SET UP GUIDE

MODEL: C75723-AU

Curved Digital Clock

& Weather Station

1. Insert 2-AA batteries into your Outdoor Sensor.

2. Insert 3-AA batteries Into your Digital Clock.

3. Hold the SET button on the right side of your clock to enter the Settings

Menu to adjust your time and date.

4. Once the sensor is reading to your clock, place the senor outside in a

shaded location. For additional mounting instruction visit:

bit.ly/temp_mounting

Power Up

Outdoor Sensor

TX141-Bv3

Digital Clock

C75723-AU

Settings Menu

1. Hold the SET button to enter the Settings Menu.

2. Use the +/- buttons to adjust values.

3. Press SET to conﬁrm values.

4. Press the SNOOZE button at any time to save and exit.

Settings Menu

Settings Menu Order:

• Beep ON/OFF

• Hour

• Minutes

• Year

• Month

• Date

• Temperature Celsius/Fahrenheit

Note: Weekday sets automatically when Year, Month and Date are set.

Forecast Icons

• Six Forecast Icons use changing atmospheric pressure to predict your

weather conditions to come within the next 12 hours. The accuracy of

these icons should improve over time.

• When the outdoor temperature is below 0°C (32°F) and the forecast is

predicting rain or storms, the clock will display snow.

FORECAST FORECAST FORECAST FORECAST FORECAST FORECAST

Sunny Partly

Sunny

Clouds SnowT-StormRain

Time Alarm

Set Alarm:

1. Hold the ALARM button to enter the Alarm Settings.

2. Use the +/- buttons to adjust values.

3. Press the ALARM button to confirm and move to the next item.

Silence a sounding alarm: Press any button except SNOOZE to silence the

alarm for 24 hours.

Activate/Deactivate Alarm:

• Press the ALARM button to activate or deactivate the alarm.

• The Alarm Icon will show when the alarm is active.

Snooze:

• When the alarm sounds, press the SNOOZE button to silence

the alarm for 10 minutes. Zz will show.

Note: The alarm will sound with increasing frequency for two minutes,

then shut off automatically if not silenced.

Alarm Hour

INDOOR OUTDOORFORECAST

Alarm Minutes

INDOOR OUTDOORFORECAST

1. Hold the ALERTS button to enter the Alerts Menu.

2. Use the +/- buttons to arm or disarm an alert.

3. When Alert is ON, press the ALERTS button and the Alert Value will flash.

4. Use the +/- buttons to adjust, and ALERTS to confirm.

5. Press the SNOOZE button at any time to save and exit.

Alerts Menu Order:

• Outdoor HI Temperature • Outdoor LO Temperature

• Indoor HI Temperature • Indoor LO Temperature

Sounding Alert:

• When armed alert value is reached, the clock will beep 5 times each minute until

out of the alert range.

• The ﬂashing Alert Icon will indicate if is a LO or HI alert.

• Press any button to stop the alert sound. The Alert Icon will ﬂash while value is in

the alert range.

Temperature Alerts

Outdoor HI Alert Outdoor LO Alert

INDOOR OUTDOORFORECAST

Daily HI/LO Temperature Records

Temperature Trend Arrows

Both your indoor and outdoor temperature readings have Trend Arrows

used to indicate changes (1°C / 2°F) over the past one hour period.

Temperature has risen over the past hour.

Temperature has been steady over the past hour.

Temperature has fallen over the past hour.

Your clock will record your daily indoor and outdoor HI and LO temperature

readings. These will reset automatically at midnight.

HI Values: Press the + button to view today’s high indoor reading, then high

outdoor reading.

LO Values: Press the - button to view today’s low indoor reading, then low

outdoor reading.

Indoor HI Outdoor HI Indoor LO Outdoor LO

INDOOR OUTDOORFORECAST INDOOR OUTDOORFORECAST

INDOOR OUTDOORFORECAST

Search for Outdoor Temperature

If you are seeing dashes for your outdoor readings, please try the

following steps:

1. Hold the SEARCH button to search for your outdoor sensor. The

Reception Indicator will begin to animate.

2. If after 3 minutes the sensor still isn’t connected, bring the sensor inside

next to the display and remove power from both the sensor and clock.

3. Press any button on the clock 20 times and leave the parts sit for a few

moments with the power o.

4. Install a new set of alkaline batteries into the sensor, then into your clock.

For additional help visit: bit.ly/basic_restart

Low Battery Indicator

When Low Battery Icon appears on the right side of the time, replace the

batteries on the clock. When the icon appears in the outdoor temperature

area, replace the sensor batteries

Stay in Touch

Follow La Crosse Technology on YouTube, Twitter, Facebook and Instagram.

Ask questions, watch setup videos, and provide feedback on our social

media outlets.

Care + Maintanence

Do not mix old and new batteries.

Do not mix Alkaline, Lithium, standard, or

rechargeable batteries.

Always purchase the correct size and grade

of battery most suitable for intended use.

Clean the battery contacts and also those of

the device prior to battery installation.

Ensure the batteries have been installed

with correct polarity (+/-).

Remove batteries from equipment that will

not to be used for an extended period.

Promptly remove expired batteries.

Speciﬁcations

Atomic Clock (C75723-AU)

Temperature Range:

-10°C to 50°C (14°F to 122°F)

Power Requirements:

3-AA, IEC, LR6 batteries (included)

Dimensions:

30.97cm W x 4.2cm D x 30.17cm H

(12.19” W x 1.61” D x 11.87” H)

Outdoor Sensor (TX141-Bv3)

Temperature Range:

-40°C to 70°C (-40°F to 158°F)

Transmission Range: Over 100 meters

open air (330 feet) RF 433MHz

Update Interval: About every 51 seconds

Power: 2-AA, IEC, LR6 batteries (included)

Battery Life: Over 12 months

Dimensions:

4.02cm L x 2.08cm W x 13.0cm H

(1.57” L x 0.79” W x 5.12” H)

Please Recycle

Please consider the environment when deciding

to dispose of this product. Although household

electronics are generally safe to use on a daily

basis, incorrect disposal can cause negative and

potentially irreversible impacts on our environment.

Check with local donation centers to see if your

product can be donated for future use. If disposal is

the only option, federal agencies, local governments,

and certiﬁed retailers may have electronic recycling

programs in place. Programs may vary based on

location.

Recycling and Disposal

Designed in La Crosse, Wisconsin •Made in China •Printed in China •DC 070921

Warranty Info

La Crosse Technology, Ltd. provides a 1-year

limited time warranty (from date of purchase) on

this product relating to manufacturing defects in

materials & workmanship.

La Crosse Technology, Ltd,

2830 S. 26th St.

La Crosse, WI 54601

Contact:

www.lacrossetechnology.com/pages/international-support

The manufacturer is not responsible for any radio or

TV interference caused by unauthorized changes

or modiﬁcations to this equipment. Such changes

or modiﬁcations could void the user authority to

operate the equipment.

reproduced in any form, even in part, or duplicated

or processed using electronic, mechanical or

chemical process without the written permission

of the publisher. This booklet may contain

errors or misprints. The information it contains is

regularly checked and corrections are included in

subsequent editions. We disclaim any responsibility

for any technical error or printing error, or their

consequences.

All trademarks and patents are recognized.

Caution!

Black Forest Originals Grand Father Clock, Ltd.

DBA La Crosse Technology, Ltd.

2809 Losey Blvd. South

La Crosse, WI 54601

Please help in the preservation of

the environment and return used

batteries to an authorized depot

Our goods come with guarantees that cannot be

excluded under the Australian Consumer Law.

You are entitled to a replacement or refund for a

major failure and for compensation for any other

reasonably foreseeable loss or damage.

You are also entitled to have the goods repaired or

replaced if the goods fail to be of acceptable quality

and the failure does not amount to a major failure.
