LEGRAND HKRL20 Manuel utilisateur

installation guide

Smart Remote Switch

Room . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

HKRL20

table of contents

before you start..................................3

what you need ...................................4

getting to know your remote switch

........................................................6-7

installation and setup ................ 8–22

faqs ..............................................23

regulatory information ......... 24–27

warranty.......................................28

support ........................................29

before you start

Review this guide in its entirety before beginning device installation. Consult an

electrician with any questions or if you are unsure of your abilities.

DWarning: Incorrect installation could

result in death, serious injury, and/or

damage to your home or devices:

• For dry, indoor use only.

• Connect the smart remote switch to a

120 VAC, 60 Hz power source ONLY.

• The remote switch pairs ONLY with

the smart switch (HKRL10) for multi-

location control.

• The remote device does NOT connect to

any lighting loads. It is powered by your

electrical wiring and uses a wireless

connection to control its paired devices.

• Always use copper wire to install the

smart remote switch and follow all

applicable local and national electrical

codes.

• Install in a non-metallic electrical box

to protect wireless signal strength.

Visit the Legrand website at www.legrand.us/radiant/homekit.aspx to learn more about

your smart device.

what you need

REQUIRED:

Phillips-head screwdriver

Flat blade screwdriver

YOU MAY ALSO NEED:

Non-contact voltage tester, pliers, wire cutter, wire stripper, electrical tape,

ﬂashlight, radiant®screwless wallplate (included), wiring leads (included), and

wire nuts (included)

NOTE: Exercise caution when using power tools. Overtightening the screws can

damage the device.

getting to know your remote switch

Item Name Description

1 Paddle Switch

• Press the top of the paddle to turn the light on and

the bottom to turn the light off.

• To return the switch to factory default, press and

hold the top of the paddle for 15 seconds. Then,

remove the device from the Legrand Home app (or

Apple Home app).

2 LED Locator Light Indicates the current state of the device. Refer to

“LED Locator Light Explanations” for detail.

LED LOCATOR LIGHT EXPLANATIONS

LED

Color State of Light Explanation

Slowly Flashing

Amber

Device is attempting to connect to

the network

Solid White Connected to Wi-Fi and turned off

No Light Device is on

Rapidly Flashing

Green

N-Way Pairing mode: device is

attempting to pair with the master

Rapidly Flashing

Amber N-Way pairing is updating

Solid Amber N-Way pairing is successful

installation & setup

step one

turn off power for your device at the

circuit breaker

Flip the existing light switch multiple times to conﬁrm the power is off.

NOTES:

• If there are multiple devices next to your existing light switch, make sure power is

off at the circuit breaker for all of those devices.

• If you are installing your master device at the same time as the remote device,

make sure power is off to both devices.

• For detailed instructions on how to install your three-way remote product, please

visit legrand.us/3wayinstallationinstructions.

OFF

installation & setup

step two

remove the existing device

Check for the following wires:

1HOT or LINE: Receives power from the circuit box. Referred to as “hot” for the

purposes of this guide. Do not touch or let “hot” wires contact other wires.

2LOAD: Directs power to your light(s).

3NEUTRAL: Creates a path to return current to the power source, when the

device is off. Required for your switch installation.

4GROUND: Provides a safe path for electricity in the event of a short circuit.

5TRAVELER: Connects power between the three-way wiring devices. Not required for

your switch installation. Cap all traveler wires.

NOTE: Refer to the “faqs” on page23 if you are unsure of your wiring.
