Labkotec Labcom 221 GPS Manuel utilisateur

Labcom 221 GPS

Data transfer unit

Installation and User Guide EN

DOC002104-EN-2

5/19/2023

Contents

1 General information about the manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.1 Conformity of the product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 Limitation of liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2 Safety and the environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1 General safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3 Transport and storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.4 Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.5 Decommissioning and disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3 Product description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4 Installation and commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5 Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.1 Passive mA sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.2 Active mA sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.3 Switch output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.4 Switch inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.5 Example connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.5.1 Connection idOil-LIQ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.5.2 Connection idOil-SLU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.5.3 Connection GA-SG1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.5.4 Connection SGE25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.5.5 Connection 1-wire temperature sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.5.6 Connection DMU-08 and L64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.5.7 Connection Nivusonic CO 100 S . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6 External voltage supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.1 Under Voltage Lockout mode (UVLO) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7 Troubleshooting FAQ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

8 Technical specifications Labcom 221 GPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Installation and User Guide | Labcom 221 GPS 2/14

DOC002104-EN-2

1 General information about the manual

This manual is an integral part of the product.

Please read the manual before using the product.

Keep the manual available for the entire duration of the product’s life span.

Provide the manual to the next owner or user of the product.

Please report any errors or discrepancies related to this manual before commissioning

the device.

1.1 Conformity of the product

The EU declaration of conformity and the product’s technical specifications are integral

parts of this document.

All of our products have been designed and manufactured with due consideration to the

essential European standards, statutes and regulations.

Labkotec Oy has a certified ISO 9001 quality management system and ISO 14001

environmental management system.

1.2 Limitation of liability

Labkotec Oy reserves the right to make changes to this user guide.

Labkotec Oy cannot be held liable for direct or indirect damage caused by neglecting the

instructions provided in this manual or directives, standards, laws and regulations regarding

the installation location.

The copyrights to this manual are owned by Labkotec Oy.

Installation and User Guide | Labcom 221 GPS 3/14

DOC002104-EN-2

2 Safety and the environment

2.1 General safety instructions

The plant owner is responsible for the planning, installation, commissioning, operation,

maintenance and disassembly at the location.

Installation and commissioning of the device may be performed by a trained professional

only.

Protection of operating personnel and the system is not ensured if the product is not used in

accordance with its intended purpose.

Laws and regulations applicable to the usage or the intended purpose must be observed.

The device has been approved for the intended purpose of use only. Neglecting these

instructions will void any warranty and absolve the manufacturer from any liability.

2.2 Intended use

Labcom 221 GPS is primarily intended for transferring measurement, accrual, positioning,

alarm and status information to the LabkoNet server from locations where there is no fixed

power supply or installing it would be too expensive.

An LTE-M / NB-IoT network must be available for the device for data transfer. An external

antenna can also be used for data transfer. The positioning functionalities require a satellite

connection to the GPS system. The positioning (GPS) antenna is always internal, and there

is no support for an external antenna.

A more specific description of the product’s operation, installation and use is provided later

in this guide.

The device must be used in accordance with the instructions provided in this document.

Other use is counter to the product’s purpose of use. Labkotec cannot be held liable for any

damage caused by using the device in violation of its purpose of use.

2.3 Transport and storage

Check the packaging and its content for any possible damage.

Ensure that you have received all the ordered products and that they are as intended.

Keep the original package. Always store and transport the device in the original packaging.

Store the device in a clean and dry space. Observe the permitted storage temperatures. If

the storage temperatures have not been presented separately, the products must be stored

in conditions that are within the operating temperature range.

2.4 Repair

The device may not be repaired or modified without the manufacturer’s permission. If the

device exhibits a fault, it must be delivered to the manufacturer and replaced with a new

device or one repaired by the manufacturer.

2.5 Decommissioning and disposal

The device must be decommissioned and disposed of in compliance with local laws and

regulations.

Installation and User Guide | Labcom 221 GPS 4/14

DOC002104-EN-2

3 Product description

Figure 1 . Labcom 221 GPS product description

1. Internal external antenna connector

2. SIM card slot

3. Device serial number = device number (also on the device cover)

4. Battery connector

5. Additional card

6. TEST button

7. External antenna connector (option)

8. Connection wire lead-throughs

Installation and User Guide | Labcom 221 GPS 5/14

DOC002104-EN-2

4 Installation and commissioning

The device must be installed on a firm foundation where it is not at immediate risk of

physical impacts or vibrations.

The device features screw holes for installation, as shown in the measurement drawing.

The cables to be connected to the device must be installed in such a way that prevents

moisture from reaching the lead-throughs.

Figure 2 . Labcom 221 GPS measurement drawing and installation dimensions (mm)

The device features preset configurations and parameters and comes with a SIM card

installed. DO NOT remove the SIM card.

Ensure the following in the context of commissioning before connecting the battery.

The wires have been installed correctly and tightened firmly to the terminal strips.

If installed, the antenna wire has been tightened properly to the antenna connector in

the housing.

If installed, the internal antenna wire installed in the device has stayed connected.

All lead-throughs have been tightened to keep moisture out.

Once all of the above are in order, the battery can be connected to the circuit board with the

wire provided and the device cover can be closed. When closing the cover, make sure that

the cover seal is seated correctly to keep dust and moisture out of the device.

When the battery is connected, the device contacts the server. This is indicated by the

circuit board LEDs flashing.

The commissioning of the device is confirmed with the LabkoNet server by checking that

the device has sent the correct information to the server.

Installation and User Guide | Labcom 221 GPS 6/14

DOC002104-EN-2

5 Connections

Read the section General safety instructions before installation.

Make the connections when the device is de-energised.

5.1 Passive mA sensor

Labcom 221 GPS supply the operating voltage required by the sensor to the passive

measurement transmitter’s/sensor’s measurement circuit. The measurement circuit’s plus

conductor is connected to the 221 GPS device’s voltage output (+Vboost Out, I/O2) and the

circuit’s grounding conductor is connected to the device’s analogue input (4–20 mA, I/O9).

Figure 3 . Example connection

5.2 Active mA sensor

The voltage to the measurement circuit of the active measurement transmitter/sensor is

supplied by the transmitter/sensor itself. The measurement circuit’s plus conductor is

connected to the Labcom 221 GPS device’s analogue input (4–20 mA, I/O9) and the

circuit’s grounding conductor is connected to the grounding connector (GND).

Figure 4 . Example connection

Installation and User Guide | Labcom 221 GPS 7/14

DOC002104-EN-2

5.3 Switch output

Figure 5 . Example connection

The Labcom 221 GPS device has one digital output. The approved voltage range is

0...40VDC and the maximum current is 2A. For larger loads, a separate auxiliary relay must

be used, which is controlled by the Labcom 221 GPS.

5.4 Switch inputs

1brown I/O7

2yellow DIG1

3black GND

4Two

separate

switches

Figure 6 . Example connections

Installation and User Guide | Labcom 221 GPS 8/14

DOC002104-EN-2

5.5 Example connections

5.5.1 Connection idOil-LIQ

1black I/O2

2black I/O9

Figure 7 . Labcom 221 GPS - idOil-LIQ sensor; Connection

The Labcom 221 GPS data transfer unit + idOil-LIQ sensor must not be installed

in potentially explosive atmospheres.

5.5.2 Connection idOil-SLU

1black I/O2

2black I/O9

Figure 8 . Labcom 221 GPS – idOil-SLU sensor; Connection

The Labcom 221 GPS data transfer unit + idOil-LIQ sensor must not be installed

in potentially explosive atmospheres.

Installation and User Guide | Labcom 221 GPS 9/14

DOC002104-EN-2

5.5.3 Connection GA-SG1

1black I/O2

2black I/O9

Figure 9 . Labcom 221 GPS - GA-SG1 sensor; Connection

5.5.4 Connection SGE25

1red I/O2

2black I/O9

Figure 10 . Labcom 221 GPS - SGE25 sensor; Connection

5.5.5 Connection 1-wire temperature sensor

1red I/O5

2yellow I/O8

3black GND

Figure 11 . Labcom 221 GPS – 1-wire temperature sensor; Connection

Installation and User Guide | Labcom 221 GPS 10/14

DOC002104-EN-2
