SET UP GUIDE

Model: CA308148

Wireless

Temperature & Humidity Station

POWER UP

1. Insert 2-AAA batteries into your Outdoor Sensor.

2. Insert 2-AAA batteries into your Station.

3. Enter the Settings Menu to set the Time, Date, and Temperature.

4. Once the sensor is reading to your station, place the sensor outside in a

shaded location.

Sensor

TX147TH

Station

CA308148

BUTTONS

SET/MODE

Press then release to change viewing mode.

Hold to enter Settings Menu.

Settings: Press then release to move to next item.

+ PLUS

Press then release to view HI/LO records.

Hold to search for Sensor.

Settings: Press to adjust settings. Hold to adjust quickly.

 MINUS Hold to reset all HI/LO Records.

Settings: Press to adjust settings. Hold to adjust quickly. 2

SET/MODE

RÉGLAGES/MODE

Settings Menu Order:

• Hour

• Minutes

• Year

• Month

• Date

• Celsius/Fahrenheit

Important: Only press or hold one button at a time to set your station.

1. Hold the SET/MODE button until the display changes to enter the

Settings Menu.

2. Press then release the + or - button to adjust the values.

Hold to adjust quickly.

3. Press then release the SET/MODE button to conﬁrm and move to the

next item.

SETTINGS MENU

Weekday: Weekday will set automatically when Year, Month and Date are

set.

STATION AND SENSOR MOUNTING

Station: Place the display directly on a table using the built-in pull-down

stand on the back. Alternatively, hang it on a wall using the triangle hanging

hole on the back.

Sensor: Insert a screw through the front hanging hole to mount the sensor

outside in a shaded location. For more details, watch our video here:

bit.ly/th_sensor_mounting.

Built-in Stand Folds down from

back and clicks back into place.

CUSTOM DISPLAY MODES

Press then release the SET/MODE button to view Temperature or Humidity

in large numbers. Station will stay on the selection.

Temperature Large Humidity Large

Position vertically to allow

condensation to drain out.

Use the Triangle Hanging

Hole on the back to mount

on a wall.

HIGH/LOW RECORDS

View Records:

Press then release the +

(PLUS) button to view high

and low records with time and

date stamp.

Viewing Order:

Outdoor HI Temp

Outdoor LO Temp

Outdoor HI Humidity

Outdoor LO Humidity

Indoor HI Temp

Indoor LO Temp

Indoor HI Humidity

Indoor LO Humidity

Reset Records:

While viewing a record, hold

the - (MINUS) button to reset

that individual record.

A full restart will reset all

records at once.

SEARCH FOR SENSOR

LOW BATTERY INDICATOR

• When the Low Battery Icon shows by the indoor temperature, replace

batteries in the station.

• When the Low Battery Icon shows by the outdoor temperature, replace

batteries in the sensor.

Lost Connection to Sensor Searching for Sensor

• If a sensor loses connection to the thermometer for any reason, the

thermometer will show NO on screen after 30 minutes.

• The thermometer will automatically search for 3 minutes every hour to try

and reconnect with the sensor.

• Install a new set of regular alkaline batteries into the sensor. Then hold

the + (PLUS) button on the station until the Reception Icon starts to

animate.

• If the connection still cannot be reestablished, visit our support page here:

bit.ly/basic_restart for further troubleshooting.

Station (CA308148)

Power Requirements: 2 “AAA” batteries (not included)

Battery Life: Up to 12 months

Temperature Range: 0ºC to 50ºC (32ºF to 122ºF)

Humidity Range: 10% to 99% RH

Dimensions: 11.75cm L x 2.02cm D x 7.43cm H (4.63” L x 0.79” D x 2.93” H)

Sensor (TX147TH)

Power Requirements: 2 “AAA” batteries (not included)

Battery Life: Up to 12 months

Temperature Range: -40ºC to 60ºC (-40ºF to 140ºF)

Humidity Range: 10% to 99% RH

Transmission Range: 330 feet (100meters) open air, 433MHz

Update Interval: About every 51 Seconds.

Dimensions: 6.52cm L x 1.98cm W x 6.6cm H (2.57” L x 0.78” W x 2.6” H)

This product operates on alkaline batteries. However, it is suggested to use lithium

batteries in areas where the temperatures is consistently below -30°C (-22°F)

SPECIFICATIONS

Ask questions, watch setup videos, and provide feedback on our social media outlets.

Follow La Crosse Technology on YouTube, Twitter, Facebook and Instagram.

STAY IN TOUCH

Battery replacement instruction:

When batteries of dierent brand or

type are used together, or new and old

batteries are used together, some batteries may

be over-discharged due to a dierence of voltage

or capacity. This can result in venting, leakage, and

rupture and may cause personal injury.

• Always purchase the correct size and grade of

battery most suitable for the intended use.

• Always replace the whole set of batteries at one

time, taking care not to mix old and new ones, or

batteries of dierent types.

• Clean the battery contacts and those of the device

prior to battery installation.

• Ensure the batteries are installed correctly with

regard to polarity (+ and -).

• Remove batteries from product during periods of

non-use. Battery leakage can cause corrosion and

damage to this product.

• Remove used batteries promptly.

• For recycling and disposal of batteries, and

to protect the environment please check the

internet or your local phone directory for local

recycling centers and/ or follow local government

regulations.

WARRANTYBATTERY INSTRUCTIONS

La Crosse Technology, Ltd. provides a 1-year

limited time warranty (from date of purchase)

on this product relating to manufacturing

defects in materials and workmanship.

Self-help: bit.ly/ca308148

Before returning a product, please contact our

friendly customer support with questions:

Springﬁeld Instruments Inc.

104 Barr St.

Saint Laurent, Québec

H4T 1Y4

Customer Service:

1-844-687-4040

info@springﬁeldinstruments.com

This device contains licence-exempt

transmitter(s)/receiver(s) that comply with

Innovation, Science and Economic Develop-

ment Canada’s licence-exempt RSS(s).

Operation is subject to the following two

conditions:

(1 ) This device may not cause interference.

(2) This device must accept any interference,

including interference that may cause

undesired operation of the device.

CANADA STATEMENT

reproduced in any form, even in part, or

duplicated or processed using electronic,

mechanical or chemical process without the written

permission of the publisher. This booklet may

contain errors or misprints. The information it

contains is regularly checked and corrections are

included in subsequent editions. We disclaim any

responsibility for any technical error or printing error,

or their consequences.

All trademarks and patents are recognized.

GUIDE D’UTILISATION

Modèle : CA308148

Station de

température et d’humidité sans ﬁl

MISE EN MARCHE

1. Insérez 2 piles AAA dans le capteur extérieur.

2. Insérez 2 piles AAA dans la station.

3. Accédez au menu des réglages pour régler l’heure, la date et la température.

4. Une fois que votre station capte le signal du capteur, placez le capteur dehors,

dans un endroit ombragé.

Capteur

TX147TH

Station

CA308148

BOUTONS

SET/MODE

(RÉGLAGE/MODE)

Pressez et relâchez pour changer le mode d’affichage.

Maintenez enfoncé pour entrer dans le menu des réglages.

Réglages : Pressez et relâchez pour passer au réglage suivant.

+ (PLUS)

Pressez et relâchez pour voir les maximums et minimums (HI/LO) enregistrés.

Maintenez enfoncé pour chercher le signal du capteur complémentaire.

Réglages : Pressez pour modifier les réglages. Maintenez enfoncé pour un réglage

rapide.

- (MOINS)

Maintenez enfoncé pour réinitialiser tous les maximums et minimums (HI/LO)

enregistrés.

Réglages : Pressez pour modifier les réglages. Maintenez enfoncé pour un réglage

rapide. 2

SET/MODE

RÉGLAGES/MODE
