HV3R
ROTARY LASER
INSTRUCTION MANUAL
2
SAFETY
Read the following safety instructions before
attempting to operate this product.
Keep these instructions in a safe place or store
in the carry case for future reference.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE.
WARNING: Read and understand all
instructions.
▪Use the laser only with the specically
designated batteries.
▪Store the laser out of reach of children and
other untrained persons. Lasers are dangerous
in the hands of untrained users.
▪Use only accessories that are recommended
for your model.
▪Tool service must be performed only by
qualied repair personnel. Repairs, service
or maintenance performed by unqualied
personnel will void the warranty. Only
approved and authorised service technicians
can carry out warranty repairs.
▪Do not use optical tools such as a telescope
or transit to view the laser beam. Serious eye
injury could result.
▪Do not place the laser in a position which
may cause anyone to intentionally or
unintentionally stare into the laser beam.
Serious eye injury could result.
▪ Do not position the laser near a reective
surface which may reect the laser beam
toward anyone’s eyes. Serious eye injury
could result.
▪Do not use optical tools to view the laser
beam.
!
3
▪Do not set up the tool at a position where
the laser beam can cross any person at head
height.
▪Do not let children come in contact with the
laser.
▪ Turn the laser o when it is not in use. Leaving
the laser on increases the risk of staring into
the laser beam.
▪Do not operate the laser around children or
allow children to operate the laser. Serious eye
injury may result.
▪Do not remove or deface warning labels.
▪Position the laser securely on a level surface.
Damage to the laser or serious injury could
result if the laser falls.
WARNING: DO NOT DISASSEMBLE
THE LASER. There are no user serviceable
parts inside. Disassembling the laser will
void all warranties on the product. Do not
modify the product in any way. Modifying
the tool may result in hazardous laser
radiation exposure.
CAUTION: Class 2 Laser Product
▪Never look into the laser beam directly and
intentionally.
▪Do not use optical tools to view the laser
beam.
▪Do not set up the tool at a position where
the laser beam can cross any person at
head height.
▪Do not let children come in contact with
the laser.
!
!
4
ITEM CHECKLIST
Please ensure the following items are included with your laser level.
If anything is missing please contact your retailer.
Laser glasses
Carry caseRechargeable
battery pack (laser level)
Charger
Laser targetDetector & clampRemote controlLasertec HV3R
INCHES CM
1
1
2
3
4
5
6
7
2
3
1x 9V alkaline
battery (detector)
2x AAA alkaline
batteries (remote)
RP M
SC AN
5
RP M
SC AN
Rotating laser port Protective lighthouse
Control panel
LASER OVERVIEW: FRONT
Charging port
6
LASER OVERVIEW: BASE
5/8” x 11 thread for
horizontal operation
on a tripod
Battery pack screw
Battery pack screw
Battery pack screw
Battery pack screw
7
LASER OVERVIEW: CONTROL PANEL
SC AN
RPM
Power
Tilt alarm indicator
Power indicator
Grade adjustment
Grade adjustment
Grade adjustment
Grade adjustment
Tilt alarm
Manual / automatic mode
Scanning mode
Manual / automatic mode indicator
Counter clockwise
rotation
Clockwise rotation Speed control
Battery pack screw
Battery pack screw
8
Manual / automatic mode
Button indicator
Counter clockwise rotation
Scanning mode
Clockwise rotation
Speed control
Grade adjustment
Grade adjustmentGrade adjustment
Grade adjustment
REMOTE CONTROL OVERVIEW: FRONT
9
Grade adjustment
Grade adjustment
REMOTE CONTROL OVERVIEW: BACK
Battery compartment
10
Sound on / off
Coarse / fine detection
LCD display screen
Laser sensor
Speaker
Power
DETECTOR OVERVIEW: FRONT
