Laserworld Evolution Series Manuel utilisateur

Manual / Bedienungsanleitung /

Mode d´emploi

Evolution Series

ES-600B

Please spend a few minutes to read this manual fully

before operating this laser!

Bitte lesen Sie diese Bedienungsanleitung sorgfältig

vor Inbetriebnahme dieses Showlasersystems!

Avant d’utiliser cet appareil pour la première fois nous vous recommandons

de lire cette notice d’utilisation!

04/2016

English

Deutsch

Français

Manual: Evolution Series ES-600B

page 2 / 27

Rechtlicher Hinweis:

Die Firma Laserworld AG behält sich das Recht vor, Änderungen an ihren Produkten vorzu-

nehmen, die der technischen Weiterentwicklung dienen. Diese Änderungen werden nicht

notwendigerweise in jedem Einzelfall dokumentiert.

Diese Betriebsanleitung und die darin enthaltenen Informationen wurden mit der gebote-

nen Sorgfalt zusammengestellt. Die Firma Laserworld AG übernimmt jedoch keine Gewähr für

Druckfehler, andere Fehler oder daraus entstehende Schäden.

Die in dieser Bedienungsanleitung genannten Marken und Produktnamen sind Warenzeichen

oder eingetragene Warenzeichen der jeweiligen Titelhalter.

Legal notice:

Thank you for purchasing this Laserworld product. Due to continual product developments

and technical improvements, Laserworld (Switzerland) AG reserves the right to make modi-

cations to its products.

This manual and its content have been made with due care but Laserworld (Switzerland) AG

cannot however, take any responsibility for any errors, omissions or any resulting damages

forthwith.

The brands and product names mentioned in this manual are trade marks or registered trade

marks of their respective owners.

Information juridique :

L’entreprise Laserworld (Switzerland) AG se réserve le droit d’eectuer des modications con-

cernant leurs produits et ainsi de répondre au développement technique. Ces modications

ne seront pas nécessairement annoncées en tout cas spécique. Ce mode d’emploi et les in-

formations contenues dedans ont été établis avec le soin minutieux qui s’impose dans ce cas.

Laserworld (Switzerland) AG ne pourra pas être tenue responsable pour d’éventuelles erreurs

d’impression ou dommages en résultants.

En cas de doutes, veuillez toujours contacter Laserworld (Switzerland) AG . Les noms de

marques et de produits utilisés dans ce mode d’emploi sont des marques de fabrique ou des

marques déposées.

L’utilisation est réservée à un usage professionnel selon décret n°2007-665 du 2 mai

2007 relatif à la sécurité des appareils à laser sortant!

Article 4 bis :

« Les usages spéciques autorisés pour les appareils à laser sortant d’une classe supérieure à 2

sont les usages professionnels suivants :

(…)

9° Spectacle et achage :

Toutes les applications de trajectoire, de visualisation, de projection ou de reproduction

d’images en deux ou trois dimensions. »

Manual: Evolution Series ES-600B

page 3 / 27

Content:

1. Product and package contents

2. Preliminary warning notices

3. Initial operations, safety instructions

4. Working on the device

5. Service notes

6. Warnings and other notices on the device

7. Device connections

8. Operation

Final statement

Technical data sheet

Laser specications

Manual: Evolution Series ES-600B

page 4 / 27

1. Product and package contents

Please check if all listed parts are included and undamaged. Included in delivery:

1 x laser projector 1 x Interlock adapter

1 x power cable 2 x key

1 x manual

3. Initial operations, safety instructions

1. Make sure to use correct voltage; see in-

formation on device & in this manual.

2. Make sure that the device is not connec-

ted to mains during installation.

3. Installation has to be done by technical

experienced and qualied persons ac-

cording to safety regulations of the res-

pective country.

4. Always ensure that maximum permissib-

le exposure (MPE) is not exceeded in are-

as accessible to the public or members of

sta.

5. In some countries an additional ins-

pection by technical control institutes

could be necessary.

6. Connect an easily accessible inter-

lock connector or circuit breaker

to the projector.

7. The power supply should be easily acces-

sible.

8. When installing the laser mount it with

a minimum distance of 15 cm from walls

and objects.

9. For safe setup e.g. on walls or ceilings

please use a safety cord. The safety cord

should be able to withstand tenfold the

weight of the device. Please follow the

accident prevention regulations of pro-

fessional associations and/or comparable

regulations for accident prevention.

2. Preliminary warning notices

1. Please use this device only according to these operating instructions.

2. Do not use the device if there are any visible damages on housing, connector panels,

power supplies or power cords.

3. Never look directly into the light source of a laser projector. Danger of damage to the

eyes or even blindness in extreme circumstances!

4. Do not operate the device at high humidity, in the rain or in dusty environments.

5. Protect device against dripping or splashing water. Do not place any liquid lled

containers near to this device.

Any warranty claims are void if the warranty label is removed or tampered

with in any way.

Manual: Evolution Series ES-600B

page 5 / 27

10. If the device has been exposed to great

temperature changes, do not switch it

on immediately. Condensation (or any

moisture/water formed) may damage

device.

11. Never use dimmer, RC or other electroni-

cally switched sockets. Whenever possib-

le, do not use the laser projector together

with large appliances (especially fog ma-

chines) on the same mains!

12. Ensure sucient ventilation and do not

place the device on any warm or heat ra-

diating surface. Especially the ventilati-

on openings must not be covered!

13. Ensure that device does not get over-

heated. Make sure that the device is not

exposed to spotlights (especially moving

heads). Heat of spotlights could overheat

laser in a little while and leads to a degra-

dation of performance.

14. This unit is intended for indoor use only.

4. Working on the device

1. This product has no user serviceable parts inside and should

only be maintained and serviced by a qualied engineer.

2. Be sure that the mains plug is not connected to the power

supply while installing or opening the device (e.g. for

cleaning).

3. Take o all reecting things like rings, watches etc. befo-

re starting to work with or at the projector.

4. Only use non-reecting tools to work on device.

5. Wear protective clothing (like goggles, gloves etc.) according to laser power and wave-

length of the laser.

5. Service notes

• Moisture and heat can reduce lifetime of

the laser system dramatically and expires

any warranty claim.

• Quick on/o switching of this device will

reduce durability of the laser diode dra-

matically.

• Avoid sharp knocks and shocks to this

device and ensure sucient protection

during transportation. Look after your La-

serworld product.

• To increase durability of your laser,

protect device against overheating:

• Always ensure sucient ventilation.

• Do not face spotlights (especially moving

heads) to the device.

• Check temperature after approx. 30 mi-

nutes with each new installation. If neces-

sary install the projector at a place with

dierent temperature.

• Keep the device dry. Protect it from mois-

ture, rain and damp.

• Switch o device when it is not needed.

Diodes are switched on and can wear out

even if there is no visible laser output.

Manual: Evolution Series ES-600B

page 6 / 27

• The devices of Ecoline, Evolution, Club

and Proline Series are not meant for pro-

fessional applications. After approx. one

hour of operation, the device should cool

down for about 15 minutes.

• Please ensure the fans and heatsinks are

clear from dust and debris otherwise the

risk of overheating may occur. If the unit

and airways appear to be blocked then

please contact a qualied service engi-

neer to maintain and service the product.

• Removal of the warranty label as well

as damages to the device caused by

improper handling, neglect of the sa-

fety instructions and service notes will

void the warranty.

6. Warnings and other notices on the device

Laser radiation!

Avoid exposure

to beam.

Laser class 4

Caution of

radiation if cover

is removed Power supply

& consumption

Model type

Wavelength

Output power

Production

year

Please read manual before operation

Use in enclosed spaces only!

7. Device connections

Connection for

power supply

DMX in

DMX out

Fan

Key switch

Interlock

LED signal

DMX address

Power switch

Manual: Evolution Series ES-600B

page 7 / 27

8. Operation

1. Connect the power cable to the device and then to the mains

2. Insert key and turn it„ON“

3. Press„ON“ to switch on your device

4. Please make sure, that the Interlock adapter is inserted.

5. Your device runs in auto mode:

6. Your device runs in music mode:

Control the music-sensitivity by the trim pot at the front side of the device. The LED is

ashing when the device is triggered.

Microphone &

Sensitivity

Manual: Evolution Series ES-600B

page 8 / 27

7. Your device runs in DMX mode if ‘10‘ is switched o:

Connect a DMX controller to operate the laser.

Use the switches 1 - 9 to set the DMX address of the laser. Each switch represents a num-

ber. To dene a number use the preceding number and multiply it by 2:

The laser uses 12 DMX channels, so make sure that the next device uses an address that

doesn’t overlap with this range.

Channel Value Function

1 0 - 63 Laser o

64 - 127 Sound mode

128 - 191 Automatic mode

192 - 255 DMX mode

2 0 - 255 Patterns

3 0 - 255 Strobe (with increasing speed)

4 - -

5 0 - 255 horizontal movement (not for all patterns)

0 - 161 movement on the X axis

161 - 189 see above; right to left

190 - 219 see above; left to right

220 - 255 see above; changing movements

6 0 - 255 vertical movement (not for all patterns)

0 - 160 movements on the Y axis

161 - 189 see above; bottom to top, automatically

190 - 219 see above; top to bottom, automatically

220 - 255 see above; changing movements

7 11 - 255 Zoom / size (not for all patterns)

0 - 10 -

11 - 90 increasing size

Switch 12345678910

Number 1 2 4 8 16 32 64 128 256 Mode Switch

Manual: Evolution Series ES-600B

page 9 / 27

Channel Value Function

91 - 146 see above; small to large, automatically

147 - 200 see above; large to small, automatically

201 - 255 see above; small to large to small, automatically

8 - -

9 > 200 Reset (shortly over 200)

10 0 - 255 Rotation Y (height)

0 - 150 static rotation

151 - 255 automatic rotation

11 0 - 255 Rotation X (width): analogue to channel 10

12 0 - 255 Rotation Z

0 - 180 see above; static rotation

181 - 217 see above; automatic rotation clockwise

218 - 255 see above; automatic rotation counter clockwise

Please note that not each pattern can be combined with each eect.

8. To turn o the device switch it o („OFF“), switch the key to‚OFF‘ and disconnect the

power cable from the mains.

Manual: Evolution Series ES-600B

page 10 / 27

Final statement

Laserworld products are tested and product packaging is inspected before leaving our

warehouse.

Users must to follow the local safety regulations and warnings within this manual and adhere

to any regulations within its place of use. Damages through inappropriate use will void any

liability or warranty of our products.

Due to continual product developments, please check for the latest update of this product

manual at www.laserworld.com. If you do have any further questions, then please contact

your dealer/place of purchase or use our contact section on our website.

For service issues, please contact your dealer/place of purchase and ensure only genuine

Laserworld spare parts are used in any service repairs.

Errors and Omissions excepted and products are subject to change.

Laserworld (Switzerland) AG

Kreuzlingerstrasse 5

8574 Lengwil

SWITZERLAND

Registered oce:

8574 Lengwil / Switzerland

Company number: CH-440.3.020.548-6

Commercial Registry Kanton Thurgau

CEO: Martin Werner

VAT no. (Switzerland): 683 180

UID (Switzerland): CHE-113.954.889

VAT no. (Germany): DE258030001

WEEE-Reg.-No. (Germany): DE 90759352

www.laserworld.com

[email protected]

representative according to EMVG:

Ray Technologies GmbH

Managing Director: Martin Werner

Mühlbachweg 2

83626 Valley / Germany

Autres manuels pour Evolution Series

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Laserworld Équipement d'éclairage

Laserworld

Laserworld Evolution Series ES-800S RGB 3D Instructions de montage

Laserworld

Laserworld GREEN-1500 Manuel utilisateur

Laserworld

Laserworld Diode Series Manuel utilisateur

Laserworld

Laserworld Garden Series Manuel utilisateur

Laserworld

Laserworld GREEN-400 Manuel utilisateur

Laserworld

Laserworld Club Series Manuel utilisateur

Laserworld

Laserworld GREEN-4000 Manuel utilisateur

Laserworld

Laserworld EL-60 G Manuel utilisateur

Laserworld

Laserworld RB-1.5 Manuel utilisateur

Laserworld

Laserworld Proline Series Manuel utilisateur

Laserworld

Laserworld CT-6215 Manuel utilisateur

Laserworld

Laserworld GREEN-300E Manuel utilisateur

Laserworld

Laserworld CS-400RGB Manuel utilisateur

Laserworld

Laserworld BeamBar 10R-638 Manuel utilisateur

Laserworld

Laserworld Evolution ES-800RGB Manuel utilisateur

Laserworld

Laserworld Evolution Series ES-400RGB Manuel utilisateur

Laserworld

Laserworld SwissLas Purelight Series Manuel utilisateur

Laserworld

Laserworld GREEN-200A Manuel utilisateur

Laserworld

Laserworld HIGH PRO-OEM Manuel utilisateur

Laserworld

Laserworld CS-8000RGB FX MK2 Manuel utilisateur

Laserworld

Laserworld Ecoline EL-D100G Manuel utilisateur

Laserworld

Laserworld Evolution ES-600B Manuel utilisateur

Laserworld

Laserworld Evolution Series ES-400RGB Manuel utilisateur

Laserworld

Laserworld FX Series Manuel utilisateur

Manuels Équipement d'éclairage populaires d'autres marques

Brizo

Brizo 8SP-MU-4 Manuel utilisateur

LUCE&LIGHT

LUCE&LIGHT BROM 1.0 Manuel utilisateur

IKEA

IKEA BJÖRKSPIREA Manuel utilisateur

Alien

Alien RG STAR Manuel utilisateur

EuroLite

EuroLite LED B-40 Manuel utilisateur

Qazqa

Qazqa Suplux SL 3 Black 103062 Manuel utilisateur

Commercial Electric

Commercial Electric 54568141 Manuel utilisateur

CREE LIGHTING

CREE LIGHTING 304 Series Manuel utilisateur

Goobay

Goobay 49867 Manuel utilisateur

ECOMAN ITALIA

ECOMAN ITALIA LED T8 Manuel utilisateur

Alkalite

Alkalite Krypton KT-81 Manuel utilisateur

Clas Ohlson

Clas Ohlson GU10 Manuel utilisateur

DTS

DTS DELTA 10 F Manuel utilisateur

ring

ring Solar Steplight Manuel utilisateur

One Stop Gardens

One Stop Gardens 57696 Instructions de montage

Chauvet DJ

Chauvet DJ COREpar UV120 ILS Manuel utilisateur

SIREM

SIREM Swimeo A2 Manuel utilisateur

Silvair

Silvair MESH-CEDRP Manuel utilisateur
