2TM6100A
Introduction
Introduction
Purchase Congratulations on the purchase of a TM6100A instrument.
This manual contains important safety directions as well as instructions for setting
up the product and operating it. Refer to "6 Safety Directions" for further informa-
tion.
Read carefully through the User Manual before you switch on the product.
Product
identification
The type and the serial number of your product are indicated on the type plate.
Enter the type and serial number in your manual and always refer to this information
when you need to contact your agency or Leica Geosystems authorized service work-
shop.
Type: _______________
Serial No.: _______________
Introduction TM6100A 3
Symbols The symbols used in this manual have the following meanings:
Type Description
Danger Indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
Warning Indicates a potentially hazardous situation or an unintended use
which, if not avoided, could result in death or serious injury.
Caution Indicates a potentially hazardous situation or an unintended use
which, if not avoided, may result in minor or moderate injury
and/or appreciable material, financial and environmental
damage.
Important paragraphs which must be adhered to in practice as
they enable the product to be used in a technically correct and
efficient manner.
Trademarks • CompactFlash and CF are trademarks of SanDisk Corporation
• Bluetooth is a registered trademark of Bluetooth SIG, Inc
All other trademarks are the property of their respective owners.
Validity of this
manual Description
General This manual applies to all TM6100A instruments.
4TM6100A
Introduction
Available
documentation Name Description and Format
User Manual All instructions required in order to operate the product
to a basic level are contained in the User Manual.
Provides an overview of the product together with
technical data and safety directions.
Name Description and Format
System
Field Manual
Describes the general working of the product in
standard use and specific onboard application
programs. Intended as a quick reference field guide.
Technical
Reference
Manual
Overall comprehensive guide to the product and
program functions. Included are detailed descriptions
of special software/hardware settings and soft-
ware/hardware functions intended for technical
specialists.
Refer to the following resources for all TM6100A documentation and soft-
ware
• the TPS6000 Product CD
• http://metrology.leica-geosystems.com/en/Downloads_6843.htm
Table of Contents TM6100A 5
Table of Contents
In this manual Chapter Page
1 Description of the System 8
1.1 System Components 8
1.2 System Concept 11
1.2.1 Software Concept 11
1.2.2 Data Storage and Data Conversion Concept 13
1.2.3 Power Concept 15
1.3 Container Contents 16
1.4 Instrument Components 17
2 User Interface 20
2.1 Keyboard 20
2.2 Hot Key Assignments 24
2.3 Screen 27
2.4 Operating Principles 29
2.5 Icons 35
3 Operation 37
3.1 Instrument Setup 37
3.2 Battery 40
3.2.1 Operating Principles 40
6TM6100A
Table of Contents
3.2.2 Instrument Battery 41
3.3 Working with the CompactFlash Card 43
3.4 Accessing Survey Application Program 46
3.5 Built-in autocollimation device 49
3.6 Connection to Application Computer 51
3.7 Limitation of the horizontal and vertical movements 55
4 Check & Adjust 60
4.1 Overview 60
4.2 Preparation 63
4.3 Combined Adjustment (l, t, i and c) 65
4.4 Tilting Axis Adjustment (a) 69
4.5 Adjusting the Circular Level of the Instrument and Tribrach 74
4.6 Adjusting the Circular Level of the Prism Pole 76
4.7 Inspecting the Laser Plummet of the Instrument 77
4.8 Servicing the Tripod 79
4.9 Adjustment of the autocollimation reticule 80
5 Care and Transport 82
5.1 Transport 82
5.2 Storage 84
5.3 Cleaning and Drying 85
5.4 Maintenance 87
Table of Contents TM6100A 7
6 Safety Directions 88
6.1 General Introduction 88
6.2 Intended Use 89
6.3 Limits of Use 91
6.4 Responsibilities 92
6.5 Hazards of Use 93
6.6 Laser Classification 99
6.6.1 General 99
6.6.2 Laser Plummet 101
6.7 Electromagnetic Compatibility EMC 104
6.8 FCC Statement, Applicable in U.S. 107
7 Technical Data 110
7.1 Angle Measurement 110
7.2 Conformity to National Regulations 111
7.2.1 Communication side cover with Bluetooth 111
7.3 General Technical Data of the Instrument 112
8 International Limited Warranty,
Software License Agreement 119
1 - 8TM6100A
Description of the System
1 Description of the System
1.1 System Components
Main components
TM6100A_001
TM6100A
Component Description
TM6100A • an instrument of highest accuracy for measuring, calculating
and capturing data.
• connected with LGO Tools to view, exchange and manage data.
Application
Software
Third party metrology software with an interface to the TM6100A
for acquisition, analysis, management and reporting of data.
LGO Tools An office software consisting of a suite of standard and extended
programs for the viewing, exchange and management of data.
Description of the System TM6100A 1 - 9
Terminology The following terms and abbreviations may be found in this manual:
Term Description
TPS Total Station Positioning System
LGO Tools LEICA Geo Office Tools
Motorised TM6100A instruments are fitted with internal motors, enabling
automatic horizontal and vertical turning are referred to as
Motorised.
Communication
side cover
Communication side cover with integrated Bluetooth is a compo-
nent with external devices, i.e. laptop with application software.
1 - 10TM6100A
Description of the System
Instrument models Model Description
TM6100A Electronic theodolite, motorised, 0.5" accuracy.
LEICA Geo Office
Tools
• LGO Tools supports TM6100A instruments. It also supports all other Leica TPS
instruments.
•LGO Tools is based on a graphical user interface with standard Windows® oper-
ating procedures.
• LGO Tools provides the following functionality:
Functionality Description
Standard
Functionality
Includes data exchange between computer and instrument, data
management including viewing and editing, reporting, creation
and management of codelists, creation and use of format files for
data conversion, uploading and deleting of system software and
application programs.
• Supported operating systems: Windows® XP, Windows® 2000.
• Refer to the online help of LGO Tools for additional information.
