617-1485 www.lacrossetechnology.com/support Page | 1

Model: 617-1485

Instruction Manual

DC: 041916

ATOMIC ALARM CLOCK

AC Power Jack

HX09-0501500-AU

USB Charge Port

AAA

617-1485 www.lacrossetechnology.com/support Page | 2

Get Started

1: Insert 5.0 volt AC adapter into the wall then into the back of

the alarm clock.

2: Insert 2 new AAAAlkaline batteries (not included) into the

alarm clock. Observe the correct polarity.

Restart: If there is no indoor temperature data after 60 seconds,

unplug the AC adapter and remove batteries from the alarm clock,

press any button 20 times. After 15 minutes, return to # 1 above.

LCD Features

Adjust Backlight HI/LOW/OFF

For constant backlight use A/C adapter:

•Press the HI/LOW/OFF button to adjust the backlight.

Battery power only:

•Press the HI/LOW/OFF button and backlight will come on for

10 seconds when operating on battery power.

•Backlight will not stay on with battery operation only.

Low Battery Icon

When the icon is displayed in below the moon phase,

replace batteries in the alarm clock.

Indoor

Temperature

+ Trend

indicators

Atomic Time Moon Phase

Indoor

Humidity

+ Trend

indicators

Low Battery

Icon

WWVB

Tower

Weekday, Month & Date

617-1485 www.lacrossetechnology.com/support Page | 3

Set Time & Calendar

1. Hold the SET button to enter time set mode.

2. Press the +or -buttons to adjust values.

3. Press the SET button to confirm adjustments and move to the

next item.

Setting order:

1. WWVB time signal (On/Off)

2. Time Zone - 7 time zones

3. DST (Daylight Saving Time On/Off)

4. 12/24 hour time format

5. Hour

6. Minutes

7. Year

8. Month

9. Date

Press the SET button to exit, or wait 20 seconds without pressing

buttons to return to the normal time display.

Fahrenheit/Celsius

•Press the °F/°C button to select temperature readings in

Fahrenheit or Celsius.

USB Charging Port

NOTE: This is a power-output charging port. It does not provide

power to the alarm clock.

Charge a smart phone, camera or other devices when the alarm

clock is plugged into a power outlet with the included 5.0V AC

adapter.

•Connect your external device’s USB

charging cable (not included) to the USB

charging port.

•Charging times will vary.

•USB Power Output: 1A maximum current.

•Charge 1A devices or devices that are

self-regulating.

617-1485 www.lacrossetechnology.com/support Page | 4

Alarm

Bell Icon

Set Time Alarm

Setting the alarm and activating the alarm are separate actions.

1. Hold the ALARM button for 5 seconds to enter alarm time set

mode.

2. The letters “AL” will replace the seconds and the alarm hour

will flash.

3. Press the ALARM button to confirm and move to the minutes.

4. Press the +or -buttons to adjust the alarm minutes.

5. Press the ALARM button to confirm. After 5 seconds the clock

will default to regular time mode.

Activate/Deactivate Time Alarm

•Press the ALARM button once to enter alarm mode.

The letters “AL” will replace the seconds

•Press the ALARM button again to activate the alarm.

Once activated, the bell icon appears.

•Press the ALARM button again to deactivate the

alarm. The bell icon will disappear.

Snooze (Silences alarm temporarily)

•When alarm sounds, press the SNOOZE button to silence the

alarm for 10 minutes.

•The snooze icon Zz will flash.

•In snooze mode, press the ALARM button to stop alarm for

one day.

Note: The alarm is crescendo sound. The alarm will sound for 2

minutes and then shut off completely if no buttons are pressed.

Normal Time Display Alarm Mode

617-1485 www.lacrossetechnology.com/support Page | 5

Temperature/Humidity Trend Indicators

The temperature (2°F / 1°C) and humidity (1% RH) trend

indicators update every 30 minutes or less.

•Temperature has risen in the past 3 hours.

•Humidity has risen in the past 3 hours.

•Temperature has not changed in the past 3 hours.

•Humidity has not changed in the past 3 hours.

•Temperature has fallen in the past 3 hours.

•Humidity has fallen in the past 3 hours.

Manual WWVB Atomic Time Search

•Hold the -button to start or stop a WWVB signal search.

•WWVB Icon will flash when searching.

For information about WWVB visit:

www.nist.gov/pml/div688/grp40/wwvb.cfm

ATOMIC SIGNAL SEARCH:

The LCD backlight and USB charging port will momentarily turn off

while the station searches for the atomic signal. The alarm clock

will start searching at UTC 7:00, 8:00, 9:00, 10:00, 11:00.；

If there is no WWVB reception, the alarm clock will search the

WWVB time signal every 2 hours until the WWVB time is received.

After reception, this alarm clock will only search for the atomic

signal after midnight.

Position Alarm Clock

•Position the alarm clock three feet from the electrical outlet

and six feet from other electronics for best WWVB reception.

•Have the front or back of the alarm clock facing Colorado.

617-1485 www.lacrossetechnology.com/support Page | 6

Moon Phase

The moon phase is based on the Gregorian calendar and the

year, month and date set (manually or by the WWVB signal). Most

Internet moon phase calculations are based on the lunar calendar.

Specifications

Indoor:

Temperature Range: +32°F to +122°F (0°C to 50°C)

Humidity Range: 10% to 99% RH

Power:

Atomic Alarm Clock: 5.0V A/C power adapter (included)

AC6 Adapter number: HX09-0501500-AU

Battery backup: 2-AAA, IEC, LR3 batteries ( not included)

Battery Life:

Battery Backup: Battery life is over 24 months when using

the AC adapter for primary power

USB:

Output: 1 Amp maximum current

(charging cable not included)

Dimensions:

Atomic Alarm Clock:5.56" L x 2.2" D x 3.33 " H

(141.2 x 55.8 x 86.4 mm)

New Waxing First Waxing Full Waning Last Waning

Moon Crescent Quarter Gibbous Moon Gibbous Quarter Crescent

617-1485 www.lacrossetechnology.com/support Page | 7

Care and Maintenance

•Do not mix old and new batteries

•Do not mix Alkaline, Standard, Lithium or Rechargeable Batteries

•Always purchase the correct size and grade of battery most suitable

for the intended use.

•Replace all batteries of a set at the same time.

•Clean the battery contacts and also those of the device prior to

battery installation.

•Ensure the batteries are installed with regard to polarity (+ and -).

•Remove batteries from equipment which is not to be used for an

extended period of time.

•Promptly remove expired batteries.

•If the alarm clock is not working properly, change the batteries and/or

check the A/C cord connection.

Warranty and Support Information

La Crosse Technology, Ltd. provides a 1-year limited time

warranty (from date of purchase) on this product relating to

manufacturing defects in materials & workmanship.

Before returning a product, please contact our friendly

customer support with questions or visit our online help

(manuals and FAQS):

Phone: 1-608-782-1610

Online Product Support:

www.lacrossetechnology.com/support

Product Registration:

www.lacrossetechnology.com/support/register

View full warranty details online at:

www.lacrossetechnology.com/warranty_info.pdf

Warranty Address:

La Crosse Technology, Ltd

2830 S. 26th St.

La Crosse, WI 54601

617-1485 www.lacrossetechnology.com/support Page | 8

FCC STATEMENT

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses and can

radiate radio frequency energy, and if not installed and used in accordance

with the instructions, may cause harmful interference to radio

communications.

However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

This device must not be co-located or operating in conjunction with any

other antenna or transmitter.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including

interference that may cause undesired operation.

Caution!

The manufacturer is not responsible for any radio or TV interference

caused by unauthorized changes or modifications to this equipment. Such

changes or modifications could void the user authority to operate the

equipment.

in part, or duplicated or processed using electronic, mechanical or chemical

process without the written permission of the publisher.

This booklet may contain errors or misprints. The information it contains is

regularly checked and corrections are included in subsequent editions. We

disclaim any responsibility for any technical error or printing error, or their

consequences. All trademarks and patents are recognized.

Canada Statement

This device complies with CNR Industry Canada license -exempt devices.

Operation is subject to the following two conditions:

(1) This device may not cause interference; and

(2) This device must accept any interference, including interference that

may cause undesired operation of the device.

Table des matières

Autres manuels La Crosse Technology Réveil

La Crosse Technology

La Crosse Technology C80765 Dimensions

La Crosse Technology

La Crosse Technology 616A-56647 Manuel utilisateur

La Crosse Technology

La Crosse Technology 616-1950 Manuel utilisateur

La Crosse Technology

La Crosse Technology 616-146A Dimensions

La Crosse Technology

La Crosse Technology 616-1412v2 Manuel d'utilisation et d'entretien

La Crosse Technology

La Crosse Technology WT-5600 Manuel utilisateur

La Crosse Technology

La Crosse Technology 617-1485Bv2 Manuel utilisateur

La Crosse Technology

La Crosse Technology 602-249V2 Dimensions

La Crosse Technology

La Crosse Technology RADIO CONTROLLED PROJECTION CLOCK WITH DIGITAL... Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-8016U Manuel utilisateur

La Crosse Technology

La Crosse Technology RADIO CONTROLLED PROJECTION ALARM CLOCK Manuel utilisateur

La Crosse Technology

La Crosse Technology SOLUNA Manuel utilisateur

La Crosse Technology

La Crosse Technology C86371 Manuel utilisateur

La Crosse Technology

La Crosse Technology WT-5720 Manuel utilisateur

La Crosse Technology

La Crosse Technology WT-2191A Manuel utilisateur

La Crosse Technology

La Crosse Technology 617-3314 Manuel utilisateur

La Crosse Technology

La Crosse Technology Radio-Controlled Travel Alarm Clock WT-2160 Manuel utilisateur

La Crosse Technology

La Crosse Technology 616-143V2 Dimensions

La Crosse Technology

La Crosse Technology 617-148v2 Manuel utilisateur

La Crosse Technology

La Crosse Technology C82929V2 Dimensions

La Crosse Technology

La Crosse Technology T83721 Dimensions

La Crosse Technology

La Crosse Technology CA81199 Dimensions

La Crosse Technology

La Crosse Technology 616-1950V2 Manuel utilisateur

La Crosse Technology

La Crosse Technology 616-146 Manuel utilisateur

Manuels Réveil populaires d'autres marques

Steren

Steren CLK-210 Manuel utilisateur

COP-USA

COP-USA ALCDVR32-SL Manuel utilisateur

Philips

Philips HF3505/70 Manuel technique

Casio

Casio PQ-70 Manuel utilisateur

iHome

iHome IA63 Manuel utilisateur

Coopers

Coopers 9765 Manuel utilisateur

ANJANK

ANJANK AC-190 Mode d’emploi

TFA

TFA 98.1075 Manuel utilisateur

Sharper Image

Sharper Image 204050 Manuel utilisateur

Lumie

Lumie Zest Manuel utilisateur

Dexford

Dexford RCT200 Manuel utilisateur

Philips

Philips AJL303/37B Manuel utilisateur

RST

RST Q754 Manuel utilisateur

iHome

iHome iKT50 Manuel utilisateur

Sony

Sony dash HID-B7 Manuel utilisateur

SVINZ

SVINZ SCC009 Manuel utilisateur

Clas Ohlson

Clas Ohlson 918863 Manuel utilisateur

IKEA

IKEA FNURRA Manuel utilisateur
