La Crosse 616-1908v2 Manuel utilisateur
Model: 616-1908 www.lacrossetechnology.com/support Page | 1
Model: 616-1908v2
Quick Setup Guide
DC: 052715
Projection Time Alarm
BUTTONS
Time
Calendar or
Alarm Time
Projection
Arm
Adjustable
FRONT
Foldout
Stand Open
Clock cover closed
Pull firmly to open.
Battery compartment
2-“AAA” batteries
Standard USB
for charging
mobile devices
Micro-USB port
to operate clock
Model: 616-1908 www.lacrossetechnology.com/support Page | 2
GET STARTED
Step 1: With the cover/stand closed, insert two AAA batteries (not
included) into the back of projection alarm. Observe correct
polarity.
Step 2: Looking at the top of the clock, firmly pull the cover/stand
open to view the clock.
Step 3: Optional Micro-USB power cord (included) for constant,
adjustable backlight and projection. Insert the Micro-USB end
of the cord into the clock and the USB end into your computer
USB port or a USB outlet.
Restart: Unplug the Micro-USB cord and remove batteries from the
projection alarm, press a button 20 times. After 15 minutes, return to
Step 1 above.
SET TIME AND DATE
1. Hold the MODE/SET button five seconds, to enter time set mode.
2. Use the ▲UP or ▼ DOWN buttons to adjust values.
Press and hold those buttons for fast adjustment.
3. Press the MODE/SET button to confirm adjustments and move to
the next item.
Time and Date setting order:
1. 12/24 Hour Time Format
2. Hour
3. Minutes
4. Year
5. Month
6. Date
Note: Day of the week sets automatically when year, month and date
are set.
Press the MODE/SET button to exit, or wait 20 seconds without
pressing buttons to return to the normal time display.
SET TIME ALARM
1. Press the ALARM button to view the alarm time.
2. In alarm mode, hold the ALARM button to enter
alarm time set mode.
3. Use the ▲UP or ▼ DOWN buttons to adjust
values.
Model: 616-1908 www.lacrossetechnology.com/support Page | 3
4. Press the ALARM button to confirm
adjustments and move to the next item.
Alarm Time setting order:
1. Hours
2. Minutes
ACTIVATE/DEACTIVATE TIME ALARM
Press the ALARM button once to view alarm time.
Press the ALARM button again to activate the alarm.
Bell icon appears.
Press the ALARM button again to deactivate the alarm.
The bell icon disappears.
SNOOZE (Silences alarm temporarily)
Press the SNOOZE/LIGHT button to silence alarm
for 10 minutes.
Zz will show above the time.
When in snooze mode, press SNOOZE/LIGHT to
stop alarm for one day.
Note: The alarm is crescendo sound. The alarm will sound for 2
minutes and then shut off completely.
CALENDAR OR ALARM TIME DISPLAY
Press the MODE/SET button to select Alarm Time
or Calendar to be displayed.
BACKLIGHT BRIGHTNESS-MICRO-USB POWER
Press and release the SNOOZE/LIGHT button to adjust the
brightness of the backlight:
ON Bright
ON Dim
OFF
Note: When the Micro-USB cord is NOT in use, the High/Low/Off
features are not available.
When operating on battery power only, press the SNOOZE/LIGHT
button for a 10 second backlight and projection. The projection will
not stay on with battery power only.
Model: 616-1908 www.lacrossetechnology.com/support Page | 4
PROJECTION (rotate, projection arm)
Battery Power: Press and release the SNOOZE/LIGHT
button to show the projection for 10 seconds.
Micro-USB Cord: Projection is displayed constantly.
Note: Projection will not display constantly when operating on battery
power.
Rotate Projection:
Press the ▲UP button to rotate the projection image 90 degrees.
Press the ▲UP button again to rotate another 90 degrees.
Continue until the projected image is right side up.
Projection Arm: The projection arm will move forward or backward
so you can project on the wall or ceiling.
USB CHARGE PORT
Charge your mobile device when the clock is plugged into a USB
outlet with the Micro-USB cord. You cannot charge mobile devices
when operating the clock on battery power only.
Option 1:
Use the included Micro-USB cord to connect the clock to a USB
power outlet or your computer.
Connect your mobile device’s USB charging cable (not included)
to the USB charging port.
Charging times will vary.
USB Power Output: 1.0A maximum current. Charge 1.0A devices
or devices that are self-regulating.
Model: 616-1908 www.lacrossetechnology.com/support Page | 5
Option 2:
Use your mobile device’s charge cord to connect to an AC/DC
outlet and to the Micro-USB port on the clock to power the clock.
Then use the included USB cord to connect to the standard USB
charge port to charge your mobile device.
IMPORTANT: Charging ability will depend on the power output of
your devices charge cord. There is no guarantee this configuration
will charge your mobile device while powering the clock.
CARE AND MAINTENANCE
Do not mix old and new batteries
Do not mix Alkaline, Standard, Lithium or Rechargeable
Batteries
Always purchase the correct size and grade of battery most
suitable for the intended use.
Replace all batteries of a set at the same time.
Clean the battery contacts and also those of the device prior to
battery installation.
Ensure the batteries are installed correctly with regard to polarity
(+ and -).
Remove batteries from equipment when is not to be used for an
extended period of time.
Remove expired batteries promptly.
Do not expose to extreme temperature, vibration or shock.
Clean with a soft damp cloth. Do not use solvents or scouring
agents.
The product is not a toy. Keep it out of reach of children.
The product is not to be used for medical purpose or for public
information. It is intended for home use only.
The specs of this product may change without prior notice.
Improper use or unauthorized opening of housing voids warranty.
If the product is not working properly, change the batteries.
Model: 616-1908 www.lacrossetechnology.com/support Page | 6
SPECIFICATIONS
Power:
Optional Micro-USB cord
Micro-USB to USB outlet(included)
Batteries
2-AAA, IEC, LR3 batteries
(not included)
Battery Life:
Projection Alarm
Battery life is over 12months with reputable
battery brands.
Dimensions:
Projection Alarm Open:
Closed
4.5” L x 3” W x 3” H
(114.3 x 76.2 x 76.2 mm)
4.5”L x 0.94” W x 3”H
(114.3 x 24 x 76.2mm)
WARRANTY AND SUPPORT
La Crosse Technology, Ltd. provides a 1-year limited time warranty
(from date of purchase) on this product relating to manufacturing
defects in materials & workmanship.
View full warranty details online at:
www.lacrossetechnology.com/warranty_info.pdf
Before returning a product, please contact our friendly customer
support with questions or visit our online help:
La Crosse Technology, Ltd
2830 South 26th St
La Crosse, WI 54601
Contact Support:
1-608-782-1610
Online Product Support:
www.lacrossetechnology.com/support
Product Registration:
www.lacrossetechnology.com/support/register
