LABNET Excel
Single and Multi-channel Electronic Pipettors
Operation Manual
Version: 2.9
www.Labnetlink.com
Labnet International
31 Mayfield Ave
Edison, NJ 08837
USA
Declaration of Conformity
Product Name: Labnet Excel Single/Multi-channel Electronic
Pipettors
All models comply with the following European standards:
EMC: EN 55011, Class A
EN 60601-1-2
To the best of my knowledge and belief, these units conform to these
standards.
Name: Mike Revesz
Position: Director of Quality Assurance
Issue Date: 2005/1/1
Table of Contents
1. Safety Precautions...................................................................................1
1.1. Operation Safety Precautions 1
1.2. Battery Safety 1
2. General Description................................................................................3
2.1. Features 3
2.2. Ranges and Specifications 4
3. Getting Started ........................................................................................4
3.1. Unpacking 4
3.2. Inserting the Battery 5
3.3. Charging the Battery 6
3.4. Start Pipetting 8
3.5. Manual Blow-out Operation 10
3.6. Hanger Installation 10
4. LABNET Excel electronic pipettor Overview.....................................11
4.1. Keypad Function 12
4.2. Audible Signals 13
5. Function Map ........................................................................................14
9. SYS (System) Mode...............................................................................15
6.1. Aspirating Speed 15
6.2. Dispensing Speed16
6.3. Audible Signals 16
6.4. Blow-out 16
6.5. Reverse Pipetting17
6.6. Setting PROG (Programs) 18
7. AUTO Mode ........................................................................................ 19
8. MD (Multiple Dispensing) Mode .........................................................21
9. MIX Mode.... 22
10. SE (Sequential Aspirating/Dispensing) Mode.....................................22
10.1. SA (Sequential Aspirating) Mode 23
10.2. SD (Sequential Dispensing) Mode 24
11. Sterilization.. 26
11.1. Removal of the Lower Piston Assembly 27
11.2. Reattach the lower piston assembly 28
12. Maintenance 30
13. Troubleshooting.....................................................................................31
Appendix A: Technical Specifications...........................................................33
Appendix B : Tip Ejector Height Adjustment..............................................33
Appendix C: Warranty...................................................................................34
1
1. Safety Precautions
1.1. Operation Safety Precautions
When using infectious, radioactive, toxic and other solutions which
may pose health risks, please observe appropriate safety precautions.
1. Do not use the LABNET Excel electronic pipettor in a potentially
explosive environment or with potentially explosive chemicals.
2. When using organic solvents or corrosive chemicals, please check their
compatibility with the pipette tips and the LABNET electronic pipettor.
3. Repair should be carried out by LABNET’s authorized service
personnel only. Contact LABNET International, Inc. for information
on authorized service options.
4. Use original spare parts and accessories only.
1.2. Battery Safety
The LABNET Excel electronic pipettors operate on a small but
powerful Lithium-ion battery. Misuse or abuse of the Lithium-ion
battery may cause damage or injury through fire, electric shock, or
chemical leakage. Please read and understand all warnings before using
the battery.
1. When storing the battery, do not allow it to come into contact with any
metallic surfaces.
Before using the LABNET Excel electronic pipettor for the first time,
please read this entire operating manual carefully. To guarantee problem
free, safe operation, it is essential to observe the following points:
2
2. Never use the LABNET Excel electronic pipettors while using the
DC-in jack to charge the battery.
3. Do not incinerate the Lithium battery or expose it to excessive heat.
4. Do not short-circuit, puncture, crush, disassemble, damage, force
over-discharge (reversal) or modify the battery.
5. Do not expose the battery to water or moisture.
6. Do not drop or subject the battery to strong impacts.
7. Only use the battery specified in this manual.
8. Only use the specified, battery charging unit or DC-in jack to charge
the battery.
9. Do not use a leaking battery.
10. If charging is not completed within the specified time period, unplug
the charger and discontinue charging immediately.
11. The charger and battery temperature rises with extended periods of use.
Care should be taken to avoid burns.
12. Burns may result if the battery is removed immediately after extended
periods of use.
13. If fluid from the battery enters your eye, immediately rinse the eye with
plenty of fresh water and contact a doctor. If fluid from the battery
makes contact with your skin or clothing, wash the area thoroughly
with water.
3
2. General Description
2.1. Features
zHigh accuracy and precision
zLow forces
zUseful, practical operation protocols, such as Automatic Pipetting
(AUTO) with Mixing (MIX) option, Multiple Dispensing (MD),
Mixing (MIX) and Sequential Aspirating/Dispensing (SE), etc.
z9 user-defined program sets
z5 speeds for aspirating and dispensing
zLi-ion battery provides extended use on a single battery charge
zErgonomic design
zAutomatic calibration
zUser-friendly graphic operation interface.
zAdjustable tip ejector.
zAutomatically remembers the last-used pipetting protocol and settings
zComplies with CE, ISO-8655, GLP
LABNET Excel electronic pipettors feature an accurate and efficient, as
well as ergonomic and light-weight design. Researchers can program these
state-of-the-art products to conduct different pipetting tasks. More accurate
and comfortable pipetting can be easily achieved without any concern of
finger stress or injury.
4
2.2. Ranges and Specifications
Product No. Channels Volume
Range (µl)
Increment
(µl)
Accuracy
(Rel.±)
Precision
( Rel. CV )
E10-1 1 0.5 -10 0.1
4.0-1.0% 2.5-0.4%
E20-1 1 2 -20 0.1
5.0-1.0% 2.0-0.3%
E200-1 1 10 -200 1 2.0-0.6% 1.0-0.15%
E1200-1 1 100 -1,200 1 1.5-0.5% 0.6-0.15%
E10-8 8 0.5-10 0.1 4.0-1.0% 2.5-0.4%
E20-8 8 2-20 0.1 5.0-1.0% 2.0-0.3%
E200-8 8 10-200 1 2.0-0.6% 1.0-0.15%
E1200-8 8 100 -1,200 1 1.5-0.5% 0.6-0.15%
Note:
LABNET Excel electronic pipette Accuracy and Precision Specifications
have been attained using LABNET Excel pipette tips. LABNET
guarantees Accuracy and Precision only if LABNET Excel tips or other
approved tips are used.
3. Getting Started
3.1. Unpacking
zSingle/8-channel LABNET
electronic pipette unit
zOperation manual
Open the LABNET Excel electronic pipettor package and confirm that all
items are included:
5
zQuality assurance card zAC-DC power adaptor
zLABNET electronic pipette
hanger and accessories
zPipette tips
3.2. Inserting the Battery
Figure 1: Open the battery cover. Figure 2: Insert the battery.
If there are any items missing, damaged, or not according to your order,
please contact your distributor or sales representatives for replacement
immediately.
Please charge the battery before first-time operation.
Remove the battery cover by pressing the battery cover latch (see Figure 1)
and move the cover outward. Insert the battery (see Figure 2). Metallic
contacts must be face down. Close the cover of the battery compartment.
Press the RESET button to power on and calibrate the LABNET electronic
pipette.
6
Note: After a charged battery is inserted, the LABNET electronic pipette
will automatically carry out a calibration routine.
3.3. Charging the Battery
Included AC-DC Power Adapter
Optional Charging Kit
There are two ways to charge the battery: (1) Attach the included AC-DC
Power Adapter to the pipettor (2) Use the optional battery charging kit.
Insert the battery into the battery compartment. Insert the DC-in plug of the
power adaptor into the DC-in jack (see Figure 3). Connect the power plug
of the power adaptor with the external power source. Connecting the power
plug before inserting the battery will inactivate the charging process. The
indication bar inside battery symbol will blink during the charging
process. When the battery is fully charged, the blinking will stop and the
LABNET electronic pipette will beep once to remind the user.
Connect the power plug of the charging unit to the proper external power
source. The indication light will turn green. Insert the battery (see Figure 4).
Once the battery is correctly inserted and charging, the indicator light will
turn red. When the battery capacity is full, the indicator light will turn green
again.
