For the Kyocera Laser Printers

Für Kyocera Laserdrucker

Pour imprimantes laser Kyocera

Per la stampanti laser Kyocera

Para las impresoras láser Kyocera

User's Manual

Bedienungsanleitung

Manuel d'utilisation

Istruzioni per l'uso

Manual del usuario

Duplexer

Duplexeinheit

Unité de duplexage

Unità duplex

Duplexor

Declaration of Conformity

Manufacturer’s name: Kyocera Corporation, Printer Division

Manufacturer’s address: 2-14-9 Tamagawadai, Setagaya Ward, Tokyo 158-8610, Japan

declares that the product

Product name: Duplexer

Model number: DU-21 (as tested with Printer FS-1750 and enhancement

optional units HS-21, PF-21, and ST-20 etc.)

Conforms to the following product specifications.

EN 55 022:1998 Class B

EN 50 082-1:1997

IEC 801-2:1991

IEC 801-3:1984

IEC 801-4:1988

EN 60 950:1992+A1+A2+A3+A4

The manufacturer and its merchandising companies retain the following technical documentation in

anticipation of the inspection that may be conducted by the authorities concerned.

User’s instruction that conforms to the applicable specifications

Technical drawings

Descriptions of the procedures that guarantee the conformity

Other technical information

KYOCERA ELECTRONICS EUROPE GmbH

Mollsfeld 12

40670 Meerbusch, Germany

Phone: +49 21 59 918 0

Fax: +49 21 59 918 100

Declaration of Conformity

Manufacturer’s name: Kyocera Corporation, Printer Division

Manufacturer’s address: 2-14-9 Tamagawadai, Setagaya Ward, Tokyo 158-8610, Japan

declares that the product

Product name: Duplexer

Model number: DU-21 (as tested with Printer FS-1750 and enhancement optional units

HS-21, PF-21, and ST-20 etc.)

Description of device: This Page Printer Model FS-1750 is the 14ppm; up to A4 size plain paper,

laser, dry toner etc. The printer can be equipped with several enhancement

optional units such as the Paper Feeder PF-21, Duplexer DU-21 etc.

Conforms to the following product specifications.

AS/NZS 3548:1995

(CISPR 22:1993 Class B)

IEC60 950:1991+A1+A2+A3+A4

(EN 60 950:1992+A1+A2+A3+A4)

The manufacturer and its merchandising companies retain the following technical documentation in

anticipation of the inspection that may be conducted by the authorities concerned.

User’s instruction that conforms to the applicable specifications

Technical drawings

Descriptions of the procedures that guarantee the conformity

Other technical information

The manufacturer has been employed with ISO9001 scheme. The manufacturer has been attested by JQA and BS.

KYOCERA ELECTRONICS AUSTRALIA PTY., LTD

Unit 6, 112, Taravera Road North Ryde,

NSW 2113, Australia

Phone: +61 2-9888-9999

Fax: +61 2-9888-9588

Declaration of Conformity

Model Number: DU-21 (as tested with Printer FS-1750 and enhancement optional units

HS-21, PF-21, and ST-20 etc.)

Trade Name: Kyocera

Responsible Party: Kyocera Electronics Inc.

Address: 11465 John's Creek Parkway

Suite #250 Duluth, GA 30097, U.S.A.

Telephone number: 770-623-2150

Fax number: 770-623-2151

Contact person for technical matter: Paul Bosak

Phone: 770-623-2163

Manufacturer’s name: Kyocera Corporation, Printer Division

Manufacturer’s address: 2-14-9 Tamagawadai, Setagaya Ward,

Tokyo 158-8610, Japan

This device complies with Part 15 of the FCC Rules, Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause undesired operation.

The manufacturer and its merchandising companies retain the following technical documentation in

anticipation of the inspection that may be conducted by the authorities concerned.

User’s instruction that conforms to the applicable specifications

Technical drawings

Descriptions of the procedures that guarantee the conformity

Other technical information KYOCERA ELECTRONICS Inc.

iii

Fig. 1 Names of parts

Abb. 1 Namen der Teile

Fig. 1 Nomenclature

Fig. 1 Nome delle parti

Figura 1 Nombres de las partes

A - Connector A- Anschluß A- Connecteur A- Connettore A- Conector

B- Positioning pins B- Positionierungsstifte B- Broches de positionnement

B- Perni di posizionamento B- Clavijas de colocación

C- READY indicator C- Anzeige READY C- Indicateur READY C- Indicatore READY

C- Indicador de puesta a punto (READY)

D- Duplexer drawer D- Duplexlade D- Caser de l’unité de duplexage D- Cassetto unità duplex

D- Cajón del duplexor

E- Rear cover E- Hintere Abdeckung E- Couvercle arrière E- Coperchio posteriore E- Tapa

trasera

Fig. 2 Typical configurations using the duplexer

Abb. 2 Typische Konfigurationen mit der Duplexeinheit

Fig.2 Configurations typiques en utilisant l’unité de duplexage

Fig. 2 Configurazione tipica con unità duplex

Figura 2 Configuraciones típicas utilizando el duplexor

F- HS-20/HS-21 F- HS-20/HS-21 F- HS-20/HS-21 F- HS-20/HS-21 F- HS-20/HS-21

G- Printer G- Drucker G- Imprimante G- Stampante G- Impresora

Optional PA-20 paper path adaptor

Optionaler Papierwegadapter PA-20

Adaptateur d’acheminement de papier optionnel PA-20

Adattatore del percorso della carta opzionale PA-20

Adaptador opcional de recorrido de papel PA-20

Optional PA-1 paper path adaptor

Optionaler Papierwegadapter PA-1

Adaptateur d’acheminement de papier optionnel PA-1

Adattatore del percorso della carta opzionale PA-1

Adaptador opcional de recorrido de papel PA-1

FG FG FG FG

(d)(a) (b) (c)

Fig. 3 Installing the PA-20 on the front of the duplexer

Abb. 3 Installieren des PA-20 anVorderseite der Duplexeinheit

Fig. 3 Installation du PA-20 à l’avant de l’unité de duplexage

Fig. 3 Installazione del PA-20 sul lato anteriore dell’unità duplex

Figura 3 Instalación del PA-20 en la parte delantera del duplexor

H- Duplexer H- Duplexer H- Duplexeinheit H- Unité de duplexage H- Unità duplex

H- Duplexor

To remove the PA-20, simply reverse the above procedure.

Zum Entfernen des PA-20 den obigen Vorgang einfach umkehren.

Pour retirer le PA-20, inverser tout simplement cette procédure.

Per rimuovere il PA-20, invertire semplicemente la procedura sopraindicata.

Para extraer el PA-20, invierta simplemente el procedimiento dado más arriba.

PA-20

Fig. 4 Lowering the printer

Abb. 4Absenken des Drukers

Fig. 4 Pour baisser l’imprimante

Fig. 4 Posizionamento della stampante

Figura 4 Bajada de la impresora

Fig. 5 Installing the PA-1 on the rear of the duplexer

Abb. 5 Installieren des PA-1 an Rückseite der Duplexeinheit

Fig. 5 Installation du PA-1 à l’arrière de l’unité de duplexage

Fig. 5 Installazione del PA-1 sul lato posteriore dell’unità duplex

Figura 5 Instalación del PA-1 en la parte trasera del duplexor

PA-1

vii

Fig. 6 Removing the PA-1

To remove the PA-1, press at the point indicated in the figure below while sliding

the PA-1 to the right.

Abb. 6 Entfernen des PA-1

Zum Entfernen des PA-1 auf den in der nachfolgenden Abbildung bezeichneten

Punkt drücken und debei den PA-1 nach rechts schieben.

Fig. 6 Pour retirer le PA-1

Pour retirer le PA-1, appuyer à l’endroit indiqué dans l’illustration ci-dessous tout

en glissant le PA-1 vers la droite.

Fig. 6 Rimozione del PA-1

Per rimuovere il PA-1, premete nel punto indicato nella figura in basso mentre

fate scorrere il PA-1 stesso verso destra.

Figura 6 Desmontaje del PA-1

Para desmontar el PA-1, presione en el punto indicado en la figura de abajo y

deslice el PA-1 hacia la derecha.

I- Front of duplexer I- Vorderseite der Duplexeinheit I- Avant de l’unité de duplexage I- Parte

anteriore dell’unità duplex I- Parte delantera del duplexor

J- Push J- Drücken J- Appuyer J- Premere J- Pulse

DU-21

PA-1

viii

Fig. 7 Installing the paper feeder on the duplexer

Abb. 7 Installieren der Papierzuführung auf die Duplexeinheit

Fig. 7 Installation du chargeur de papier sur l’unité de duplexage

Fig. 7 Installazione l’alimentatore sull’unità duplex

Figura 7 Instalación del alimentador de papel en el duplexor

K- Paper feeder K- Papierzuführung K- Chargeur de papier K- Alimentatore carta

K- Alimentador de papel

L- Duplexer L- Duplexeinheit L- Unité de duplexage L- Unità duplex L- Duplexor

Fig. 8 Paper path with duplex printing

Abb. 8 Papierweg bei doppelseitigem Drucken

Fig. 8Acheminement du papier avec impression en duplex

Fig. 8 Percorso carta con stampa fronte-retro

Figura 8 Recorrido del papel con impresión dúplex

M- Paper handler/stacker M- Papier-Handler/Stapler M- Gestionnaire/empileuse

M- Unità trasporto/ordinamento carta M- Manipulador/apilador del papel

N- Printer N- Drucker N- Imprimante N- Stampante N- Impresora

O- Duplexer O- Duplexeinheit O- Unité de duplexage O- Unità duplex O- Duplexor
