Leader Fox Runner Manuel utilisateur

Electric Bicycle Operating

Instructions

Under the law, the dealer is obliged to attach the LEADER FOX Electric Bicycle Operating Instructions to every product

Runner

E –BIKE POWER RIDE

Introduction

Dear users,

Please read carefully all the information regarding your E-LF product to ensure optimal functioning of your

e-bike. The following text containing a comprehensive description will provide you with information on all

aspects and details (including installation, setting up and general use of the display) regarding the use of

our display. This instruction document will also help you solve potential problems and failures.

What is an electric bicycle?

Electric bicycle is a conventional bicycle with an electric drive added to assist the rider. The motor function

is actuated by pedalling, which is scanned by a special sensor installed in the pedal hub. Therefore, you

have to keep pedalling on an e-bike, the motor is there only to help you. You can set an electric bicycle in

motion also using a control button or an accelerator but only up to the maximum permitted speed of 6

KMPH (e.g. for walk assistance). The maximum speed of an e-bike with motor assistance is 25 KMPH, with

a 10% tolerance (when this speed limit is reached, the motor switches off and you need to pedal just like

with a regular bicycle). When your battery runs out of power or your motor is off, you can ride your

electric bicycle as a conventional bike, without any resistance at all.

From the point of view of the Road Traffic Act, an electric bicycle whose features conform to European

standard EN 15194-1 is regarded as a regular bicycle, i.e. you can ride on bike trails, do not need a driver's

license and a helmet is mandatory only up to 18 years of age.

Description

Intelligent display with control

Motor Battery

Factors influencing the electric bicycle range

1. Rolling resistance of the tyres. Leader Fox e-bikes are fittet with tyres with low rolling resistance and

increased resistance to puncture. It is also important that the tyres are inflated properly. Therefor, if the

tyres of your electric bicycle are underinflated, the range will decrease.

2. Weight of the electric bicycle. The lower weight of the electric bicycle, the greater the range.

3. Battery status. It depends on whether the battery was fully charged before your trip. It is also to be

expected that the higher the number of discharge cycles the battery has undergone, the smaller capacity

it has.

4. Profile and surface of the track. The higher the elevation difference and the steeper hills you negotiate

and the worse surface, the shorter the range.

5. Riding mode. It depends on which of the three riding modes you have set.

6. Continuity of riding. The more braking and acceleration, the shorter the range.

7. Air resistance. For example, it depends on whether we ride a bicycle with low frame and sitting upright

or whether we ride sporty bicycle with seat set to the same height as the handlebars.

8. Wind strength. The stronger the wind we have beck, the longer the range and vice versa.

9. Weight of the rider and load. The greater the weight, the shorter the range.

10. External temperature. The lower the temperature, the less battery capacity can be used while riding.

Electric set

Fazua Evation 1.0 drivepack

The system uses monitoring of torque, monitoring of speed of the pedal assist system and monitoring of real

speed of wheels.

The system uses a dual protection feedback for measuring the speed signal to ensure safety and reliabilityof

the system.

It has high starting torque, maximum torque of 60 Nm, suitable especially for riding uphill.

It is highly efficient with low power consumption, long range, low noise levels, and smooth operation.

Description and specification

Dimensions of the power unit:

1 –Drivepack

2 –Battery slot

3 –Interface to Bottom Bracked

4 –USB slot

5 –Slot detail

6 –Release button

7 –Pressing chock

8 –Fastening hook

9 –Battery lock

10 –Key

Bottom bracket:

Article number 01-2018-002-01

Assistance Torque, max. 60 Nm

Q Factor, min. 135 mm (w/o crank arms)

Operating temperature -20 + 60 °C

Storage temperature -20 + 60 °C

Degree of protection IP 54

Chainline 49, 52 mm

Weight , approx. 1.3 kg

Locking/unlocking the drivepack within your eBike

Once a Drivepack (1) is mounted in the eBike, it can be locked in so that the Drivepack cannot be removed. To

lock a mounted Drivepack, insert the key (10) into the lock cylinder (9) and turn it counter-clockwise. To

unlock the Drivepack from the eBike, insert the key into the cylinder and turn it clockwise.

Safety instruction

Do not open the Drivepack yourself. The Drivepack is free of maintenance. It must only be opened by qualified

experts and repaired with original spare parts. Unauthorized opening of a system would lead to its warranty

expiration.

All components making up the Drivepack and eBike may only be replaced with identical components or

specifically approved by your eBike manufacturer. This protects your drivepack from damage.

Don’t modify the Drivepack or add any other non-approved product to enhance performance.

Always remove the Drivepack from the eBike before working on your eBike, transportation or storage. There is

risk of accident in case of accidental activation.

Be careful when touching the radiator of your Drivepack. The radiator may heat up considerably and cause

skin burns.

The walk-assistance function may only be used when pushing the eBike. There is risk of injury if the wheels do

not have ground contact when using this function.

Use only original evation batteries approved by the eBike manufacturer. Using unauthorized batteries may

cause injuries or fire. FAZUA will not assume responsibility if unauthorized batteries are used.

Observe all national regulations in reference to eBikes and pedelecs.

Do not open the Bottom Bracket yourself. The Bottom Bracket is free of maintenance. It may only be opened

by qualified experts and repaired with original spare parts. Unauthorized opening of a system would lead to its

warranty expiration.

All components making up the Bottom Bracket and eBike may only be replaced with identical components or

specifically approved by your eBike manufacturer. This protects your Drivepack from damage.

Don’t modify the Bottom Bracket or add any other non-approved product to enhance its performance.

Do not open the drive system’s components by yourself. The components are free of maintenance. They may

only be opened with qualified experts and repaired with original spare parts. Unauthorized opening of a

system would lead to its warranty expiration.

Stay aware of the traffic and your environment when manipulating the evation Remote. There is a risk of

accident if you do not focus on the traffic.

Remove the Battery Pack from the Drivepack before carrying out cleaning works. Humidity on the contacts of

your Drivepack when the Battery Pack is being inserted may damage your Battery Pack.

Do not open the Battery Pack. Danger of explosion. Opening the Battery Pack assumes an automatic

expiration of the warranty.

Use the Battery Pack exclusively with eBikes that have an original FAZUA evation drive system.

Use only original evation Battery Packs approved by the eBike manufacturer. Using unapproved batteries may

cause injuries or fire. FAZUA will not be liable for using unapproved batteries.

Use only original FAZUA chargers for charging the Battery Pack. FAZUA will not be liable for damage caused by

the use of unapproved chargers.

Keep the Battery Pack away from heat, fire and water. Risk of explosion.

Protect the Battery Pack from mechanical impacts or stress. Risk of damage and emission of fumes, which can

irritate the respiratory system. Provide fresh air and seek medical assistance in case of discomfort.

Watch out for metal objects such as coins, paper clips, screws, etc etc. in the vicinity of the Battery Pack. They

can produce a connection between the terminals of the Battery Pack. Danger of fire. Damage caused this way

will not be covered by the warranty.

Keep the Battery Pack away from flammable materials. Make sure the Battery Pack is dry and placed in a

fireproof area when charging. Heat produced while charging may cause fire.

Do not leave the Battery Pack unattended when charging.

Never use or charge a damaged Battery Pack.

Avoid contact with any liquid that may be discharged by the Battery Pack. Flush with abundant water in case

of contact with such liquid. Any contact with such liquid may produce irritations and burns. If liquid contacts

eyes, look for medical assistance.

Keep the Battery Pack and Charger away from pacemakers. Magnetic connectors can affect their functionality.

Keep the Battery Pack out of reach of children.

Keep your charger away from water or moisture. Otherwise there is a high risk of electric shock.

Charge only original evation Battery Packs approved by the eBike manufacturer. Otherwise there is risk of fire

and explosion.

Do not open the Charger. It must only be opened by qualified experts and repaired with original spare parts.

Check the Charger, cable and plug before each use. If you detect damage, do not use it. There is a high risk of

electric shock.

Keep your Charger clean. Dirt on the Charger increases the risk of electric shock.

Keep the Charger and Battery Pack away from flammable materials. Make sure the Charger and Battery Pack

are dry and placed in a fireproof area when charging. Heat produced while charging may cause fire.

Be careful when touching the charger while charging or right after the charging is over. The charger may heat

up considerably.

Do not leave the Charger unattended when charging.

Persons not capable of safely operating the charger may only use the Charger under supervision.

Keep the Charger out of reach of children.

Fumes may come out of the Battery if damaged. Provide fresh air and seek medical assistance in case of

discomfort.

Keep the Battery Pack and Charger away from pacemakers. Magnetic plugs can affect their functionality.
