1. Introduction

Congratulations on the purchase of your new LaCie Hard Drive. This hard drive system will give you a unique combination of

compatibility and convenience, as well as generous storage capacity. LaCie’s Hard Drive is ideally suited for a wide range of

high-end, high-traffic environments, including: servers, workstations, video/audio editing and database management. For

even greater flexibility, your LaCie external U&I (one USB 2.0 port and two FireWire 800/IEEE 1394b ports) hard drive sys-

tem is also cross-platform, which enables you to use it on both Macs and PCs.

The LaCie Hard Drive was designed to allow you to use your desk-space efficiently – included with your LaCie Hard Drive is a

drive stand, so you can stand the drive vertically, freeing up even more valuable space. Engineered to be rack mountable,

you can quickly and easily integrate the LaCie drive into your standard 19-inch computer equipment racks using the LaCie

rackmount kit (sold separately).

With all it can do for you, we’re confident that your LaCie Hard Drive will quickly become an important tool in your day-to-

day business and personal computing.

This manual will help you to:

• Install your new device properly

• Get your drive up and running

• Quickly learn how to operate it

1.1. Icons Used In This Manual

Italicized paragraphs feature an icon describing the type of information being given.

Important Note Technical Information or News

Warning! (This icon indicates potential hazard).

Precautions

Always follow the basic precautions to use your LaCie Hard Drive safely and correctly. Respecting these guidelines will help to

avoid the possibility of personal injury to yourself or others, as well as to prevent damage to your device and other computer

equipment. For a complete list of precautions, please see Health And Safety Precautions.

Warranty

LaCie accepts no liability for any loss of data during the use of this device, or for any of the problems caused as a result.

Under no circumstances does LaCie guarantee the reliability of the hard drive.

d2HDFW800_UG_030311_4.0 3/12/03 2:02 PM Page 6

Introduction

page 7

LaCie Hard Drive User’s Manual

Manual Updates

LaCie is constantly striving to give you the most up-to-date, comprehensive User’s Manuals available on the market. It is our

goal to provide you with a friendly, easy-to-use format that will help you quickly install and utilize the many functions of your

new device.

If your manual does not reflect the configurations of the product that you purchased, please check our Web site

(www.lacie.com) for the most current version available, on the page of the product you purchased.

1.2. What Is FireWire?

FireWire, also known as IEEE 1394, is a high-speed serial input/output technology for connecting peripheral devices to a

computer or to each other, and FireWire 800 is the implementation of the new IEEE 1394b standard. Pushing the speed bar-

rier to new limits, FireWire 800 offers increased bandwidth and extended cabling distance between devices. FireWire 800 is

ideal for bandwidth-intensive applications, such as audio, video and graphics. Benefits of FireWire 800 include:

• Resourceful architecture: FireWire 800 reduces delays in arbitration and signal distortion, and increases throughput.

• Hot-pluggable: devices can be added and removed while the bus is active.

• Backwards compatibility: adapter cables allow FireWire 400 devices to operate under the FireWire 800 port.

• Isochronous data delivery: no dropped frames – FireWire 800 supports real-time data delivery.

• Flexible: up to 63 devices can be connected on a single bus.

Please see Appendix 1 – FireWire Questions And Answers for a more detailed discussion of FireWire’s uses and capabilities.

FireWire Icons

Theses icons will help you easily identify the FireWire interface. They appear on FireWire cables, and next to the FireWire

port connectors on certain computers.

FireWire icon iLink icon

DV icon

1.3. What Is USB 2.0?

The new USB 2.0 standard provides higher bandwidth for high-speed peripherals such as external hard drives, high-speed

scanners, CD-RW and DVD drives. USB 2.0 delivers transfer rates of 480Mb/s, while conveniently maintaining backward

compatibility with USB 1.1 devices.

d2HDFW800_UG_030311_4.0 3/12/03 2:02 PM Page 7

Introduction

page 8

LaCie Hard Drive User’s Manual

USB 2.0 can still be used to connect lower-speed USB 1.1 ports and devices like digital cameras, scanners, modems, key-

boards, mice, joysticks and printers. In the USB 2.0 system, existing USB peripherals do not have to be upgraded, and lower-

speed devices will not require additional performance, instead operating as USB 1.1 devices.

Please see Appendix 2 – USB Questions And Answers for a more detailed discussion of USB’s uses and capabilities.

USB Icons

These icons will help you easily identify the USB interfaces. They appear on USB cables and next to the USB port connectors

on certain computers.

USB 1.1 icon USB 2.0 icon

1.4. LaCie Storage Utilities Software

The LaCie Storage Utilities CD is a hybrid CD-ROM that has the Mac version, Silverlining Pro and SilverKeeper, and the PC

version, Silverlining 98, on the same CD. Mac users will be able to only view and use the Mac portion, and PC users will be

able to only view and use the PC version.

Mac Users Using Mac OS 9.x

Please see the Silverlining and SilverKeeper manuals for instructions on how to use this software. The manuals are located on

your LaCie Storage Utilities CD in PDF format.

Mac Users Using Mac OS 10.x

Use the formatting and partitioning capabilities in the Apple Disk Utility. Please refer to 4.1.1. Formatting And Partitioning

Using Mac OS 10.x for more information.

Please see the SilverKeeper manual for instructions on how to use this software. The manual is located on your LaCie Storage

Utilities CD in PDF format.

PC Users Using Windows 2000 and Windows XP

Use the formatting and partitioning capabilities that are included with your operating system. Please see 4.2.1. Formatting

And Partitioning Using Windows 2000 And Windows XP for more details.

PC Users Using Windows 98 Second Edition (SE) and Windows Me

You have the option of using Silverlining 98, included with your drive, or using the formatting and partitioning capabilities in

your operating system. Please see 4.2.2. Formatting And Partitioning Using Windows 98SE And Windows Me for more

details.

d2HDFW800_UG_030311_4.0 3/12/03 2:02 PM Page 8

Getting To Know Your LaCie Hard Drive

page 9

LaCie Hard Drive User’s Manual

2. Getting To Know Your LaCie Hard Drive

What can your external hard drive system do?

• Store and exchange data between several computers.

• Back up your computers’ internal hard drive.

• Store files created by your various applications.

2.1. Minimum System Requirements

FireWire 800

Hardware Requirements for FireWire 800:

• Mac: G4 with a FireWire 800/IEEE 1394b inter-

face card

• PC: Pentium III or higher compatible processor,

with a FireWire 800/IEEE 1394b interface card

• 128MB RAM or higher

System Requirements for FireWire 800:

• Mac OS 10.2.4 or higher

• Windows 2000 and Windows XP

FireWire 400

Hardware Requirements for FireWire 400:

• Mac: G3 or greater, with FireWire 400/IEEE 1394a interface card

• PC: Pentium II or higher -compatible processor, with a FireWire/IEEE

1394/iLink interface card (SBP-2 compatible) that supports mass stor-

age devices.

• 64MB RAM or greater

Important Note: If you only have a 4-pin connector on your

FireWire 400 interface card, you will need to purchase a 4-to-

6 pin FireWire cable.

System Requirements for FireWire 400:

• Mac OS 9.x (Apple FireWire support 2.3.3 and greater) and 10.x

• Windows 98 SE, Windows Me, Windows 2000 and Windows XP

USB 2.0

Hardware Requirements for USB:

• Mac: G3 or greater, with USB 2.0 or 1.1 interface card

• PC: Pentium II or higher -compatible processor, with a USB 2.0 or 1.1 card

• 32MB RAM or greater

System Requirements for USB:

• Mac OS 9.x and 10.x (Apple USB support 1.3.5 and greater)

• Windows 2000, Windows Me and Windows XP

d2HDFW800_UG_030311_4.0 3/12/03 2:02 PM Page 9

Autres manuels pour Hard Drive

Table des matières

Autres manuels LaCie Stockage

LaCie

LaCie Biggest Quadra Manuel utilisateur

LaCie

LaCie 6big Thunderbolt 3 Manuel utilisateur

LaCie

LaCie Little Big Disk Thunderbolt™ Series Manuel utilisateur

LaCie

LaCie Hard Drive Porsche Manuel utilisateur

LaCie

LaCie Mobile Hard Drive Manuel utilisateur

LaCie

LaCie Silver CooKey Manuel utilisateur

LaCie

LaCie LITTLE DISK USB 2.0 Manuel utilisateur

LaCie

LaCie Porsche Design P′9233 Manuel utilisateur

LaCie

LaCie Rugged Hard Disk Manuel utilisateur

LaCie

LaCie Rugged Hard Disk Manuel utilisateur

LaCie

LaCie USB 3.0 Drive Manuel utilisateur

LaCie

LaCie Golden Disk Manuel utilisateur

LaCie

LaCie 2big Spare Drive Manuel utilisateur

LaCie

LaCie 301490 Manuel utilisateur

LaCie

LaCie rugged XL Manuel utilisateur

LaCie

LaCie Biggest S2S Manuel utilisateur

LaCie

LaCie LaCinema Classic Manuel utilisateur

LaCie

LaCie 12big Rack Fibre 8 Manuel utilisateur

LaCie

LaCie LaCie Ethernet Big Disk Manuel utilisateur

LaCie

LaCie Rugged Hard Disk Manuel utilisateur

LaCie

LaCie DataShare Manuel utilisateur

LaCie

LaCie LaCie Ethernet Disk Manuel

LaCie

LaCie Dual DVD RW Drive Manuel utilisateur

LaCie

LaCie Rugged Triple USB 3.0 Manuel utilisateur

Manuels Stockage populaires d'autres marques

QNAP

QNAP TS 32PXU Series Manuel utilisateur

Freecom

Freecom CLS DOCK Manuel utilisateur

PNY

PNY Attache P-FD64MBATT3 Manuel utilisateur

HP StorageWorks MSL2024 Manuel utilisateur

OLT

OLT 6x6 Maximizer Manuel utilisateur

Transcend

Transcend JetFlash 160 Manuel utilisateur

Thunderbolt

Thunderbolt 600 Manuel utilisateur

Panasonic

Panasonic LB-DH8 series Manuel

Intel

Intel RAID High Availability Manuel utilisateur

Spectra Logic

Spectra Logic T-Series Spectra T50e Manuel utilisateur

Panasonic

Panasonic LKM-F931-1 Manuel utilisateur

Tabernus

Tabernus Enterprise Erase E2400 Manuel utilisateur

Rocstor

Rocstor COMMANDER 3F series Manuel utilisateur

HP P9000 Manuel utilisateur

Western Digital

Western Digital Ultrastar Data60 Manuel utilisateur

Dell

Dell PowerVault MD3600f Series Manuel utilisateur

CFI

CFI TERA STOR SATA RAID IV Manuel utilisateur

Quantum

Quantum PX506 Manuel utilisateur
