WS-8056U

433 MHz

Radio Controlled Temperature Alarm

Instruction Manual

              

TABLE OF CONTENTS

Topic Page

Inventory of Contents/ Additional Equipment 3

About WWVB 3

Quick Set-Up Guide 4

Detailed Set-Up Guide

Battery Installation 5

Program Mode

Function Buttons 6

Time Zone Setting 6

DST (Daylight Saving Time) Setting 7

Language Selection 7

Time Setting 7

Calendar Setting 8

12/24-Hour Setting 8

Selecting °F or °C 8

Features & Operations

Changing Display Mode (viewing seconds) 9

The Alarm 10

Indoor temperature 11

Remote Temperature 11

Mounting 11

Maintenance & Care 12

Troubleshooting 13

Specifications 14

Warranty Information 15-16

INVENTORY OF CONTENTS

1) WS-8056U

2) TX6U remote temperature transmitter

3) Instruction manual and warranty card.

ADDITIONAL EQUIPMENT (not included)

1) Two fresh 1.5V AA batteries.

2) Two fresh 1.5V AA batteries.

3) Three wall-hanging screws.

4) Appropriate screwdriver for screws.

ABOUT WWVB (Radio Controlled Time)

The NIST (National Institute of Standards and Technology—Time and Frequency

Division) WWVB radio station is located in Ft. Collins, Colorado, and transmits the exact

time signal continuously throughout the United States at 60 kHz. The signal can be

received up to 2, 000 miles away through the internal antenna in the Temperature Alarm.

However, due to the nature of the Earth’s Ionosphere, reception is very limited during

daylight hours. The Temperature Alarm will search for a signal every night when

reception is best. The WWVB radio station derives its signal from the NIST Atomic

clock in Boulder, Colorado. A team of atomic physicists is continually measuring every

second, of every day, to an accuracy of ten billionths of a second per day. These

physicists have created an international standard, measuring a second as 9,192,631,770

vibrations of a Cesium-133 atom in a vacuum.

QUICK SET-UP GUIDE

Hint: Use good quality Alkaline Batteries and avoid rechargeable batteries.

1. Have the temperature clock and remote temperature sensor 3 to 5 apart.

2. Batteries should be out of both units for 10 minutes.

3. Place the batteries into the remote temperature sensor first then into the

temperature clock.

(All remote temperature sensors must be started before the temperature

clock)

4. DO NOT PRESS ANY BUTTONS FOR 10 MINUTES.

In this time the temperature clock and remote temperature sensor will start to talk to each

other and the temperature clock will show both the indoor temperature and an outdoor

temperature. If the temperature clock does not display both temperatures after the 10

minutes please retry the set up as stated above. After both indoor and outdoor

temperatures are displayed for 10 minutes you can place your remote temperature sensor

outdoors and set your time.

The remote temperature sensor should be placed in a dry, shaded area. The remote

temperature sensor has a range of 80 feet. Any walls that the signal will have to pass

through will reduce distance. An outdoor wall or window will have 20 to 30 feet of

resistance and an interior wall will have 10 to 20 feet of resistance. Your distance plus

resistance should not exceed 80 ft. in a straight line.

NOTE: Fog and mist will not harm your remote temperature sensor but direct rain must

be avoided.

To complete the set up of your temperature clock after the 10 minutes have passed please

follow the steps below.

DETAILED SET-UP GUIDE

I) BATTERY INSTALLATION

Note: To avoid start-up problems make sure that the batteries do not spring free.

A) REMOTE TEMPERATURE SENSOR

1) Remove the battery cover. Place your thumb over

the two air-vent slots on the face of the remote

temperature sensor, push down gently, and slide

battery cover down and off.

2) Observing the correct polarity, install 2 AA

batteries. The batteries will fit tightly (to avoid

start-up problems make sure that they do not spring

free during installation).

3) Replace the battery cover.

B) TEMPERATURE ALARM

1) Remove the battery cover,

located on the backside of the

unit and directly below the

function buttons.

2) Observe the correct polarity and

install 2 AA batteries.

3) Replace the battery cover.

Note: After the batteries have been

installed a tone will sound, and all

the LCD’s (Liquid Crystal Display)

will briefly light up. The indoor

temperature, the date as “1/ 1”, the

weekday as “MON”, and the remote

temperature will be displayed (within

three minutes). Also, the time will

appear as “-:--” for approximately 1

minute. The WWVB search is automatically initiated, and a tower icon appears and

flashes with the time colon (no tower icon will appear if the WWVB is too weak to

be detected, and the time display will remain on “-:--”). While the WWVB search is

being conducted various numbers will appear in the time display. After 10minutes,

the temperature alarm will either display the WWVB time, or discontinue the search

if the time is not found. If the search is cancelled “-:--” will appear in the time LCD.

The temperature alarm will conduct a WWVB search every hour until the first signal

is found. Once the WWVB time is found, a search is automatically conducted

nightly at midnight. If the signal is found at midnight, the tower icon will remain, if

not, another search will take place every hour (until 6:00 am) until the signal is

found successfully. If no signal is found during this period, the tower icon will not

appear and the clock will search again at 12:00 am the next night.

Outdoor tem

erature

Date

WWVB

larm

Radio rece

tion

Indoor temperature or

seconds display

Weekday or

seconds display

II) PROGRAM MODE

To enter the program mode hold down the “SET” button for 2 seconds, until

“-5EST” flashes in the date LCD. The program mode is laid out in a manner that

allows you to program each function separately, or you can follow the instructions

entirely to program the temperature alarm. Complete programming is usually done

for the initial set-up, and will require you to skip step 1 of programming sections III

through VIII. Press the “SNOOZE” button at any time to exit the program mode, or

wait approximately 15 seconds for the temperature alarm to automatically return to

normal operation.

A) FUNCTION BUTTONS

There are 3 function buttons located on the front

of the temperature alarm and one on the top. The

function buttons are labeled: “SET”, “+”,

“ALARM”, and “SNOOZE” (the top bar).

B) TIME ZONE SETTING

1) Hold down the “SET” button for 2 seconds,

the default setting “-5EST” will flash in the date LCD.

2) Press and release the “+” button to select the appropriate time zone. There

are 13 time zones to choose from:

3) Press and release the “SET” button to confirm the time zone setting, and to

advance to DST (Daylight saving time) setting.

-4ATL Atlantic Time

-5EST Eastern Time (default setting)

-6CST Central Time

-7MST Mountain Time

-8PST Pacific Time

-9ALA Alaskan Time

-10HAW Hawaiian Time

-11, -12 Next two time zones West of HAW

GMT Greenwich Mean Time

-1, -2, -3GMT Three time zones West of GMT

              

US English

F French

E Spanish

C) DST (DAYLIGHT SAVING TIME) SETTING

Note: The DST default is “On”, meaning that the WWVB will automatically

change the time according to Daylight Saving Time in the spring and fall. For

areas that do not recognize DST changes (Arizona and parts of Indiana) turn

the DST “OFF”.

1) Hold down the “SET” button for 2 seconds (the selected time zone will

flash); press and release the “SET” button once more until “On” flashes in

the time LCD and “DST” flashes where the weekday normally appears.

2) Press and release the “+” button to turn the DST off, this will be indicated

by the display of “OFF” in the time LCD.

3) Press and release the “SET” button to confirm the DST setting and to

advance to select the language for the weekday.

D) LANGUAGE SELECTION FOR THE WEEKDAY

1) Hold down the “SET” button for 2 seconds (the selected time zone will

flash), press and release the “SET” button 2 more times until the default

language “US” flashes in the time LCD.

2) Press and release the “+” button to toggle through and to select the desired

language. There are 3 languages to select from:

Press and release the “SET” button to confirm the language setting, and to

advance to manually set the time.

E) TIME SETTING

Note: When the WWVB signal is found, that time will over-ride the manually set

time.

1) Hold down the “SET” button for 2 seconds (the selected time zone will

flash), press and release the “SET” button 3 more times until the hour “12”

flashes in the time LCD.

2) Press and release the “+” button to select the hour. Note: when setting the

hour, “PM” will appear to the left of the hour display, if it is AM nothing

will be displayed.

3) Press and release the “SET” button to confirm the hour setting, and to shift

to select the minutes.

4) Press and release the “+” button to select the minutes.

5) Press and release the “SET” button to confirm the time setting, and to

advance to manually set the calendar.

F) CALENDAR SETTING

Note: When the WWVB signal is found, that date will over-ride the manually set

date.

1) Hold down the “SET” button for 2 seconds (the selected time zone will

flash), press and release the “SET” button 5 more times until the default

year “00” flashes in the date LCD.

2) Press and release the “+” button to select the year.

3) Press and release the “SET” button to confirm the year and to move to

select the month.

4) The default month “1” will flash. Press and release the “+” button to select

the appropriate month.

5) Press and release the “SET” button to confirm the month and to move to

select the date.

6) The default date “1” will flash. Press and release the “+” button to select

the appropriate date.

7) Press and release the “SET” button to confirm the date and to move to

select the weekday.

8) The default weekday “MON” (depends on selected language) will flash.

Press and release the “+” button to select the appropriate weekday.

9) Press and release the “SET” button to confirm the calendar settings and to

advance to select either 12 or 24-hour time display.

G) 12/24-HOUR SETTING

1) Hold down the “SET” button for 2 seconds (the selected time zone will

flash), press and release the “SET” button 9 more times until the “12” hour

time display flashes in the time LCD.

2) Press and release the “+” button to toggle between 12 and 24 hour time.

3) Press and release the “SET” button to confirm the 12/24-hour time display

and to advance to select either °F or °C.

H) SELECTING °F OR °C

1) Hold down the “SET” button for 2 seconds (the selected time zone will

flash), press and release the “SET” button 10 more times until the default

“°F” flashes in the time LCD.

2) Press and release the “+” button to toggle between °F and °C.

3) Press and release the “SET” button to confirm the °F or °C selection and

exit the Program Mode.

III) FEATURES & OPERATIONS

A) CHANGING DISPLAY MODE (DAY, SECONDS, AND

TEMPERATURE)

There are three possible display modes to view the day, seconds, and

temperature.

The month&date/weekday /indoor temperature/remote temperature is the

default.

To change the display:

1) Press and release the “+” button.

2) The display should now show the month&date/seconds/indoor

temperature/remote temperature

3) Press and release the “+” button a second time.

4) The display will now show the month&date/weekday/seconds/remote

temperature

5) Press and release the “+” button a third time and the display will return to

the normal display.

B) THE ALARM

1) SETTING THE ALARM

Note: The duration of the alarm is 85 seconds. After each of the first two 25

second periods, the rate of the alarm increases.

(a) Hold down the “ALARM” button for 5 seconds. The “TIME” icon to

the right of the minutes (in the time LCD) shifts to “ALARM” and the

hour digit of the alarm flashes.

(b) Press and release the “+” button to set the alarm hour.

the alarm minutes.

(d) The alarm minutes will now flash.

(e) Press and release the “+” button to set the alarm minutes.

(f) Press and release the “ALARM” button to confirm and to exit the alarm

setting mode.

Note: The alarm will be automatically set to sound when exiting the

alarm-setting mode (indicated by the alarm “sound” icon to the right

of the time).

2) ACTIVATING/DEACTIVATING THE ALARM

(a) The alarm will be automatically set to sound when exiting the alarm-

setting mode (indicated by the alarm “sound” icon to the right of the

time).

(b) Press and release the “ALARM” button to activate and deactivate the

alarm. The alarm “sound” icon to the right of the time will appear or

disappear and the alarm time will be displayed briefly before returning

to the normal display mode.

3) ACTIVATING THE SNOOZE FUNCTION

(a) While the alarm is sounding, press and release the “SNOOZE” button

to activate the snooze function. The alarm “sound” icon and

“SNOOZE” icon (to the right of the time) will flash. The duration of

the snooze function is 10 minutes, then the alarm will resume.

4) SUSPENDING ALARM

(a) While the alarm is sounding or the SNOOZE is active, press and

release the “ALARM” button to suspend the alarm until the next day.

Table des matières

Autres manuels La Crosse Technology Réveil

La Crosse Technology

La Crosse Technology W85923 Dimensions

La Crosse Technology

La Crosse Technology 616-146 Manuel utilisateur

La Crosse Technology

La Crosse Technology C86224 Manuel d'utilisation et d'entretien

La Crosse Technology

La Crosse Technology 617-1485Bv3 Manuel utilisateur

La Crosse Technology

La Crosse Technology 817-2410B Manuel utilisateur

La Crosse Technology

La Crosse Technology CA80765 Manuel utilisateur

La Crosse Technology

La Crosse Technology 617-1485 Manuel utilisateur

La Crosse Technology

La Crosse Technology WT-2191A Manuel utilisateur

La Crosse Technology

La Crosse Technology 617-1485Bv2 Manuel utilisateur

La Crosse Technology

La Crosse Technology W85923 Manuel d'utilisation et d'entretien

La Crosse Technology

La Crosse Technology C85183 Manuel utilisateur

La Crosse Technology

La Crosse Technology 617-106 Dimensions

La Crosse Technology

La Crosse Technology 317-1909 Dimensions

La Crosse Technology

La Crosse Technology WS-8349U Manuel utilisateur

La Crosse Technology

La Crosse Technology C85135 Dimensions

La Crosse Technology

La Crosse Technology 817-2410 Manuel utilisateur

La Crosse Technology

La Crosse Technology C87207 Manuel utilisateur

La Crosse Technology

La Crosse Technology 616-1950V2 Manuel utilisateur

La Crosse Technology

La Crosse Technology W88723v2 Manuel utilisateur

La Crosse Technology

La Crosse Technology 616-146A Manuel utilisateur

La Crosse Technology

La Crosse Technology Equity 20090 Manuel utilisateur

La Crosse Technology

La Crosse Technology 616-1412v3 Manuel utilisateur

La Crosse Technology

La Crosse Technology 602-249 Dimensions

La Crosse Technology

La Crosse Technology 616-146v2 Manuel utilisateur

Manuels Réveil populaires d'autres marques

Steren

Steren CLK-210 Manuel utilisateur

COP-USA

COP-USA ALCDVR32-SL Manuel utilisateur

Philips

Philips HF3505/70 Manuel technique

Casio

Casio PQ-70 Manuel utilisateur

iHome

iHome IA63 Manuel utilisateur

Coopers

Coopers 9765 Manuel utilisateur

ANJANK

ANJANK AC-190 Mode d’emploi

TFA

TFA 98.1075 Manuel utilisateur

Sharper Image

Sharper Image 204050 Manuel utilisateur

Lumie

Lumie Zest Manuel utilisateur

Dexford

Dexford RCT200 Manuel utilisateur

Philips

Philips AJL303/37B Manuel utilisateur

RST

RST Q754 Manuel utilisateur

iHome

iHome iKT50 Manuel utilisateur

Sony

Sony dash HID-B7 Manuel utilisateur

SVINZ

SVINZ SCC009 Manuel utilisateur

Clas Ohlson

Clas Ohlson 918863 Manuel utilisateur

IKEA

IKEA FNURRA Manuel utilisateur
