SERVICE

MANUAL

Published in June 2012

842MN111

2MNSM061

Rev. 1

FS-C8600DN

FS-C8650DN

CAUTION

RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE

OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

It may be illegal to dispose of this battery into the municipal waste stream. Check with your

local solid waste officials for details in your area for proper disposal.

ATTENTION

IL Y A UN RISQUE D’EXPLOSION SI LA BATTERIE EST REMPLACEE PAR UN MODELE

DE TYPE INCORRECT. METTRE AU REBUT LES BATTERIES UTILISEES SELON LES

INSTRUCTIONS DONNEES.

Il peut être illégal de jeter les batteries dans des eaux d’égout municipales. Vérifiez avec les

fonctionnaires municipaux de votre région pour les détails concernant des déchets solides

et une mise au rebut appropriée.

Notation of products in the manual

For the purpose of this service manual, products are identified by print speed at A4 and

black and white modes.

FS-C8600DN: 45 ppm model

FS-C8650DN: 55 ppm model

Revision history

Revision Date Replaced pages Remarks

1 June 18, 2012 Contents, 1-1-1 to 1-1-3,1-1-6,1-2-2,1-2-8,1-2-9,

1-2-19,1-2-20,1-2-22,1-2-26,1-2-28,1-3-32,1-2-33,

1-2-38,1-2-43,1-3-6 to 1-3-8,1-3-10,1-3-16,1-3-17,

1-3-21 to 1-3-23,1-3-26 to 1-3-29,1-3-31 to 1-3-34,

1-3-37,1-3-38,1-3-48,1-3-49,1-3-53,1-3-54,1-3-59,

1-3-60,1-3-62,1-3-65,1-3-72,1-3-76,1-3-77,1-3-79,

1-3-84,1-3-85,1-3-87 to 1-3-91,1-3-93 to 1-3-96,

1-3-99,1-3-106,1-3-108,1-3-112 to 1-3-116,1-3-126,

1-3-130 to 1-3-133,1-3-135,1-3-137,1-3-139,

1-3-141,1-3-147 to1-3-150,1-4-2,1-4-26 to 1-4-28,

1-4-35 to 1-4-39,1-4-42,1-4-55,1-4-58 to 1-4-60,

1-4-71,1-4-88,1-4-90,1-4-91,1-5-1,1-5-4,1-5-8,

1-5-11,1-5-17,1-5-18,1-5-24,1-5-26,1-5-32,1-5-44 to

1-5-46,1-5-48,1-5-49,1-5-54,1-5-79 to 1-5-81,1-6-1,

1-6-2,2-2-1,2-2-3,2-3-1,2-3-8,2-3-28,2-3-32,2-3-36,

2-3-46,2-3-56,2-3-62,2-3-68,2-3-72,2-4-3,2-4-7,

2-4-8,2-4-13,2-4-22,2-4-23

This page is intentionally left blank.

Safety precautions

This booklet provides safety warnings and precautions for our service personnel to ensure the safety of

their customers, their machines as well as themselves during maintenance activities. Service personnel

are advised to read this booklet carefully to familiarize themselves with the warnings and precautions

described here before engaging in maintenance activities.

Safety warnings and precautions

Various symbols are used to protect our service personnel and customers from physical danger and

to prevent damage to their property. These symbols are described below:

DANGER: High risk of serious bodily injury or death may result from insufficient attention to or incorrect

compliance with warning messages using this symbol.

WARNING: Serious bodily injury or death may result from insufficient attention to or incorrect compliance

with warning messages using this symbol.

CAUTION: Bodily injury or damage to property may result from insufficient attention to or incorrect com-

pliance with warning messages using this symbol.

Symbols

The triangle ( ) symbol indicates a warning including danger and caution. The specific point of attention is

shown inside the symbol.

General warning. Warning of risk of electric shock.

Warning of high temperature.

indicates a prohibited action. The specific prohibition is shown inside the symbol.

General prohibited action. Disassembly prohibited.

indicates that action is required. The specific action required is shown inside the symbol.

General action required. Remove the power plug from the wall outlet.

Always ground the machine.

1. Installation Precautions

WARNING

• Do not use a power supply with a voltage other than that specified. Avoid multiple connections to

one outlet: they may cause fire or electric shock. When using an extension cable, always check that

it is adequate for the rated current. .....................................................................................................

• Connect the ground wire to a suitable grounding point. Not grounding the machine may cause fire

or electric shock. Connecting the earth wire to an object not approved for the purpose may cause

explosion or electric shock. Never connect the ground cable to any of the following: gas pipes, light-

ning rods, ground cables for telephone lines and water pipes or faucets not approved by the proper

authorities. ..........................................................................................................................................

CAUTION:

• Do not place the machine on an infirm or angled surface: the machine may tip over, causing injury. .

• Do not install the machine in a humid or dusty place. This may cause fire or electric shock. ..............

• Do not install the machine near a radiator, heater, other heat source or near flammable material.

This may cause fire............................................................................................................................

• Allow sufficient space around the machine to allow the ventilation grills to keep the machine as

cool as possible. Insufficient ventilation may cause heat buildup and poor printing performance. .....

• Always handle the machine by the correct locations when moving it. .................................................

• Always use anti-toppling and locking devices on machines so equipped. Failure to do this may

cause the machine to move unexpectedly or topple, leading to injury. ...............................................

• Avoid inhaling toner or developer excessively. Protect the eyes. If toner or developer is accidentally

ingested, drink a lot of water to dilute it in the stomach and obtain medical attention immediately.

If it gets into the eyes, rinse immediately with copious amounts of water and obtain medical atten-

tion. .....................................................................................................................................................

• Advice customers that they must always follow the safety warnings and precautions in the

machine’s instruction handbook. .......................................................................................................

2. Precautions for Maintenance

WARNING

• Always remove the power plug from the wall outlet before starting machine disassembly. ................

• Always follow the procedures for maintenance described in the service manual and other related

brochures. ..........................................................................................................................................

• Under no circumstances attempt to bypass or disable safety features including safety mechanisms

and protective circuits. ........................................................................................................................

• Always use parts having the correct specifications. ............................................................................

• Always use the thermostat or thermal fuse specified in the service manual or other related brochure

when replacing them. Using a piece of wire, for example, could lead to fire or other serious acci-

dent. ...................................................................................................................................................

• When the service manual or other serious brochure specifies a distance or gap for installation of a

part, always use the correct scale and measure carefully. ..................................................................

• Always check that the machine is correctly connected to an outlet with a ground connection. ...........

• Check that the power cable covering is free of damage. Check that the power plug is dust-free. If it

is dirty, clean it to remove the risk of fire or electric shock. .................................................................

• Never attempt to disassemble the optical unit in machines using lasers. Leaking laser light may

damage eyesight. ...............................................................................................................................

• Handle the charger sections with care. They are charged to high potentials and may cause electric

shock if handled improperly. ...............................................................................................................

CAUTION

• Wear safe clothing. If wearing loose clothing or accessories such as ties, make sure they are safely

secured so they will not be caught in rotating sections. ......................................................................

• Use utmost caution when working on a powered machine. Keep away from chains and belts. ..........

• Handle the fixing section with care to avoid burns as it can be extremely hot. ..................................

• Check that the fixing unit thermistor, heat and press rollers are clean. Dirt on them can cause

abnormally high temperatures. ...........................................................................................................

• Do not remove the ozone filter, if any, from the machine except for routine replacement. .................

• Do not pull on the AC power cord or connector wires on high-voltage components when removing

them; always hold the plug itself. ........................................................................................................

• Do not route the power cable where it may be stood on or trapped. If necessary, protect it with a

cable cover or other appropriate item. ................................................................................................

• Treat the ends of the wire carefully when installing a new charger wire to avoid electric leaks. ..........

• Remove toner completely from electronic components. .....................................................................

• Run wire harnesses carefully so that wires will not be trapped or damaged. ......................................

• After maintenance, always check that all the parts, screws, connectors and wires that were

removed, have been refitted correctly. Special attention should be paid to any forgotten connector,

trapped wire and missing screws. .......................................................................................................

• Check that all the caution labels that should be present on the machine according to the instruction

handbook are clean and not peeling. Replace with new ones if necessary. .......................................

• Handle greases and solvents with care by following the instructions below: ......................................

· Use only a small amount of solvent at a time, being careful not to spill. Wipe spills off completely.

· Ventilate the room well while using grease or solvents.

· Allow applied solvents to evaporate completely before refitting the covers or turning the power

switch on.

· Always wash hands afterwards.

• Never dispose of toner or toner bottles in fire. Toner may cause sparks when exposed directly to

fire in a furnace, etc. ...........................................................................................................................

• Should smoke be seen coming from the machine, remove the power plug from the wall outlet

immediately. .......................................................................................................................................

3. Miscellaneous

WARNING

• Never attempt to heat the drum or expose it to any organic solvents such as alcohol, other than the

specified refiner; it may generate toxic gas. ........................................................................................

• Keep the machine away from flammable liquids, gases, and aerosols. A fire or an electric shock

might occur. ........................................................................................................................................
