilation openings. Slots and openings on the

unit are provided for ventilation. The openings should never be

blocked by placing your portable DVD on a cushion, sofa or other

similar surface.

Do not place the portable DVD on unstable cart, stand, tripod,

bracket or table. The unit may fall, resulting In possible damage or

Injury.

Never place heavy or sharp objects on the LCD panel or frame.

Unplug the power from the outlet when the unit Is not in use.

WARNNING: Excessive sound pressure from earphones or

headphones can cause hearing loss.

WARNNING: Only use attachments/accessories specified

provided by the manufacturer.

This marking indicates that this product

should not be disposed with other household

wastes throughout the EU. To prevent

possible harm to the environment or human

health from uncontrolled waste disposal,

recycle it responsibly to promote the

sustainable reuse of material resources. To

return your used device, please use the

return and collection systems or contact the

retailer where the product was purchased.

They can take this product for environmental

safe recycling

To prevent possible heating damage, do not listen at high

volume levels for long periods.

Safety Precautions

Warning: This digital video disc player employs a laser system.

Use of controls, adjustments, or the performance of procedures

other than those specified herein may result in hazardous

radiation Exposure.

Warning: To prevent direct exposure to laser beam, do not open

the enclosure. Visible laser radiation when open.

Warning: Never stare directly into the laser beam.

Caution: Do not install this product in a confined space such as a

book case or similar unit.

Warning: more than 250mm USB extension cord is prohibited to

use for USB port

Notes on Copyrights:

It is forbidden by law to copy, broadcast, show, broadcast via

cable, play In public, or rent copyrighted material without

permission.

This product features the copy protection function developed

by Macrovision. Copy protection signals are recorded on some

discs. When recording and playing the pictures of these discs

picture noise will appear. This product incorporates copyright

protection technology that is protected by method claims of

certain U.S. Patents and other intellectual property rights

owned by Macrovision Corporation and other rights owners.

Use of this copyright protection technology must be authorized

by Macrovision Corporation, and is intended for home and

other limited viewing uses only unless otherwise authorized by

macrovision Corporation. Reverse engineering or disassembly

is prohibited.

SERIAL NUMBER:

You can find the serial number on the back of the unit. This

number is unique to this unit and not available to others. You

should record requested information here and retain this guide

as a permanent record of your purchase.

Model No.

Serial No.

Date of Purchase

WARNING

RISK OF ELECTRIC

SHOCK DO NOT OPEN

strong

over

heat

40°C

impact

Using the Car Power Adapter (for in-car use)

The included 12V car power adapter is designed for use with vehicles that have a 12v

negative ground electrical system.

Using the DVD Player Only

Mounting in the Vehicle

Use the supplied car mounting straps to install the main unit and monitor on the

back of the vehicle's headrests. Tightly wrap the mounting strap around the

headrest.

Monitor

right side

DVD player

left side

To the cigarette

lighter socket

DC+AV cable

(included)

To AV IN &

IN sockets

To AV OUT & DC

OUT sockets

To DC IN 9V

-12V

socket

Car Power Adapter

(included)

DVD player

left side

To the cigarette

lighter socket

To DC IN 9V

-12V

socket

Car Power Adapter

(included)

Identification of Controls

Main Unit

MONITOR TFT SCREEN

1. SETUP

2. / Up/Prev Short

press is Up Long press is

3. / Down/Next Short

press is Down Long

press is Next

4. /VOL- Left/VOL- Short

press is Left Long press

is VOL-

5. /VOL+ Right/VOL+

Short press is Right Long

press is VOL+

6. ENTER

7. SOURCE

8. ON/OFF

9. USB

10. Earphone Socket

11. AV OUT

12. DC OUT

13. DC IN 9-12V

14. MUTE

15. UP

16. Down

17. /VOL- Left/VOL-

Short press is Left

Long press is

VOL-

18. /VOL+

Right/VOL+ Short

press is Right

Long press is

VOL+

19. MODE

20. BACK LIGHT

21. DC IN 9-12V

22. AV IN

23. O Earphone

Socket

24.

ON/OFF

Insert the battery

1. Open the battery door. 2. Insert battery CR-2025.

When using the remote control for the first time do not forget to remove

the plastic card.

NOTES:

Remove battery during storage or when you are not using the

DVD player for a long time.

Hole

Identification of Controls

Remote control unit

1. ZOOM

Each press of the ZOOM button changes the TV screen in the following sequence: 2X

size 3X size 4X size 1/2 1/3 1/4.

2. SEARCH

Go to time point, title or chapter you want in DVD Mode.

3. SUBTITLE

Press SUBTITLE repeatedly during playback to hear a different subtitle languages.

4. ANGLE

Press ANGLE will change the view angle, on DVDs that support this feature.

5. TITLE

Return to DVD title menu.

6. ENTER

Confirms menu selection.

7. SETUP

Accesses or removes setup menu.

8. VOL-

Adjust VOLUME

9. REPEAT

Press REPEAT during playback to select a desired repeat mode.

DVD: you can play a chapter/title/all on a disc.

VCD CD: you can play a track/all on a disc.

Mp3 WMA: you can select Repeat one/Repeat folder/ALL play mode

on a disc.

10. SLOW

Press Slow button repeatedly to enter slow playback, and cycle

between different speeds. The speeds are 1/2, 1/3, 1/4,1/5,1/6,

1/7 and normal.

11. PROGRAM

DVD VCD CD MP3: The program function enables you to store your

favourlte tracks from the disc. Press PROGRAM button, then

PROGRAM MENU will appear on screen, now you can use the

number or direction keys input the titles, chapters or tracks number

and select PLAY option to resume normal playback, press PROGRAM

and select CLEAR option on the program menu.

JPEG: You can press PROGRAM repeatedly toselect the slide show

mode, there are 6 types slide show mode.

12. DISPLAY

To display the playtime and status information.

13. SOURCE

DVD/USB.

VOL -

VOL+

REPEAT

TITLE

ENTER

RETURN

ZOOMMUTE

SOURCE

214

Identification of Controls

Remote control unit

14. MUTE

Disable Audio output.

15. 0-9 NUMBER BUTTON

Selects numbered items in a menu.

16. 10+ BUTTON

In order to select a track 10 or greater, first press 10 + , For example; select track 12,

first press 10+, and then press number 2 button.

17. STEP

Press STEP once to pause playback, Form this station, press STEP to advance one

video frame.

18. MENU

Accesses menu on a DVD disc, PBC on/off switch for VCD.

19. AUDIO

DVD: Press AUDIO repeatedly during playback to hear a different audio language or

audio track, If available.

VCD: Press AUDIO repeatedly during playback to hear a different audio channel

(Stereo, Left, or Right).

20. PLAY/PAUSE

Press PLAY/PAUSE once to pause playback, pressing PLAY/PAUSE second time

will resume the playback.

21. STOP

When this button is pressed once, the unit records the stopped point, from where

playback will resume if ENTER is pressed after wards. But if STOP button is pressed

again instead of ENTER button, there will be no resume function.

22. RETURN

Return to upper page.

23. VOL +

Adjust VOLUME.

24. Forward Skip

Go to next chapter/track.

25. Reverse Skip

Go to previous chapter/track to the beginning.

26. BUTTON

Press BUTTON allow skipping ahead at 5-level speed(X2->

X4->X8->X20), press ENTER button return to normal playback

27. BUTTON

Press BUTTON allow skipping back at 5-level speed(X2->

X4->X8->X20), press ENTER button return to normal playback.

SETUP Menu Setting

System Setup Page

Press SETUP button to get the setup menu. Use direction buttons

to select the preferred item. After finishing settings, press

SETUP again to normal display.

System Setup

TV System

Selecting the color system that corresponds to your TV when AV

output. This DVD Player is compatible with both NTSC and PAL. PAL -

Select this If the connected TV is PAL system. It will change the video

signal of a NTSC disc and output in PAL format.

NTSC - Select this if the connected TV Is NTSC system. It will change

the video signal of a PAL disc and output in NTSC format.

Power Resume

This function is used to turn the last memory on or off.

TV Type

Selects the aspect ratio of the playback picture.

4:3 PS: If you have a normal TV and want both sides of the picture to be

trimmed or formatted to fit your TV screen.

4:3 LB: If you have a normal TV. In this case, a wide picture with black

bands on the upper and lower portions of the TV screen wilI be displayed.

16:9: wide screen display.

Default

Restore the factory setting of setup menu.

Language Setup Page

Language setup

You can select OSD language, and select audio/subtitle/menu

language of DVD discs if available. Also you can select font type for

mpeg4 subtitle.

TV SYSTEM

POWER RESUME ON

OFF

NTSC

PAL

TV TYPE 4:3 PS

4:3 LB

16:9

DEFAULT

RESTORE

SYSTEM SETUP

OSD LANGUAGE

AUDIO LANG

SUBTITLE LANG

MENU LANGUAGE

LANGUAGE SETUP

11ENGLISH

FRENCH

GERMAN

SPANISH

DUTCH

POLISH

HUNGARIAN

ENGLISH

FRENCH

GERMAN

SPANISH

DUTCH

POLISH

HUNGARIAN

OFF

ENGLISH

FRENCH

GERMAN

SPANISH

DUTCH

POLISH

HUNGARIAN

ENGLISH

FRENCH

GERMAN

SPANISH

DUTCH

POLISH

HUNGARIAN

SETUP Menu Setting

Audio Setup Page

The function is use to select standby setting: OFF, 3 HOURS,

4 HOURS

OFF: No standby

3 HOURS: No remote control and panel key operation within three hours into

standby

4 HOURS: No remote control and panel key operation within four hours into

standby

In standby mode, switch ON/OFF selector to OFF and ON to resume use.

Video Setup Page

You can change the video setting: brightness, contrast, hue,

saturation.

MONITOR TFT MENU SETTING

PICTURE Page

Brightness

Adjust screen Bright Setting.

Contrast

Adjust screen Contrast Setting.

Color

Adjust screen Color Setting.

ENGLISH

Adjust Menu OSD Language

SCREEN

Adjust screen SCREEN 16:9 or 4:3

AUTO STANDBY

OFF

3 HOURS

4 HOURS

STANDBY SETTING

BRIGHTNESS

CONTRAST

HUE

SATURATION

SHARPNESS

-2

-4

-6

VIDEO SETUP

PIC TURE

BRIG HT

C ONTRAST

C OLOR

ENG LISH

RESET

16: 9

OPTIO N

SC REEN

Parameters and specifications

Electronical parameters

Item Standard requirement

Power consumption : <15W

Operating humidity : 5 % to 90 %

output

VIDEO OUT : 1 Vp-p (75Q )

AUDIO OUT : 1.2 Vrms (1 KHz, 0 dB)

System

Laser : Semiconductor laser, wavelength 650 nm

Signal system : NTSC/PAL

Frequency response : 20 Hz to 20 kHz(1 dB)

Signal-to-noise ratio

: More than 80 dB (ANALOG OUT connectors only)

Dynamic range : More than 85 dB (DVD/CD)

Note: Design and specifications are subject to change prior notice.

Service and support

For information: www.lenco.com

Lenco offers service and warranty in accordance to European law, which means

that in case of repairs (both during and after the warranty period) you should

contact your local dealer.

Important note: It is not possible to send products that need repairs to Lenco

directly.

Important note: If this unit is opened or accessed by a non-official service center

in any way, the warranty expires.

This device is not suitable for professional use. In case of professional use, all

warranty obligations of the manufacturer will be voided.

Products with the CE marking comply with the EMC Directive

(2004/108/EC) and the Low Voltage Directive (2006/95/EC)

Issued by the Commission of the European Community.

The declaration of conformity may be consulted at

https://lencosupport.zendesk.com/forums/22413161-CE-Docum

ents

The declaration of conformity may be consulted at

https://lencosupport.zendesk.com/forums/22413161 -CE-Documents

This symbol indicates that the relevant electrical product or

battery should not be disposed of as general household waste

in Europe. To ensure the correct waste treatment of the product

and battery, please dispose them in accordance to any

applicable local laws of requirement for disposal of electrical

equipment or batteries. In so doing, you will help to conserve

natural resources and improve standards of environmental

protection in treatment and disposal of electrical waste (Waste

Electrical and Electronic Equipment Directive).

®AII rights reserved

Autres manuels pour MES-212

Table des matières

Langues :

Autres manuels LENCO Lecteur DVD portable

LENCO

LENCO MES-405 Manuel utilisateur

LENCO

LENCO MES-4031 Manuel utilisateur

LENCO

LENCO DVP-722 - Manuel utilisateur

LENCO

LENCO DVP-9412 Manuel utilisateur

LENCO

LENCO DVP-738X2 Manuel utilisateur

LENCO

LENCO DVP-1273 Manuel utilisateur

LENCO

LENCO MES-219 MPEG4 - Manuel utilisateur

LENCO

LENCO DVP-947 BK Manuel utilisateur

LENCO

LENCO TDV901 Manuel utilisateur

LENCO

LENCO MES-219 MPEG4 - Manuel utilisateur

LENCO

LENCO DV-9831 Manuel utilisateur

LENCO

LENCO DVP-931 Manuel utilisateur

LENCO

LENCO DVP-938 Manuel utilisateur

LENCO

LENCO DVR-70 Manuel utilisateur

LENCO

LENCO DTVR-700 Manuel utilisateur

LENCO

LENCO DVP-744 Manuel utilisateur

LENCO

LENCO DVP-1063 Manuel utilisateur

LENCO

LENCO DVP-74 Manuel utilisateur

LENCO

LENCO DVP-1064BK Manuel utilisateur

LENCO

LENCO DVP-1022 Manuel utilisateur

LENCO

LENCO DVP-734 Manuel utilisateur

LENCO

LENCO TDV-900 Manuel utilisateur

LENCO

LENCO MES-204 Manuel utilisateur

LENCO

LENCO DVP-1023 CR - Manuel utilisateur

Manuels Lecteur DVD portable populaires d'autres marques

Philips

Philips PET718/77 Manuel utilisateur

Impecca

Impecca DVP775 Manuel utilisateur

NextBase

NextBase MULTI-VISION SET PRO Manuel utilisateur

Impecca

Impecca DVP-1017 Manuel utilisateur

Akura

Akura APDVD6008 Manuel utilisateur

TV Star

TV Star TD3 LCD COMBO Manuel utilisateur

Philips

Philips PET940/98 Manuel utilisateur

Philips

Philips PET702P Manuel utilisateur

Philips

Philips PD7016 Manuel utilisateur

Logik

Logik L7SPDVD11 Manuel utilisateur

LG DP650 Manuel utilisateur

Mustek

Mustek MVP850B Manuel utilisateur

Insignia

Insignia NS-MDDVD10 Manuel utilisateur

Philips

Philips PD9000/12 Manuel utilisateur

Philips

Philips PD7010/05 Manuel utilisateur

Technika

Technika PDVDTWINSS10 Guide de l'utilisateur

Philips

Philips PD7006/51 Manuel utilisateur

Insignia

Insignia NS-P10DVD11 Guide de démarrage rapide
