Labnet BioPette PLUS Manuel utilisateur

This quick guide is intended to provide

a brief overview of the main features

and operation of all Labnet Single- and

Multi-channel Pipettors.

For detailed information, please refer to

the User Manuals that can be found at

www.labnetlink.com in several languages.

Labnet Single- and Multi-

channel Pipettors

Quick Start Guide

Biopette Pro

Biopette Plus

Biopette A

Labpette FX, xed volume

Intended Use

Labnet Pipettors are volumetric instruments designed to

measure and transfer liquids precisely and safely with the

use of disposable pipet tips. The pipettors operate on the

air-cushion principle (i.e., the aspirated liquid does not

come in contact with the shaft or plunger of the pipettor).

Getting started

Know your pipettor

Pushbutton

Ejector button

Volume lock

(Biopette Plus and

Biopette Pro only)

Volume display

Tip ejector

Shaft

Multi-channel

manifold

Labpette FX, xed volume

Variable volume pipettors

Pushbutton

Ejector button

Handle

Tip ejector

Shaft

They can accommodate volumes from 0.1 µL to 10,000 µL

depending on the model. They are available in single-,

8- and 12-channel variable volume as well as xed volume

single-channel versions.

Biopette Plus Biopette A

Step 1

Set the volume

2.16 µL 1.25 mL

Biopette Pro

20.42 µL 1,000 µL

Lock the volume

Biopette Plus Biopette Pro

NOTE: Biopette A Single- and Multi-channel Pipettors do not

feature a volume lock function.

Step 2

Insert the tip

✓✕

Ejector adjustment

Biopette Plus

Biopette A

+1 mm

+2 mm

NOTE: Ejector adjustment is not necessary in Biopette Pro

and Labpette FX pipettors as they feature a long ejector

stroke.

Pipettors 5,000 and 10,000 µL

Step 3

Aspirate the liquid

~1 sec.

Step 4

Dispense the liquid

10-40°

Recommended depth

≤1 mm 2-3 mm 2-4 mm 5-7 mm

0.1-1 µL 1-100 µL 101-1,000 µL > 1,000 µL

Step 5

Eject the tip

NOTE: Before calibration, in the Biopette Plus and Biopette

Pro lines, always remember to lock the volume using the

lock function and for the Biopette A hold the calibration

knob.

Step 6

Calibration

Biopette Plus Biopette A Labpette FX

Calibration key

Biopette Pro

Safety Notes

• The pipettor is designed for the transfer of liquids only

using the tip. Do not aspirate liquids without the tip

attached. The aspirated liquid should not enter the

pipettor, as it may cause damage.

• Single-use tips reduce the risk of contamination of

samples.

• Keep the pipettor clean, avoiding the use of abrasive or

corrosive cleaning agents (e.g., acetone).

• Keep the pipettor upright when there is liquid in the tip.

• Only using the pipettor in accordance with the

manufacturer’s instructions ensures the correct pipettor

parameters are maintained.

• After replacing the plunger or the shaft, the pipettor

should be calibrated.

• In the case of incorrect operation, the device should

be cleaned in accordance with the Instructions for Use

or transferred to a service point.

• Ambient operating temperature is +5°C to 45°C.

• Ambient storage conditions (in the original packaging

during transport and short storage) is -25°C to 55°C.

• Follow general work safety regulations regarding hazards

related to work in the laboratory.

• Take special care when pipetting aggressive substances.

• Use appropriate protective attire (e.g. clothing, goggles

and gloves).

• Avoid pointing the pipettor at yourself or others during

use.

• Only use parts and accessories recommended by the

manufacturer.

Cleaning

• External parts may be cleaned with a swab moistened

with isopropyl alcohol.

• Pipettors can be autoclaved at 121°C for 20 minutes.

Prior to autoclaving, untighten the pipettor shaft,

remove the lter from 5 and 10 mL pipettor shafts.

• The outer body of the pipettor is UV-resistant. The

recommended distance from the radiation source to

exposed element should not be less than 50 cm.

• Prolonged and very intense UV exposure can cause

de-coloration of pipettor parts but does not affect its

performance.

Warranty

Labnet Single- and Multi-channel Pipettors are covered by

a three (3) year limited warranty. For more information on

the warranty limitations refer to the full version of the User

Manuals available at www.labnetlink.com.

“Calibration”

position

“Operating”

position

Calibration key – cross end

Calibration key – flat end

7/21 CLSLN-AN-1007DOC REV1

Made in Poland

For a listing of trademarks, visit www.corning.com/clstrademarks.

All other trademarks are the property of their respective owners.

For additional product or technical information, visit

www.labnetlink.com or contact your local sales ofce.

NORTH AMERICA

t 800.492.1110

t 978.442.2200

ASIA/PACIFIC

Australia/New Zealand

t 61 427286832

Chinese Mainland

t 86 21 3338 4338

f 86 21 3338 4300

India

t 91 124 4604000

f 91 124 4604099

Japan

t 81 3-3586 1996

f 81 3-3586 1291

Korea

t 82 2-796-9500

f 82 2-796-9300

Singapore

t 65 6572-9740

f 65 6735-2913

Taiwan

t 886 2-2716-0338

f 886 2-2516-7500

EUROPE

[email protected]

France

t 0800 916 882

Germany

t 0800 101 1153

The Netherlands

t 020 655 79 28

United Kingdom

t 0800 376 8660

All Other European

Countries

t +31 (0) 206 59 60 51

LATIN AMERICA

[email protected]

Brazil

t 55 (11) 3089-7400

Mexico

t (52-81) 8158-8400
