Introduction

Trademark Information

• Ethernet is a registered trademark of Xerox Corporation.

• Adobe and Acrobat are registered trademarks of Adobe Systems Incorporated.

• Macintosh and Mac OS are registered trademarks of Apple Computer, Inc. in the USA.

All other company and product names contained in this Operation Guide are trademarks or

registered trademarks of their respective companies. The designations ™ and ® will not be used in

this Operation Guide.

means, electronic or mechanical, including photocopying, recording or by any information storage

and retrieval system, without permission in writing from the Publisher.

Legal Restriction On Copying

• It may be prohibited to copy copyrighted material without permission of the copyright owner.

• It is prohibited under any circumstances to copy domestic or foreign currencies.

• Copying other items may be prohibited.

About this Operation Guide

This Operation Guide is meant to be read when using Scan to Mac and TWAIN for Mac to store

scan data to a Macintosh computer. This Operation Guide explains the procedures of installation

and uninstallation and the basic operation method of each utility.

Since the settings may vary depending on the environment of the Macintosh computer to be

connected, read the necessary sections for proper setting.

This Operation Guide should also be read and used together with the Functions Edition of the

appropriate Operation Guide (On-Line Manual) that is on the included Kyocera Document Library

CD-ROM. The Functions Edition of the Operation Guide (On-Line Manual) explains how to scan

and various setting methods.

Important:

The use of scanned legally copyrighted materials, such as documents, musical scores, pictures,

woodblock prints, maps, drawings and photographs, for any intent other than your own personal or

home use, or other such purpose, is prohibited under the copyright law without prior permission

from the legal copyright owner.

Simply scanning the following items may result in legal penalty:

Bank notes, coins, government-issue securities, national bonds, local bonds, foreign currencies and

securities, unused postage stamps, government post cards, government stamps, and securities

regulated by the liquor tax law.

Other items that you should also not scan:

It is additionally recommended that you do not attempt to scan government-issue passports, or

licenses, permits, ID cards, securities, commuter tickets, passes, books of tickets and meal coupons

issued by public organizations or private parties.

Getting connected

For scanning with each utility, the following procedure is needed.

Connect the scanner to a Macintosh computer

Operation of scanner: Refer to the Set up Edition of the Operation Guide for the scanner.

Operation on Macintosh

Network cable

Scanner Macintosh

Hub Connect the scanner to the Macintosh

computer through a network cable

(100BASE-TX or 10BASE-T).

Basic scanner settings (register the host name and IP address, etc.)

Registering and editing user information

Date/time and time difference settings

Scan to Mac: Refer to Installing Scan to Mac on page 1.

Saves the scanned image as a data file on your computer.

TWAIN for Mac: Refer to Installing TWAIN for Mac on page 5.

Captures the picture image to a TWAIN-compatible application.

You’re now ready to scan!

iii

Contents

Introduction ............................................................................................................. i

Trademark Information ..................................................................................................................... i

About this Operation Guide .............................................................................................................. i

Important: ......................................................................................................................................... i

Getting connected ........................................................................................................................... ii

1 Scan to Mac ............................................................................................................ 1

Outline of Scan to Mac .................................................................................................................... 1

Installation and uninstallation .......................................................................................................... 1

Setting the folder ............................................................................................................................. 2

Operating Scan to Mac .................................................................................................................... 4

2 TWAIN for Mac ........................................................................................................ 5

Outline of TWAIN for Mac ................................................................................................................ 5

Installation and uninstallation .......................................................................................................... 5

Setting the scanner .......................................................................................................................... 7

Operating TWAIN for Mac ............................................................................................................... 7

Appendix ............................................................................................................................ 9

System requirements ....................................................................................................................... 9

1 Scan to Mac

Outline of Scan to Mac

Scan to Mac is a utility that allows an image captured with the scanner to be received on a

Macintosh computer and to be stored in a specified folder.

To use this utility, you must set the destination on the scanner. For details, refer to the Set up Edition

of the Operation Guide for the scanner.

Installation and uninstallation

Installing Scan to Mac

Perform the following procedure to install Scan to Mac.

1Start Macintosh. Close any applications that are running.

2Insert the supplied CD-ROM into the optical drive.

3Double-click the CD-ROM icon.

4Open the [ScanToMac] folder.

5Double-click [Scan to Mac for OS9] or [Scan to Mac OS X] according to your Mac OS.

If the operating system is Mac OS 10.1 or later, the authentication screen is displayed. Enter the

administrator name and password and click [OK].

6The description concerning the license agreement is displayed. To accept the terms and conditions,

click [Accept].

7Click [Install].

Installation of Scan to Mac starts. Follow the

instructions displayed on the screen to

install Scan to Mac.

Scan to Mac

Uninstalling Scan to Mac

Perform the following procedure to uninstall Scan to Mac.

1Start Macintosh. Close any applications that are running.

2Insert the supplied CD-ROM into the optical drive.

3Double-click the CD-ROM icon.

4Open the [ScanToMac] folder.

5Double-click [Scan to Mac for OS9] or [Scan to Mac OS X] according to your Mac OS.

If the operating system is Mac OS 10.1 or later, the authentication screen is displayed. Enter the

administrator name and password and click [OK].

6The description concerning the license agreement is displayed. To accept the terms and conditions,

click [Accept].

7Select [Uninstall] from the pull-down menu

at the upper left and click [Uninstall].

Uninstallation of Scan to Mac starts. Follow

the instructions displayed on the screen to

uninstall Scan to Mac.

Setting the folder

Set the folder in which images sent from the scanner are stored. Use the following method to open

the main dialog for setting the folder.

For Mac OS 10.1 or later

Open the [Application]/[Utilities] folder and double-click [KM Scan to Mac].

For Mac OS 9.1 to 9.22

Open the [Kyocera Scan to Mac] folder on the desktop and double-click [KM Scan to Mac].

Scan to Mac

Main dialog

This section explains the main dialog for Scan to Mac.

For Mac OS 10.1 or later

1 Connection status: Displays the status of the scanner.

2 Image files: Displays the status of reception of image.

3List: Click to display the list of received images.

4 Show preferences: Click to switch display/non-display of the setting fields for [Destination

Folders] and [File name prefix].

5 Destination Folders: Displays folders in which images are stored as a list.

6Add: Click to add a destination folder for storing images. The folder number, folder location,

and password can be set.

7Edit: Click to change the setting for a destination folder.

8 Delete: Click to delete a destination folder.

9 File name prefix: Set the storage name of an image here. If [Scanner default] is input, the file

name that has been set on the scanner is used.

10 Apply: Click to apply the changed data.

11 Quit: Click to terminate this dialog.

Scan to Mac

For Mac OS 9.1 to 9.22

1 Connection status: Displays the status of the scanner.

2 Image Files: Displays the status of reception of image.

3List: Click to display the list of received images.

4Show/Hide preferences: Click to switch display/non-display of the setting fields for

[Destination folders], [TIFF application] and [File name prefix].

5 Destination folders: Displays folders in which images are stored as a list.

6Add: Click to add a destination folder for storing images. The folder number, folder location,

and password can be set.

7Edit: Click to change the setting for a destination folder.

8Delete: Click to delete a destination folder.

9 TIFF application: Click [Browse] to specify an application for opening the images stored in the

TIFF format.

Note The image file format is set on the scanner when the image is scanned.

10 File name prefix: Set the storage name of an image here. If [Scanner default] is input, the file

name that has been set on the scanner is used.

11 Apply: Click to apply the changed data.

12 Quit: Click to terminate this dialog.

Operating Scan to Mac

Set a Macintosh computer and folder as destination on the scanner and scan the original. For

details, refer to the Set up Edition of the Operation Guide for the scanner.

10 11

2 TWAIN for Mac

Outline of TWAIN for Mac

TWAIN for Mac is a utility that allows scanning from a TWAIN-compatible application and image

capture with easy operation.

TWAIN for Mac can be used on Mac OS 10.1 or later. Also, a TWAIN-compatible application must

be installed.

Installation and uninstallation

Installing TWAIN for Mac

Perform the following procedure to install TWAIN for Mac.

1Start Macintosh. Close any applications that are running.

2Insert the supplied CD-ROM into the optical drive.

3Double-click the CD-ROM icon.

4Open the [TWAINforMac] folder.

5Double-click [TWAIN for Mac OS X].

6The authentication screen is displayed. Enter the administrator name and password and click [OK].

7The description concerning the license agreement is displayed. To accept the terms and conditions,

click [Accept].

8Click [Install].

Installation of TWAIN for Mac starts. Follow

the instructions displayed on the screen to

install TWAIN for Mac.

9After the installation is complete, set the scanner. Click

[Configure] to open [System Preference]. For the

method of setting, refer to Setting the scanner on

page 7.
