404-1235UA-SS www.lacrossetechnology.com/support Page | 1

Model: 404-1235UA-SS

Instruction Manual

DC: 110515

14” ULTRATOMIC WALL CLOCK

Welcome! Thank you for buying the UltrAtomic clock with

exceptional Atomic time reception.

Get Started-Atomic Time

1: Slide the Time Zone switch to your time zone.

PT = Pacific, MT = Mountain, CT = Central, ET = Eastern

2: Slide the DST switch to the ON or OFF position.

3: Insert two or four fresh “C”, LR14 1.5 volt batteries according to

the polarity markings.

+ C -

Use two or four

“C” batteries

404-1235UA-SS www.lacrossetechnology.com/support Page | 2

Important: When batteries are installed, the hands will move to

4 o’clock, 8 o’clock, or 12 o’clock position and search for the

Atomic Time signal.

•If successful, the hands will move to the time received for the

time-zone selected.

•If not successful, the hands will stay either at 4 o’clock 8

o’clock or 12 and the movement will continuously keep trying

to receive the Atomic Time.

Position Clock

•For the best reception, please place clock on a wall that faces

Ft. Collins, Colorado.

•Signal reception is at its peak when there is only one wall or

window between the clock and the outside.

•The antenna is best positioned for signal reception when the

front or back of the clock faces Colorado.

•Choose a location six feet or more from electronics such as

cordless phones, wireless gaming systems, televisions,

microwaves, routers, baby monitors, etc., which can prevent

signal reception.

•Large office buildings, schools, or hospitals may not receive

the WWVB time signal in every room.

•Metal roofs on buildings may interfere with reception.

Note: We recommend that you change the batteries every 24

months to maintain accuracy. Remove the battery when the clock

will not be in use for an extended period.

Optional Settings

ECO-Mode

Eco-mode is a battery saving feature that stops the second hand

at 12:00, between the hours of 11pm-5am.

•Eco Mode switch ON: Second hand does not

move between 11pm and 5am. Hour and Minute

hands move.

•Eco Mode switch OFF: the second hand runs

constantly.

ECO Mode

OFF

404-1235UA-SS www.lacrossetechnology.com/support Page | 3

Atomic Time with Custom Time Zone Selection

This clock allows you to select more than the

four selectable time zones with CUSTOM ET.

1. Slide the Time Zone switch to CUSTOM ET.

2. Press and release the SET button to

advance the time in one hour increments.

3. The clock will keep time in the new time

zone selected.

WWVB Atomic Time Signal

For information about WWVB, visit:

www.nist.gov/pml/div688/grp40/wwvb.cfm

Daylight Saving Time:

The National Institute of Standards and Technology and WWVB

encode a special DST “bit” in the WWVB transmission for DST.

Your clock will read this information and automatically advance the

hands one hour in the spring and eleven hours in the fall.

Arizona

•If you live in an area that does not recognize DST, you must

slide the DST switch OFF.

•To reactivate the DST program simply slide the switch to the

ON position.

Q-Mode-Manual Set Time

On rare occasions, the clock may not be able to receive Atomic

time because of the strength of the signal or the geographic

location. In this case, the clock can be set manually and used as

a regular Quartz wall clock.

1. Set DST switch to the OFF (Q-Set).

2. Set Time Zone switch to the Q-MODE.

Note: The movement will move to 4 o’clock 8 o’clock or 12

o’clock position and stop.

Sleep

Q-Mode

Custom

404-1235UA-SS www.lacrossetechnology.com/support Page | 4

Q-Mode

Q-Run

Q-Set

DST

OFF

3. Hold the SET button to set the time quickly

4. Press and release the SET button to change the time slowly.

5. When time is set, slide the DST switch to ON (Q-RUN)

position.

6. The second hand will start running from 12:00 and the clock

will keep time as manually set.

Troubleshooting

The wonderful advantage of owning an UltrAtomic clock is that it is

virtually trouble free. When the clock receives a clear atomic time

signal, it will set itself perfectly. If it does not receive an atomic

time signal, consider the following:

•Batteries – The clock must have a fresh batteries to receive

and process the time signal. Low batteries are indicated when

the Hour and Minutes hands run as usual but the second hand

stops at the 6.

•Location – Try a different location, ideally near a window. Your

clock should be at least six feet from computers, TVs, air

conditioners, other atomic clocks and other electrical

appliances that cause interference.

•Weather – Electrical storms between you and Colorado during

the night will interfere with the WWVB signal.

Set

404-1235UA-SS www.lacrossetechnology.com/support Page | 5

Function of Movement/Switches

Set Button

•Use the SET button to set hours and minutes when button

2 is set to Q-Set, and button 3 is set to Q-Mode.

•When ET(Custom), it is used to select other time zones:

(UTC+0h toUTC-11h).

DST/Q-Mode slide switch

•Atomic Time select DST on/off.

•In Quartz clock mode, it is used to choose Quartz

run/Quartzset.

Time Zone 6-position slide switch

•Sleep = sleep mode

•

PT/MT/CT/ET, Atomic time (4 time zone selection)

•

ET(Custom) Atomic time mode

(Custom TimeZone selection with SET button)

•Q-Mode,Quartz clock mode (manual set)

Eco Mode slide switch

•Atomic mode, to choose ECO function on/off.

Specifications

Operating Temperature: 23°F to 131°F (-5°C to +55°C)

Power Requirements: 2 or 4 “C” LR14 batteries

Battery Life: over 3 years with reputable battery

Brands

404-1235UA-SS www.lacrossetechnology.com/support Page | 6

Care and Maintenance

•Do not mix old and new batteries

•Do not mix Alkaline, Standard, Lithium or Rechargeable

Batteries

•Always purchase the correct size and grade of battery most

suitable for intended use.

•Replace all batteries of a set at the same time.

•Clean the battery contacts and also those of the device prior to

battery installation.

•Ensure the batteries are installed with correct polarity (+and -).

•Remove batteries from equipment which is not to be used for

an extended period of time.

•Remove expired batteries promptly.

Warranty and Support Information

La Crosse Technology, Ltd. provides a 1-year limited time

warranty (from date of purchase) on this product relating to

manufacturing defects in materials & workmanship.

Before returning a product, please contact our friendly

customer support with questions or visit our online help and

FAQS:

Phone: 1-608-782-1610

Online Product Support: www.lacrossetechnology.com/support

Product Registration:

www.lacrossetechnology.com/support/register

View full warranty details online at:

www.lacrossetechnology.com/warranty_info.pdf

Warranty Address: Protected under U.S. Patent:

La Crosse Technology, Ltd RE43903

2830 S. 26th St.

La Crosse, WI 54601
